– CONNECTIONS –
INPUT Jack – This ¼" jack is the audio input of the LESTER G. The input
impedance is 1M.
MONO/L and R OUTPUT Jacks – The LESTER G has true stereo output. The
two ¼" output jacks are labeled MONO/L and R. Connect these jacks to two
separate amps or inputs on a mixing board. If using the LESTER G as a mono
effect, we suggest you use the MONO/L output. The output impedance of each
jack is 220.
EXP Jack – Plug an expression pedal into this jack to control the LESTER G's
rotation speed. See "Using an Expression Pedal" on the next page for more
information on how to use the expression pedal.
The EXP input jack accepts a TRS expression pedal connector or a Tip-Sleeve 0-
5V control voltage input. The expression pedal should ideally use a 10k
potentiometer with linear taper. It must have the wiper connected to TIP and
toe-down connected to RING. Some manufacturers' pedals do not conform to
this convention and require a special cable/adaptor to swap RING and TIP.
Suggested Expression Pedals: EHX Expression Pedal, M-Audio® EX-P, Moog®
EP-2 & EP-3, Roland® EV-5 or Boss® FV-500L.
9V Power Jack – Plug the output of the LESTER G's supplied EHX9.6DC 200mA
AC Adapter into the 9V power jack located at the top of the LESTER G. The
LESTER G requires 100mA at 9VDC with a center-negative plug.
