Super high resolution dome camera

Advertisement

Super High Resolution Dome Camera
User Manual
2
SCD- 081

Advertisement

Table of Contents
loading

Summary of Contents for Samsung SCD-2081

  • Page 1 Super High Resolution Dome Camera User Manual SCD- 081...
  • Page 2: User Manual

    Samsung Techwin. Disclaimer Samsung Techwin makes the best to verify the integrity and correctness of the contents in this document, but no formal guarantee shall be provided. Use of this document and the subsequent results shall be entirely on the user’s own responsibility.
  • Page 3 Before operating the camera, confirm the camera model and correct input power voltage. To help you understand this manual thoroughly, we’ll introduce our model description. ■ SCD-2081 SERIES • NTSC MODEL • PAL MODEL SCD-2081P SCD-2081N ■ MODEL DESCRIPTION • SCD-2081X...
  • Page 4 safety information CAUTION RISK OF ELECTRIC SHOCK. DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK) NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. This symbol indicates that dangerous voltage consisting a risk of electric shock is present within this unit.
  • Page 5 If this product fails to operate normally, contact the nearest service center. never disassemble or modify this product in any way. (samsung is not liable for problems caused by unauthorized modifications or attempted repair.) When cleaning, do not spray water directly onto parts of the product.
  • Page 6: Fcc Statement

    safety information fCC sTATemeNT This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions : This device may not cause harmful interference This device must accept any interference received including interference that may cause undesired operation.
  • Page 7: Important Safety Instructions

    Apparatus shall not be exposed to dripping or splashing and no objects filled with liquids, such as vases, shall be placed on the apparatus Samsung Techwin cares for the environment at all product manufacturing stages to preserve the environment, and is taking a number of steps to provide customers with more environment-friendly products.
  • Page 8: Table Of Contents

    contents INTRODUCTION Features What’s included Component names and Functions INSTALLATION Installation Adjust the panning and tilting while watching the monitor CONNECTION Connecting to Monitor Connecting to Power Using Coaxial Communications SETUP Menu Configration Menu Setup TROUBLESHOOTING Troubleshooting SPECIFICATIONS Specifications Dimension _ contents...
  • Page 9: Introduction

    Motion Detection Without assistance from an external sensor, this camera independently detects and traces objects while examining movement to activate the alarm. ssNR3 (samsung super Noise Reduction) function  The high-performance SV-V DSP chip effectively removes low-light gain noise and afterimage to provide clear images even in dark environments.
  • Page 10 introduction  The camera’s OSD is complimented by 18 languages. - NTSC: English, Korean, Japanese, Spanish, French, Portuguese, Taiwanese - PAL: English, Chinese, German, Italian, French, Spanish, Russian, Czech, Polish, Romanian, Serbian, Swedish, Danish, Turkish, Portuguese. 10_ introduction...
  • Page 11 AUTO 6.DIA/NOCHE AUTO 1480 Charles Willard St, Carson, CA 90746, UNITED STATES Samsung House, 1000 Hillswood Drive, Hillswood Business AUTO / EXTERN / COLOR / S/W Tol Free : +1-877-213-1222 FAX : +1-310-632-2195 Park Chertsey, Surrey, UNITED KINGDOM KT16 OPS 7.PROFIL...
  • Page 12: Component Names And Functions

    introduction COmpONeNT NAmes AND fUNCTIONs OVeRVIeW ➌ ❶ ➐ ➏ ⓬ ⓫ ❿ ➒ ➑ Dome Cover ❶ shield Case ❷ Pan Base : control panning angle of camera ❸ 3.9 Vari-focal Lens Module 2.8 ~ 11.0mm (F1.2) ❹ Function Setup Switch : Display the OSD menu and move the cursor up, down, ❺...
  • Page 13: Installation

    installation INSTALLATION Separate the dome cover by turning anti-clockwise. Separate the shield case by pulling from the camera body. * To install the dome cover on the camera body, turn the latches in locking direction as Latch shown in the [Figure-1]. Locking direction Main Body (Camera)
  • Page 14 installation WHeN UsING THe CeIlING bRACkeT Ceiling bracket An arrow for installing Lock Lever directions M4 tapping screw (provided) CAMERA Locking direction Unlocking direction Dome cover Hold down the lock lever on the bottom of the camera in the UNLOCK position and turn it counter clockwise with the other hand to remove the ceiling bracket from the main body.
  • Page 15 If DeTACHING THe CAmeRA fROm THe INsTAllATION pOsITION Pan Base fixation screw M4 tapping screw [Figure-2]  If you want to install the camera with the ceiling bracket together, fi x them using two M4 tapping screws at the side of the main body (refer to the [Figure-2] on page 14) IF DETACHING THE CAMERA FROM THE INSTALLATION POSITION Lock Lever Remove the dome cover as well as the...
  • Page 16 installation ADJUST THE PANNING, TILTING & ROTATION WHILE WATCHING THE MONITOR 73˚ 174˚ 174˚ 176˚ Rotate Base Tilt Base Pan Base 176˚ You can adjust camera to any direction by using Pan, Tilt, Rotate mechanism. Pan Base moves by 176˚ to each side direction and 352˚ on the whole. ...
  • Page 17: Connection

    connection CONNeCTING TO mONITOR Connect the VIDEO-OUT jack to the VIDEO-IN jack of monitor. CCTV Camera Monitor As the connecting method varies with the instruments, refer to the manual supplied  with the instrument. Only connect the cable when the power is turned off. ...
  • Page 18: Using Coaxial Communications

    connection * Standard voltage for camera operation : DC 12V ±10%, AC 24V ± 10% * There may be some deviation in voltage drop depending on the type of wire and the manufacturer. Be sure to connect power only after all the installation is complete. Note that AC/DC adaptor is not supplied with camera.
  • Page 19: Setup

    setup meNU CONfIGRATION setup menu leNs ● BRIGHTNESS SHUTTER ● ● ● eXpOsURe SENS-UP RETURN ● ● SSDR ● ● ● ATW ● OUTDOOR ● INDOOR WHITe bAl ● MANUAL ● AWC→SET bACklIGHT ● ● ● USER BLC ssNR3 ● ON ●...
  • Page 20: Setup

    setup Press the Function Setup switch. Main setup menu is displayed on the monitor screen.  MAIN SETUP ▶ 1.LENS Select the function Change the status by moving up or by moving the 2.EXPOSURE down direction of SSDR setup switch left or function setup switch.
  • Page 21: Setup

    eXpOsURe When the SETUP menu screen is displayed, MAIN SETUP select EXPOSURE by using the Function 1.LENS Setup switch so that the arrow indicates ▶ 2.EXPOSURE 'EXPOSURE'. 3. SSDR Select a desired mode using the Function Setup switch. bRIGHTNess : Adjusts the video brightness. ...
  • Page 22: Setup

    Note that the higher the SENS-UP level, the brighter the screen, but the more likely it is that an after-image will appear. Although Noise, Spots, and Whitish symptoms may occur in SENS-UP operation when the sens-up level is increased, this is normal. ssDR ( sAmsUNG sUpeR DyNAmIC RANGe SSDR illuminates darker areas of an image SSDR SETUP...
  • Page 23: Setup

    WHITe bAl (WHITe bAlANCe) Use the White Balance function to adjust the screen color. When the SETUP menu screen is displayed, select ‘White Bal.’ by using the Function Setup switch so that the arrow indicates ‘White Bal.’. MAIN SETUP 1.LENS Select a desired mode using the Function 2.EXPOSURE Setup switch.
  • Page 24: Setup

    setup BACKLIGHT This camera is designed so that it delivers a distinctive subject and background at the same time, even when the subject is in backlight, unlike conventional cameras, by adopting a proprietary SV-V DSP chip. When the SETUP menu screen is displayed, MAIN SETUP 1.LENS select ‘BACKLIGHT’...
  • Page 25: Setup

    SSNR3 This function reduces the background noise in a low luminance environments. When the SETUP menu screen is displayed, MAIN SETUP select 'SSNR3' by using the Function Setup 1.LENS switch so that the arrow indicates 'SSNR3' . 2.EXPOSURE Select a desired mode using the Function SSDR Setup switch.
  • Page 26: Setup

    setup AUTO SETUP ▶1.BURST MODE 2.COLORB/W DURATION FAST DWELL TIME 5 SEC 3.B/WCOLOR DURATION FAST DWELL TIME 10 SEC 4.RETURN BURST MODE : You can turn on or off the burst signal on B/W mode. DWELL TIME : You can select the duration time about changing the day/night mode.
  • Page 27: Setup

    SPECIAL When the SETUP menu screen is displayed, MAIN SETUP select ‘SPECIAL’ by using the Function Setup 1.LENS switch so that the arrow indicates ‘SPECIAL’. 2.EXPOSURE SSDR Select a desired mode using the Function WHITE BAL Setup switch. BACKLIGHT ImAGe ADJ : ...
  • Page 28: Setup

    setup ReVeRse : You can reverse the picture.  OFF : You don’t reverse the picture. H-REV : You can flip the picture horizontally on the screen. V-REV : You can flip the picture vertically on the screen. H V-REV : You can flip the picture horizontally and vertically on the screen. pIp(picture in picture) : Displays a full- ...
  • Page 29: Setup

    i t c r i s e t t t e l r e t ➍ by pressing the switch. Repeat this to enter multiple letters. You can enter up to 15 letters. t i t , e l P ’ ’...
  • Page 30: Setup

    setup : Commands the camera to motion-detect and trace an object.  MOTION DET 1 If the SPECIAL menu screen is MOTION DET displayed, use the Function Setup DETECT BOX ▶ switch so that the arrow indicates ALARM OUT ‘ ’.
  • Page 31: Setup

    PRIVACY ea you want to hide on the screen.  ➊ PRIVACY AREA SETUP displayed, press the Function Setup 1.AREA AREA1 ▶ switch so that the arrow indicates 2.MODE ‘PRIVACY’. 3.MASK COLOR GREEN i t c ➋ 4.TRANSPARENCY Setup switch. 5.SEL POS L_TOP 6.X POS...
  • Page 32: Setup

    setup  pROfIle ‘PROFILE’ by using the 1. When the SETUP menu screen is displayed, seLect Functfion Setup button so that the arrow Indicates ‘PROFILE’. SPECIAL 1.IMAGE ADJ 2.CAM TITLE 3.SYNC MOTION DET 5.PRIVACY 6.DIS ▶ PROFILE BASIC RETURN Select a desfred mode using the Function Setup button according to the picture display you want.
  • Page 33: Setup

    In the PROFILE menu, you can configure the following camera settings at once. BASIC DAY/NIGHT BACKLIGHT INDOOR USER SHUTTER MANUAL(1/250) A.FLK GAIN HIGH HIGH HIGH HIGH HIGH WHITE BAL OUTDOOR INDOOR BACKLIGHT USER BLC SSNR3 DAY/NIGHT AUTO AUTO AUTO AUTO AUTO ReTURN : Select this to save the SPECIAL menu settings and return to the MAIN ...
  • Page 34: Troubleshooting

    troubleshooting TROUblesHOOTING If you have trouble operating your camera, refer to the following table. If the guidelines do not enable you to solve the problem, contact an authorized technician. pROblem sOlUTION ▶ Check that the power cord and line connection between the camera Nothing appears on the screen.
  • Page 35: Specifications

    specifications speCIfICATIONs SCD-2081N SCD-2081P VIDEO Imaging Device Super HAD CCD 1/3‘’ Total Pixels 1020(H) x 508(V) 1020(H) x 596(V) Effective Pixels 976(H) x 494(V) 976(H) x 582(V) Scanning System 2 : 1 Interlace Synchronization Internal / Line Lock Frequency H:15.734KHz / V:59.94Hz H:15.625KHz / V:50Hz Horizontal Resolution Color : 650 TV lines, B/W : 700 TV lines...
  • Page 36 specifications sCD-2081p sCD-2081N Day & Night Auto / EXT/ Color / B/W Backlight Compensation Off/ USER BLC / HLC Off / On Dynamic Range (SSDR) Off / On Digital Noise Reduction ( SSNR Ⅲ ) Off / On Digital Image Stabilization Off / On Privacy Masking Off / On (12 Programmable zones, Polygonal type) 2x ~ 512x...
  • Page 37 DImeNsION English_3...
  • Page 38 MEMO...
  • Page 39 MEMO...
  • Page 40 SAMSUNG TECHWIN AMERICA Inc. SAMSUNG TECHWIN EUROPE LTD. 100 Challenger Rd. Suite 700 Ridgefield Park, NJ 07660 Samsung House, 1000 Hillswood Drive, Hillswood Business Park Toll Free : +1-877-213-1222 Direct : +1-201-325-6920 Chertsey, Surrey, UNITED KINGDOM KT16 OPS Fax : +1-201-373-0124 TEL : +44-1932-45-5300, FAX : +44-1932-45-5325 www.samsungcctvusa.com...
