ENGLISH
Note: The shoe can be beveled to the left or to the right and
has detents at 22.5° and 45°.
This jig saw is equipped with three cutting actions, two orbital
and one straight. Orbital action has a more aggressive blade
motion and is designed for cutting in soft materials like wood
or plastic. Orbital action provides a faster cut, but with a less
smooth cut across the material. In orbital action, the blade
moves forward during the cutting stroke in addition to the up
and down motion.
Warning! Metal or hardwoods should never be cut in orbital
action.
Slide the cutting action button (7) between the three
u
cutting positions: 0, 1 and 2.
Position 0 is for straight cutting.
u
Positions 1 and 2 are for orbital cutting.
u
The aggressiveness of the cut increases as the lever is
u
adjusted from one to two, with two being the most
aggressive cut.
Sawing
Always hold the tool with both hands.
u
Let the blade run freely for a few seconds before starting
u
the cut.
Apply only a gentle pressure to the tool while performing
u
the cut.
If possible, work with the shoe plate (5) pressed against
u
the workpiece. This will improve tool control and reduce
tool vibration, as well as prevent the blade from being
damaged.
Hints for optimum use
General
Use a high speed for wood, a medium speed for
u
aluminium and PVC and a low speed for metals other than
aluminium.
Sawing laminates
As the saw blade cuts on the upward stroke, splintering may
occur on the surface closest to the shoe plate.
u
Saw from the back surface of the workpiece.
u
To minimise splintering, clamp a piece of scrap wood or
u
hardboard to both sides of the workpiece and saw through
this sandwich.
Sawing metal
Be aware that sawing metal takes much more time than
sawing wood.
8
(Original instructions)
Use
u
saw blade for ferrous metals and a coarser saw
blade for non-ferrous metals.
When cutting thin sheet metal, clamp a piece of scrap
u
wood to the back surface of the workpiece and cut through
this sandwich.
u
Accessories
The performance of your tool depends on the accessory used.
BLACK+DECKER accessories are engineered to high quality
standards and designed to enhance the performance of your
tool. By using these accessories you will get the very best
from your tool.
This tool is suitable both for U-shank and T-shank saw blades.
Maintenance
Your tool has been designed to operate over a long period of
time with a minimum of maintenance. Continuous satisfactory
operation depends upon proper tool care and regular cleaning.
Warning! Before performing any maintenance, switch off and
unplug the tool.
Regularly clean the ventilation slots in your tool and
u
charger using a soft brush or dry cloth.
Regularly clean the motor housing using a damp cloth. Do
u
not use any abrasive or solvent-based cleaner.
Occasionally apply a drop of oil to the axle of the blade
u
support roller (5).

Protecting the environment

Separate collection. This product must not be
disposed of with normal household waste.
needs replacement, or if it is of no further use to you, do
not dispose of it with household waste. Make this product
available for separate collection.
z
Separate collection of used products and
packaging allows materials to be recycled and
used again. Re-use of recycled materials helps
prevent environmental pollution and reduces the
demand for raw materials.
Local regulations may provide for separate collection of
electrical products from the household, at municipal waste
sites or by the retailer when you purchase a new product.
