Right channel delay time is 3x longer
than the Left delay time producing a
wide stereo spectrum. Right delay
time maximum is 150ms while the
Left maximum is 50ms. Helpful Hint:
Disable Dry Detune to make best use
of the Spread effect when the POG3 is
routed in mono.
17. DRY Buttons The DRY buttons
below the ATTACK, FILTER, and DETUNE
sliders route the dry signal through
the corresponding effects when lit.
18. PRESET Footswitch Activates
the current preset and then, with sub-
sequent presses, scrolls down and
loads the next preset. Press and hold
this footswitch to scroll down quickly
through the presets. Press the PRESET
and PRESET footswitches at the
same time to deactivate the current
preset and return to LIVE mode.
19. PRESET Footswitch Activates
the current preset and then, with sub-
sequent presses, scrolls up and loads
the next preset. Press and hold this
footswitch to scroll up quickly through
the presets. Press the PRESET
PRESET footswitches at the same
time to deactivate the current preset
and return to LIVE mode.
20. PRESET LED The PRESET LED lights
solid green when a preset is loaded and
1. POWER Jack Connect the output
plug of the factory-supplied AC adapter
into the 9VDC power jack. The current
requirement is 300mA at 9VDC. The
polarity of the power jack is center-
negative. The maximum allowable
power supply voltage is 10.5 VDC.
2. USB Port Connects to the Electro-
Harmonix EHXport™ app running on
blinks when a loaded preset has been
edited. The PRESET LED is off when
no preset is loaded, as in LIVE mode.
21. EFFECT Footswitch The EFFECT
footswitch toggles the POG3 between
effect mode and buffered bypass.
22. EFFECT LED The EFFECT LED lights
solid to indicate the POG3 is in effect
mode and is off in bypass.
ILLUMINATED SLIDERS Slider values
are generated by various sources
including presets, expression sweeps,
MIDI, the EHXport application, or in
LIVE mode, the actual position of the
slider. The POG3 employs illuminated
sliders to indicate the current position
of each slider, no matter the source of
its value. As a slider is pushed up to
maximum, the LED brightness increases.
If a slider is moved after loading a
preset, the new physical setting of the
slider takes over. The slider's LED blinks
indicating that the slider has been
moved, and that its value no longer
matches the value in the preset.
and
Helpful Hint: the current value of any
control always comes from the last
source to update it. The available
sources are presets, MIDI, expression,
EHXport or physical movement of the
control.

Connections

a Windows or Mac computer. EHXport
allows for preset editing and creation,
preset transfers—for backup, restore
and preset rearrangement within the
POG3, firmware updates, and global
settings adjustments.
3. MIDI IN Jack Connect a standard
5-pin DIN MIDI cable to this connector
to receive MIDI Control Change (CC),
