KFP-CE4 Series
Installation Manual
P/N 501-415503-1-31 • REV 03.10 • ISS 08NOV13

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KFP-CE4 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Kilsen KFP-CE4 Series

Summary of Contents for Kilsen KFP-CE4 Series

  • Page 1 KFP-CE4 Series Installation Manual P/N 501-415503-1-31 • REV 03.10 • ISS 08NOV13...
  • Page 2 Copyright © 2013 UTC Fire & Security. All rights reserved. Trademarks and The KFP-CE4 Series name and logo are trademarks of UTC Fire & patents Security. Other trade names used in this document may be trademarks or registered trademarks of the manufacturers or vendors of the respective products.

  • Page 3: Table Of Contents

    Mechanical and environmental specifications 67 Fire network specifications 68 Cabinet drawings and dimensions 69 Appendix A Configuration presets 71 Operating mode presets 72 Expansion board presets 74 Appendix B Product compliance 81 European standards 82 Index 85 KFP-CE4 Series Installation Manual...

  • Page 4: Important Information

    Important information This is the installation manual for KFP-CE4 Series fire and evacuation control panels. Read these instructions and all related documentation entirely before installing or operating this product. Software compatibility Information in this document applies to control panels with software version 2.0 or later.
  • Page 5 Installation in accordance with this manual, applicable codes, and the instructions of the authority having jurisdiction is mandatory. While every precaution has been taken during the preparation of this manual to ensure the accuracy of its contents, UTCFS assumes no responsibility for errors or omissions. KFP-CE4 Series Installation Manual...
  • Page 6 KFP-CE4 Series Installation Manual...

  • Page 7: Introduction

    Chapter 1 Introduction Summary This chapter provides an introduction to your control panel and the available operating modes. Content Product range 2 Product compatibility 2 Operating modes 2 KFP-CE4 Series Installation Manual...

  • Page 8: Product Range

    Chapter 1: Introduction Product range Panels in the KFP-CE4 Series are conventional fire and evacuation control panels. The series includes the models shown below. Model Description KFP-CE4 Four-zone conventional fire alarm and evacuation control panel, supporting four evacuation areas without alarm counter...
  • Page 9 Chapter 1: Introduction When the panel is configured for EN 54-13 zone supervision, the corresponding insert shows a Fault Output Fault/Disabled LED for use in the fault warning output supervision required by EN 54-13. KFP-CE4 Series Installation Manual...
  • Page 10 Chapter 1: Introduction KFP-CE4 Series Installation Manual...

  • Page 11: Installation

    Connecting the mains power supply 18 Selecting 115 or 230 VAC operation 19 Connecting the batteries 20 Powering auxiliary equipment (24 VDC auxiliary output) 20 Connecting alarm and fault relays 21 Connecting expansion boards 21 Connecting a fire network 21 KFP-CE4 Series Installation Manual...

  • Page 12: Cabinet Layout

    Chapter 2: Installation Cabinet layout Figure 1: Cabinet layout for KFP-CE4 Series control panels 1. Seven-segment display 8. Key connector 2. Zone and system connectors 9. Alarm counter connector 3. Cable knockouts 10. Fuse terminal block 4. Mounting screw knockouts 11.

  • Page 13: Cabinet Installation

    Fixing the cabinet to the wall The requirements for nylon wall plugs and screws are shown in the following table. Model Screws Wall plugs Four-zone evacuation control M4 × 30 (4X) Ø 6 mm (4X) panel KFP-CE4 Series Installation Manual...
  • Page 14 2. Drill all required holes and insert a 6 mm wall plug into each. 3. Insert screw (1) half way and hang the cabinet onto this screw. 4. Insert screws (2) and tighten. 5. Insert screws (3) and tighten. 6. Tighten screw (1). KFP-CE4 Series Installation Manual...

  • Page 15: Menu Inserts

    3. Remove the control panel cover. 4. Insert each segment in the appropriate slot, as shown in Figure 3 below. Make sure that the inserts are positioned correctly. 5. Replace the control panel cover. Figure 3: Applying the menu inserts KFP-CE4 Series Installation Manual...

  • Page 16: Connections

    All cables should be fed through the cable guides in the cabinet housing to eliminate movement. Overview of fire and evacuation system connections Standard, EN 54-13, active end-of-line, and intrinsically-safe system connections are shown in the following figures. KFP-CE4 Series Installation Manual...
  • Page 17 Chapter 2: Installation Figure 4: Standard system connections, no EN 54-13 requirement Figure 5: Standard system connections, for EN 54-13 compliance KFP-CE4 Series Installation Manual...
  • Page 18 1. A diode must be connected on the detector base. (Consult your detector installation manual for more details). Figure 7: Intrinsically-safe system connections 1. Galvanic barrier for intrinsically-safe conventional detectors. 2. Galvanic barrier for intrinsically-safe fire notification devices. KFP-CE4 Series Installation Manual...

  • Page 19: Connecting Zones And Zone Devices

    4.7 kΩ, 5%, 1/4 W end- of-line resistor. Connecting detectors Connect detectors as shown in Figure 4, Figure 5, Figure 6, and Figure 7 starting on page 11. KFP-CE4 Series Installation Manual...

  • Page 20: Connecting Inputs

    Table 6: Default input functionality for inputs 1 and 2 Operating mode INPUT1 INPUT2 NEN 2575 (EN 54-13 disabled) Fire routing inhibit delay Delay off NEN 2575 (EN 54-13 enabled) Fire routing acknowledgement Fault warning output (open (type 1, 100 seconds) supervision) KFP-CE4 Series Installation Manual...
  • Page 21 ≤ 220 Ω Short circuit (type 1, 100 seconds) > 220 Ω to 8 kΩ Active [2] > 8 kΩ to 10 kΩ Fault [3] > 10 kΩ to 20 kΩ Standby > 20 kΩ Open circuit KFP-CE4 Series Installation Manual...

  • Page 22: Connecting Supervised Outputs

    3 or zone 4 zone 3 or zone 4 NEN 2575 with Evacuation Evacuation Evacuation Evacuation one evacuation sounders for any sounders for any sounders for any sounders for any area zone zone zone zone KFP-CE4 Series Installation Manual...
  • Page 23 Depending on the operating mode, up to four sounder or notification device circuits can be connected. See Table 10 on page 16. Connecting fire routing equipment to supervised outputs Connect fire routing equipment as shown in Table 13 on page 18. KFP-CE4 Series Installation Manual...

  • Page 24: Connecting The Mains Power Supply

    Connecting the mains power supply Note: To avoid unwanted arcing, connect the mains power supply before connecting the batteries. The control panel can be operated at 110 V at 60 Hz or 240 V at 50 Hz (+10% or −15%). KFP-CE4 Series Installation Manual...

  • Page 25: Selecting 115 Or 230 Vac Operation

    Figure 11 on page 20. Caution: Risk of equipment damage. An incorrect power setting can destroy the power supply. KFP-CE4 Series Installation Manual...

  • Page 26: Connecting The Batteries

    Powering auxiliary equipment (24 VDC auxiliary output) Connect auxiliary equipment that requires 24 VDC power to the 24 AUX terminals as shown in Figure 4 on page 11. The 24 VDC auxiliary output is supervised for short circuit and voltage output level. KFP-CE4 Series Installation Manual...

  • Page 27: Connecting Alarm And Fault Relays

    Figure 13: Network board connections Two wiring options are possible: • Ring configuration • Bus configuration Ring configuration Ring network configuration is recommended as it provides for redundancy in the transmission path. KFP-CE4 Series Installation Manual...
  • Page 28 (sounder and fire routing outputs) are not remote between panels. Bus network configuration is not normally recommended, as it does not provide for redundancy in the transmission path. For bus configuration (Class B), connect control panels as shown below. Figure 15: Fire network bus configuration KFP-CE4 Series Installation Manual...

  • Page 29: Configuration And Commissioning

    The advanced configuration menu 36 Sounder operation during a zone test 38 Sounder re-sound 38 Zone configuration 39 Zone delay 40 Zone type 41 Input configuration 42 Changing user level passwords 43 Auxiliary 24 V reset 44 KFP-CE4 Series Installation Manual...
  • Page 30 Expansion board configuration 46 Fire network and repeaters configuration 48 Basic configuration options 48 Advanced configuration options 50 Commissioning 54 Before commissioning the control panel 54 Commissioning the control panel 55 Functional tests 56 Response times 56 KFP-CE4 Series Installation Manual...

  • Page 31: The User Interface

    19. Earth Fault LED 9. Reserved for special use 20. Supply Fault LED 10. Expansion I/O Fault/Disabled LED 21. Fire Routing Delay button and LED 11. General Disable button and LED 22. Fire Routing On/Acknowledge button and LEDs KFP-CE4 Series Installation Manual...

  • Page 32: User Levels

    This level is also required for installers that require minor customizations after configuring a basic installation. Passwords and indications for each user level are described in “User level passwords and indications” on page 27. KFP-CE4 Series Installation Manual...

  • Page 33: Configuration Overview

    The control panel is configured using the front panel configuration controls and the seven-segment display. The configuration controls are also used to enter the user level password. The configuration controls The configuration controls are located on the control panel interface. KFP-CE4 Series Installation Manual...
  • Page 34 Select a menu using buttons 1 and 3 when this LED is steady. — or — Select a submenu using buttons 1 and 3 when this LED is flashing. Value Select a value using buttons 2 and 4 when this LED is steady KFP-CE4 Series Installation Manual...

  • Page 35: Common Configuration Tasks

    To exit configuration mode without saving your changes: 1. Press Reset — or — 1. Set the display as shown below, and then press Enter. The control panel will exit configuration mode after 5 minutes if no button is pressed. KFP-CE4 Series Installation Manual...

  • Page 36: Basic Configuration

    Configuration options for this menu are shown in the table below. More information for each option is included in the related topic. Table 18: The basic configuration menu Display Menu Values Basic default configuration See topic EN 54-13 supervision ON/OFF KFP-CE4 Series Installation Manual...

  • Page 37: Basic Default Configuration

    1. Set the display as shown below, and then press Enter. 2. Select a value using the value selection buttons (2 and 4). See Table 19 on page 32 for descriptions of the presets. 3. Press Enter. 4. Save your changes. KFP-CE4 Series Installation Manual...

  • Page 38: En 54-13 Supervision Mode

    2. Select the supervision mode using the value selection buttons (2 and 4). 3. Press Enter. 4. Save your changes. The available settings for this feature are shown below. KFP-CE4 Series Installation Manual...

  • Page 39: Panel Mode

    • Zone delay • Zone configuration • Zone type • Input configuration The seven-segment display will alternate the custom and base operating mode indications, as shown above. KFP-CE4 Series Installation Manual...

  • Page 40: Fire Routing Delay

    Extended fire routing delay Use this menu to configure an extended fire routing delay of up to 10 minutes in operating modes where the feature is available. The default extended fire routing delay is 3 minutes. KFP-CE4 Series Installation Manual...

  • Page 41: Adding Expansion Boards

    “Expansion board configuration” on page 46. Adding a fire network board For information on how to add a fire network board to the system and how to configure it, see “Fire network and repeaters configuration” on page 48. KFP-CE4 Series Installation Manual...

  • Page 42: Advanced Configuration

    ON/OFF Sounder re-sound ON/OFF Fire routing delay 00 to 10 minutes Extended fire routing delay 00 to 10 minutes Add an expansion board 00 to 04 modules Fire network identifier 00 to 32 Software version Read-only KFP-CE4 Series Installation Manual...
  • Page 43 0 to 4444 User level 3 basic password 0 to 4444 User level 3 advanced password 0 to 4444 Control panel PCB serial number Read only Auxiliary 24 V reset ON/OFF Restore previous configuration Restore factory configuration KFP-CE4 Series Installation Manual...

  • Page 44: Sounder Operation During A Zone Test

    Values Exit without saving Exit and save [1] The CleanMe feature is not available for Kilsen devices. Sounder operation during a zone test Use this menu to configure the sounder operation during a zone test. The default setting for all operating modes is ON.

  • Page 45: Zone Configuration

    The Zone fault/test/disable LED flashes fast to indicate that the corresponding zone configuration menu is active. 3. Select a value using the value selection buttons (2 and 4). 4. Press Enter. 5. Save your changes. The available settings for this feature are shown below. KFP-CE4 Series Installation Manual...

  • Page 46: Zone Delay

    Active end-of-line with CleanMe [1][2] Intrinsically-safe zone [1][3] [1] Option not available if EN 54-13 supervision is enabled. [2] The CleanMe feature is not available for Kilsen devices. [3] By default, even zones are configured as manual and odd zones are set as automatic.

  • Page 47: Zone Type

    The red Zone LED flashes fast to indicate that the corresponding zone configuration menu is active. 3. Select a value using the value selection buttons (2 and 4). 4. Press Enter. 5. Save your changes. The available settings for this feature are shown below. KFP-CE4 Series Installation Manual...

  • Page 48: Input Configuration

    Input activation (transition) commands reset. Delays off Input activation (transition) deactivates delays (equivalent to night mode). Input deactivation (transition) activates delays (equivalent to day mode). Extended fire routing delay Input active configures extended fire routing delay. KFP-CE4 Series Installation Manual...

  • Page 49: Changing User Level Passwords

    1. Set the display for the desired user level password, and then press Enter. 2. Set the display as shown below, and then press Enter. 3. Select a value using the value selection buttons (2 and 4). 4. Press Enter. KFP-CE4 Series Installation Manual...

  • Page 50: Auxiliary 24 V Reset

    Resetting the control panel does not reset the AUX 24V output. Software, configuration, and serial number information Use the corresponding menu option (shown below) to display software, configuration, and serial number information. These details may be required for troubleshooting and technical support. KFP-CE4 Series Installation Manual...
  • Page 51 2. Select a value (control panel, expansion board or fire network board) using the value selection buttons (2 and 4). 3. Press Enter. 4. The software version is displayed in three consecutive segments, as shown below. KFP-CE4 Series Installation Manual...

  • Page 52: Expansion Board Configuration

    The label for a given module is defined by its position (left to right) in the control panel cabinet, The first expansion board installed is module A, the second B, etc. See your expansion board installation sheet for installation instructions. KFP-CE4 Series Installation Manual...
  • Page 53 ON LED on the expansion board flashes fast to indicate that the module function configuration menu is active. 2. Select a value from 01 to 94 using the value selection buttons (2 and 4). 3. Press Enter. 4. Save your changes. KFP-CE4 Series Installation Manual...

  • Page 54: Fire Network And Repeaters Configuration

    To display information for only that panel, press the Enter key for 3 seconds to provide a temporary, 30-second display of the local status indications. Basic configuration options The following table shows the options for creating basic fire network (firenet) configurations. KFP-CE4 Series Installation Manual...
  • Page 55 If you select 5, panel IDs 1 to 5 will have to be present so as not to have a network fault indication. Use advanced settings if you need to configure a network with other node IDs and you need specific control and repeater settings. KFP-CE4 Series Installation Manual...

  • Page 56: Advanced Configuration Options

    • The control panel will control its outputs (no addressable system in the network). Advanced configuration options The following table shows the options (available to an advanced configuration user) for creating an advanced fire network configuration. KFP-CE4 Series Installation Manual...
  • Page 57 (nM), and a set of panels to be repeated, called a firenet repeater map (rM). If the configuration is changed by modifying nM or rM, the value displayed for firenet number of nodes (nn) is Cu, indicating a custom network configuration. KFP-CE4 Series Installation Manual...
  • Page 58 1 has fire routing on delay and control panel 2 fire routing on, the indication of a third panel repeater will show fire routing on). All indications received that are not available in the repeater panel for display will be ignored. KFP-CE4 Series Installation Manual...
  • Page 59 • Create systems where alarm indications have to be local to the panel (nP should be inactive) By default, process remote zone alarms (nP) is active (ON). KFP-CE4 Series Installation Manual...

  • Page 60: Commissioning

    All zones have the correct end-of-line termination, as described in “Terminating zones” on page 13 • All manual call points have the correct resistance for alarm identification, as described in “Connecting manual call points” on page 14 KFP-CE4 Series Installation Manual...

  • Page 61: Commissioning The Control Panel

    To power up the control panel from the batteries, press the battery start button on the control panel PCB (marked as BAT. START, see Figure 19 on page 56). Keep the button pressed for approximately 5 seconds. KFP-CE4 Series Installation Manual...

  • Page 62: Functional Tests

    Less than 30 seconds Fire routing fault Less than 30 seconds Expansion board fault Less than 100 seconds Network fault Less than 100 seconds Earth fault Less than 100 seconds Battery charger fault Less than 100 seconds KFP-CE4 Series Installation Manual...
  • Page 63 Less than 3 minutes Mains fault Less than 3 minutes Out of service fault Less than 100 seconds Fuse/protection fault Less than 3 minutes System fault Less than 100 seconds Battery high resistance fault Less than 4 hours KFP-CE4 Series Installation Manual...
  • Page 64 Chapter 3: Configuration and commissioning KFP-CE4 Series Installation Manual...

  • Page 65: Maintenance

    Chapter 4 Maintenance Summary This chapter includes information on fire alarm and evacuation system maintenance and battery maintenance. Content System maintenance 60 Quarterly maintenance 60 Annual maintenance 60 Cleaning the control panel 60 Battery maintenance 60 KFP-CE4 Series Installation Manual...

  • Page 66: System Maintenance

    The control panel requires two 12V, 7.2 or 12 Ah rechargeable sealed lead-acid batteries. Compatible batteries for this product are: • BS127N (7.2 Ah) • BS130N (12 Ah) • Fiamm FG20721/2 (7.2 Ah) • Fiamm FG21201/2 (12 Ah) • Yuasa NP7-12 (7.0 Ah) • Yuasa NP12-12 (12 Ah) KFP-CE4 Series Installation Manual...
  • Page 67 1. Disconnect and remove the existing batteries from the cabinet. 2. Install and connect the replacement batteries using the bridge provided. Observe correct polarity. 3. Dispose of the batteries as required by local or regional regulations. KFP-CE4 Series Installation Manual...
  • Page 68 Chapter 4: Maintenance KFP-CE4 Series Installation Manual...

  • Page 69: Technical Specifications

    This chapter includes technical specifications for your fire alarm and evacuation control panel. Content Zone specifications 64 Input and output specifications 65 Power supply specifications 66 Mechanical and environmental specifications 67 Fire network specifications 68 Cabinet drawings and dimensions 69 KFP-CE4 Series Installation Manual...

  • Page 70: Zone Specifications

    Zone impedance < 55 Ω Open circuit reference range Zone impedance > 8 kΩ Zone device current consumption ≤ 2.6 mA [1] Mixed zones are not allowed on installations requiring EN 54-13 compliance or intrinsically- safe zones KFP-CE4 Series Installation Manual...

  • Page 71: Input And Output Specifications

    1 mA max. (for activation with short-circuit contact) Voltage between terminals 28 V max. (for deactivation with open circuit) [1] Fire routing acknowledgement inputs [2] For EN 54-13 compliance, the active impedance should be from 220 Ω to 3.9 kΩ KFP-CE4 Series Installation Manual...

  • Page 72: Power Supply Specifications

    110 VAC / 60 Hz or 240 VAC / 50 Hz Rated current 110 VAC 3.15 A 240 VAC 1.5 A Voltage tolerance +10% / −15% Mains fuse 110 VAC T 3.15A 250V 240 VAC T 2A 250V KFP-CE4 Series Installation Manual...

  • Page 73: Mechanical And Environmental Specifications

    26X Ø 20 mm at rear of cabinet IP rating IP30 Table 36: Environmental specifications Operating temperature −5 to +40ºC Storage temperature −20 to +70ºC Relative humidity 10 to 95% noncondensing Type class conditions 3K5 of IEC 60721-3-3 KFP-CE4 Series Installation Manual...

  • Page 74: Fire Network Specifications

    For detailed cabinet drawings and dimensions, see “Cabinet drawings and dimensions” on page 69. Fire network specifications Table 37: Fire network specifications Maximum distance between control 1.2 km panels Maximum capacity 32 nodes and 64 zones Communication protocol Proprietary peer-to-peer protocol based on RS-485 KFP-CE4 Series Installation Manual...

  • Page 75: Cabinet Drawings And Dimensions

    Chapter 5: Technical specifications Cabinet drawings and dimensions Figure 20: Cabinet with cover KFP-CE4 Series Installation Manual...
  • Page 76 Chapter 5: Technical specifications Figure 21: Cabinet without cover KFP-CE4 Series Installation Manual...

  • Page 77: Appendix A Configuration Presets

    This appendix includes detailed information on operating mode and expansion board configuration presets. Content Operating mode presets 72 NEN 2575 4E presets 72 NEN 2575 2E presets 73 NEN 2575 1E presets 73 Additional configuration characteristics 74 Expansion board presets 74 KFP-CE4 Series Installation Manual...

  • Page 78: Operating Mode Presets

    [1] In this mode, EN 54-13 requires an additional 2010-1SB expansion board, configured with four separate outputs. An alarm in zone 3 will activate output 1 and output 2. An alarm in zone 4 will activate output 3 and output 4. KFP-CE4 Series Installation Manual...

  • Page 79: Nen 2575 2E Presets

    Fire routing (activated by a manual fire alarm device) NEN 2575 1E presets Table 42: Configuration presets Preset Control panel One evacuation area EOL type Passive Output type Class B Evacuation sounder outputs Fire routing outputs Zone type Odd: Automatic Even: Manual KFP-CE4 Series Installation Manual...

  • Page 80: Expansion Board Presets

    An additional (optional) supervised expansion board may be installed for individual automatic and manual fire routing outputs. Expansion board presets The following tables include the display settings for relay and supervised output expansion board configuration presets. KFP-CE4 Series Installation Manual...
  • Page 81 7 or 8 1 and 2 3 and 4 5 and 6 7 and 8 1, 2, 3, or 4 5, 6, 7, or 8 1 and 2 3 and 4 1 or 2 3 or 4 KFP-CE4 Series Installation Manual...
  • Page 82 3 to 4 Alarm Fault [1] Buzzer on Reset on Buzzer on Reset on Buzzer on Reset on 34 [2] Fire Routing (Auto) Fire routing (Manual) 35 [2] Fire routing Fault warning output [3] Fault [1] KFP-CE4 Series Installation Manual...
  • Page 83 Display Events Output Delay Sounders evacuation output 1 Sounders evacuation output 2 Sounders evacuation output 1 Sounders evacuation output 2 Sounders evacuation output 1 Sounders evacuation output 2 Sounders evacuation output 3 Sounders evacuation output 4 KFP-CE4 Series Installation Manual...
  • Page 84 3 and 4 Alarm 1 and 2 Fault 3 and 4 Fault [1] 1 and 2 3 and 4 Alarm 1 and 2 Fault [1] 3 and 4 Buzzer on 1 and 2 Reset on 3 and 4 KFP-CE4 Series Installation Manual...
  • Page 85 Sounders evacuation output 2 3 and 4 Sounders evacuation output Sounders evacuation output 2 Sounders evacuation output 3 Sounders evacuation output 4 [1] Each evacuation area is linked to a respective indication, button and functionality in the user interface KFP-CE4 Series Installation Manual...
  • Page 86 Appendix A: Configuration presets KFP-CE4 Series Installation Manual...

  • Page 87: Appendix B Product Compliance

    Appendix B Product compliance Summary This appendix contains regulatory information that applies to your control panel. Content European standards 82 KFP-CE4 Series Installation Manual...

  • Page 88: European Standards

    European standards European standards for fire control and indicating equipment The KFP-CE4 Series fire and evacuation control panels have been designed in accordance with European EN 54-2, EN 54-4, and NEN 2575 standards. In addition, all models comply with the following EN 54-2 optional requirements.
  • Page 89 UTC Fire & Security B.V., Kelvinstraat 7,6003 DH Weert, The Netherlands Year of first CE marking Declaration of Performance 360-3100-1699 number Product identification See model number on product identification label Intended use See DoP point 3 Essential characteristics See DoP point 9 KFP-CE4 Series Installation Manual...
