KFP-A Series Installation
Manual
P/N 00-3252-501-0003-04 • ISS 04MAY15

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KFP-AE1(-S) and is the answer not in the manual?

Questions and answers

Related Manuals for Kilsen KFP-AE1(-S)

Summary of Contents for Kilsen KFP-AE1(-S)

  • Page 1 KFP-A Series Installation Manual P/N 00-3252-501-0003-04 • ISS 04MAY15...
  • Page 2 Copyright © 2015 UTC Fire & Security. All rights reserved. Trademarks and KFP-A Series is a trademark of UTC Fire & Security. patents Other trade names used in this document may be trademarks or registered trademarks of the manufacturers or vendors of the respective products.

  • Page 3: Table Of Contents

    Content Important information ii Chapter 1 Introduction 1 Product range 2 Product compatibility 3 Product overview 4 Chapter 2 Installation 15 Electrical safety 16 Cabinet and PCB layout 17 Cabinet installation 19 Connections 24 Chapter 3 Configuration and commissioning 35 Introduction 36 Maintenance level operation and configuration 39 Installer level operation and configuration 53...

  • Page 4: Important Information

    Important information Introduction This is the installation manual for the KFP-A Series fire alarm, repeater, and evacuation control panels. Read these instructions and all related documentation entirely before installing or operating this product. Firmware compatibility Information in this document covers control panels with firmware version 3.5 or later.
  • Page 5 Caution: Caution messages advise you of possible equipment damage. They tell you which actions to take or to avoid in order to prevent the damage. Note: Note messages advise you of the possible loss of time or effort. They describe how to avoid the loss. Notes are also used to point out important information that you should read.
  • Page 6 KFP-A Series Installation Manual...

  • Page 7: Introduction

    Chapter 1 Introduction Summary This chapter provides an introduction to your control panel, the main controls, and the indicators. Content Product range 2 Product compatibility 3 Product overview 4 The user interface 4 Front panel controls and indicators 6 LCD controls and indicators 10 Acoustic indicators 12 Conditions 12 KFP-A Series Installation Manual...

  • Page 8: Product Range

    Chapter 1: Introduction Product range The series includes the fire alarm, repeater, and evacuation panels shown below. Table 1: Fire alarm, repeater, and evacuation panels Model Description KFP-AE1(-S) [1] One-loop addressable fire and evacuation alarm control panel KFP-AE2(-S) Two-loop addressable fire and evacuation alarm control panel KFP-AER(-S) Addressable fire and evacuation alarm repeater panel KFP-AF1(-S)

  • Page 9: Product Compatibility

    Chapter 1: Introduction Product compatibility Products compatible with these control panels are listed in the supplied compatibility list. Only those products specified in the compatibility list are guaranteed to be compatible with these control panels. For further details contact your local supplier. KFP-A Series Installation Manual...

  • Page 10: Product Overview

    Chapter 1: Introduction Product overview This topic provides an introduction to the control panel user interface, LCD, operator controls, and indicators. For a detailed overview of front panel controls and indicators, see “Front panel controls and indicators” on page 6. The user interface Figure 1: Fire panel user interface (with fire routing and fire protection controls) 1.
  • Page 11 Chapter 1: Introduction Figure 2: Evacuation panel user interface 1. Supply LED 14. Panel Silence button and LED 2. General Test LED 15. Sounder Start/Stop Button and LED 3. General Disable LED 16. System Fault LED 4. General Fault LED 17.

  • Page 12: Front Panel Controls And Indicators

    Chapter 1: Introduction Configuration options Depending on your configuration, the labels for some interface buttons may change. See Table 2 below. Table 2: Configured changes to interface buttons and LEDs Item EN 54 NEN 2575 All Output Groups Start/Stop All Evacuation Start/Stop Programmable output group start/stop Evacuation area sounders start/stop [1] Sounder Start/Stop...
  • Page 13 Chapter 1: Introduction Control/LED LED colour Description Fire Routing Delay Yellow Enables or disables a previously configured fire routing button and LED delay. Cancels a delay as it counts down and activates fire routing. A steady LED indicates that a delay is configured and enabled.
  • Page 14 Chapter 1: Introduction Control/LED LED colour Description Programmable Yellow Starts or stops the the output group associated with the start/stop button and programmable button. A steady yellow LED indicates that the output group associated with the button is active. A flashing yellow LED indicates that a delay is counting (the output group is activated when the configured delay elapses or when the delay is cancelled).
  • Page 15 Chapter 1: Introduction Evacuation panel controls and indicators The table below includes information for the additional controls and indicators for evacuation panels. Note: If the evacuation panel is operating in NEN 2575 mode, only sounder output groups can be associated with the programmable start/stop buttons. Table 4: Evacuation panel controls and indicators Control/LED LED colour...

  • Page 16: Lcd Controls And Indicators

    Chapter 1: Introduction There are two fire routing output groups, the first is in activated status and the second is in acknowledged status. The fire routing indication displays the acknowledged status but not the activation status (the acknowledgement status takes priority). For more information on output groups, see “Output groups”...
  • Page 17 Chapter 1: Introduction Icons displayed on the LCD Icons displayed on the LCD are shown below. Table 5: LCD icons and descriptions Icon Description This icon indicates that the primary sensitivity mode Day mode (network) setting for control panels in the fire network is day mode.

  • Page 18: Acoustic Indicators

    Chapter 1: Introduction Indication of remote and local events on the LCD The local control panel ID is always displayed on the LCD (see Figure 3 on page 10). If your control panel forms part of a fire network, the event notification includes the panel ID reporting the event as follows: •...
  • Page 19 Chapter 1: Introduction Condition type Description Loop device not configured A loop device is detected that is not configured Maximum conventional zones The number of conventional zones in a fire network exceeded in a network exceeds the maximum allowed Maximum loops exceeded in a The number of loops in a fire network exceeds the network maximum allowed...
  • Page 20 Chapter 1: Introduction KFP-A Series Installation Manual...

  • Page 21: Installation

    Chapter 2 Installation Summary This chapter provides detailed installation and connection information for your control panel. Caution: This product must be installed and maintained by qualified personnel adhering to the CEN/TS 54-14 standard (or the corresponding national standard) and any other applicable regulations. Content Electrical safety 16 Cabinet and PCB layout 17...

  • Page 22: Electrical Safety

    Chapter 2: Installation Electrical safety WARNING: Electrocution hazard. To avoid personal injury or death from electrocution, remove all sources of power and allow stored energy to discharge before installing or removing equipment. Caution: Equipment damage hazard. This product is sensitive to electrostatic discharge (ESD).

  • Page 23: Cabinet And Pcb Layout

    Chapter 2: Installation Cabinet and PCB layout Figure 4: Large cabinet and PCB layout (two-loop control panel) 1. 24V connector 9. COM0 and COM1 serial ports 2. COM2 serial port 10. COM0 and COM1 interface connectors 3. Loop and fire system connectors 11.
  • Page 24 Chapter 2: Installation Figure 5: Small cabinet and PCB layout (two-loop control panel) 1. Loop and fire system connectors 8. COM0 and COM1 interface connectors 2. Spirit level 9. Battery connector 3. Earth studs 10. Power supply connector 4. Ethernet connector 11.

  • Page 25: Cabinet Installation

    Chapter 2: Installation Cabinet installation Where to install the control panel Install the control panel in a location that is free from construction dust and debris, and immune to extreme temperature ranges and humidity. See Chapter 5 “Technical specifications” on page 113 for more information on the operating temperature and relative humidity specifications.

  • Page 26: Adding The Menu Inserts

    Chapter 2: Installation To fix the cabinet to the wall: 1. Hold the cabinet to the wall at the required installation height. 2. Ensure that the cabinet is level using the built-in spirit level and mark drill points on the wall. 3.

  • Page 27: Connecting The User Interface Cable

    Chapter 2: Installation The inserts are numbered 1, 2, 3, and 4, and are inserted at the location indicated (with the printed area facing the front of the control panel). For evacuation panels, remember to add descriptions for any output groups assigned to the programmable buttons to insert 3.

  • Page 28: Connecting The Internal Printer And Loading Paper

    Chapter 2: Installation Connecting the internal printer and loading paper This topic shows you how to connect the internal printer and load the printer with paper. See “Printer configuration” on page 69 for printer configuration options. The internal printer is only available on selected models. Connecting the internal printer Connect the internal printer as shown below.
  • Page 29 Chapter 2: Installation Loading paper Load the paper for the internal printer as shown below. Figure 11: Loading the paper for the internal printer KFP-A Series Installation Manual...

  • Page 30: Connections

    Chapter 2: Installation Connections Recommended cables Recommended cables for optimal system performance are shown in the table below. Table 9: Recommended cables Cable Cable requirements Maximum cable length Mains cable 3 × 1.5 mm Loop cable Twisted-pair (52 Ω and 500 nF max.) [1] 2 km with KAL51 cable [2] 12 to 26 AWG (0.13 to 3.31 mm²) Fire network cable...

  • Page 31: Overview Of Fire System Connections

    Chapter 2: Installation To determine noise immunity, check the communications error rate and the stability of analogue values for installed devices. Securing cables Use 20 mm cable glands to ensure clean and secure connections. All cables should be fed through the cable guides in the cabinet housing to eliminate movement.

  • Page 32: Connecting Loops

    Chapter 2: Installation Figure 13: Overview of EN 54-13 fire system connections with a single Class A loop 1. 2010-FS-EOL end-of-line device 2. Fault indicating equipment Connecting loops Loop guidelines For best results, follow these guidelines when connecting loops: • Install at least one isolator per loop (we recommend one for every 32 devices).
  • Page 33 Chapter 2: Installation • Ensure that the loop cable complies with the cable specifications outlined in “Recommended cables” on page 24. • If using shielded loop cable, ensure that the shield is continuous (connected through to each loop device). To prevent earth loops caused by electromagnetic interference, only one cable shield should be connected to earth, as shown in Figure 12 on page 25.

  • Page 34: Connecting Loop Devices

    Chapter 2: Installation Connecting loop devices Each loop can support up to 250 devices, as shown below. Table 10: Maximum number of loop devices Device Maximum per loop Address range Detectors 1 to 125 I/O modules, manual call points 128 to 252 For detailed loop device installation information, see your device installation sheet.

  • Page 35: Connecting Outputs

    Chapter 2: Installation Connecting outputs Control panel outputs are shown in the table below. Table 12: Control panel outputs Output Description Supervision 24V AUX Used to supply power to auxiliary equipment. The Short circuit, voltage output can be configured as resettable and to shut level down when there is no mains power.
  • Page 36 Chapter 2: Installation End-of-line components for outputs are included in the accessory kit provided with your control panel. Note: Output termination differs for typical and EN 54-13 installation types. Take care to install the correct termination for your installation. Output polarity All outputs are polarity sensitive.

  • Page 37: Connecting The Mains Power Supply

    Chapter 2: Installation Connecting the mains power supply Caution: Connect the mains power supply before connecting the batteries. The control panel can be operated at 110 VAC 50/60 Hz or 240 VAC 50/60 Hz (+10%/−15%). Mains power should be sourced directly from a separate circuit breaker in the building electrical supply distribution board.

  • Page 38: Connecting The Batteries

    Chapter 2: Installation Figure 16: Selecting 115 or 230 VAC operation Connecting the batteries The control panel requires two 12 V, rechargeable, sealed lead-acid batteries with 7.2, 12, or 18 Ah capacity (see “Battery maintenance” on page 111). Batteries are located inside the control panel cabinet and must be installed in series.
  • Page 39 Chapter 2: Installation Two wiring options are possible: • Ring configuration • Bus configuration Ring configuration Ring network configuration is recommended as it provides for redundancy in the transmission path. For ring configuration (Class A), use both ports to connect all network boards or control panels to form a ring, as shown below.

  • Page 40: Connecting An External Printer Or Ascii Terminal

    Chapter 2: Installation Connecting an external printer or ASCII terminal To print control panel events in real time, connect an external EPSON LX300 printer or ASCII terminal to COM0 or COM1. Note: This option requires the 2010-2-232-KIT (not supplied). The kit contains a 3 m cable and the 2010-2-232-IB isolation board required for external RS-232 device connections.

  • Page 41: Configuration And Commissioning

    Chapter 3 Configuration and commissioning Summary This chapter provides configuration and commissioning information for your control panel and fire detection system. Content Introduction 36 System update 69 User levels 36 Printer configuration 69 Configuration overview 37 DACT configuration 70 Maintenance level operation and Panel activation key 74 configuration 39 Auto date and time 75...

  • Page 42: Introduction

    Introduction User levels Access to some of the features of this product is restricted by the user level assigned to a user account. Public The public level is the default user level. This level allows basic operational tasks, such as responding to a fire alarm or fault warning at the control panel.

  • Page 43: Configuration Overview

    Chapter 3: Configuration and commissioning Table 16: User level timeouts User level Automatic timeout period Operator 2 minutes Maintenance 10 minutes Installer 10 minutes To enter a password-protected level: 1. Press F4 (Main menu). The username and password prompt appears on the LCD.
  • Page 44 Chapter 3: Configuration and commissioning When configuring your fire system using the Configuration Utility: 1. Configure the communications settings if you plan to download configurations using an Ethernet connection. This is not required if you plan to save configurations to a PC connected to the control panel USB connector. 2.

  • Page 45: Maintenance Level Operation And Configuration

    Chapter 3: Configuration and commissioning Configuration options The options listed below are available when making configuration changes to the control panel. The control panel configuration (and configuration revision) is only updated when configuration changes are applied by pressing F3 (Apply). The configuration revision change and timestamp are recorded in the Revision report and can be accessed at operator, maintenance, and installer levels.

  • Page 46: The Field Setup Menu

    Chapter 3: Configuration and commissioning The Main menu The maintenance level Main menu is shown below. Figure 20: Maintenance level Main menu The Field setup menu Use the Field setup menu to set timeout values for zone test and disablement operations.

  • Page 47: The Panel Setup Menu

    Chapter 3: Configuration and commissioning The Panel setup menu Use the Panel setup menu to set the date and time, to synchronize the date and time in a fire network, and to set day or night mode sensitivity settings. Date and time Select Date and time to change the control panel date and time.
  • Page 48 Chapter 3: Configuration and commissioning To set a day/night schedule: 1. Select Panel setup from the Main menu. 2. Select Day/Night mode, and then select Day/Night schedule. 3. Select the day you want to configure. 4. Enter the time that day mode starts using the hh:mm format (for example, 08:00).
  • Page 49 Chapter 3: Configuration and commissioning Additional day/night mode settings Select Day/Night setup to configure additional settings such as manual override of day/night mode schedule and holiday calendar mode changes or delay behaviour in night mode. The configuration options available are shown in the table below. Table 19: Additional day/night mode options Option Description...

  • Page 50: The Communications Menu

    Chapter 3: Configuration and commissioning Control panels in the same network can have different day/night mode sensitivity settings. If the command filter is configured accordingly, a control panel can operate a local day/night mode setting independently from other control panels in the same network.

  • Page 51: The Disable/Enable Menu

    Chapter 3: Configuration and commissioning To remove a USB device: 1. Select Panel setup from the Main menu, and then select Communications. 2. Select Remove USB device. A message displays on the LCD confirming the operation. 3. Press F2 (Exit) to exit the menu. 4.

  • Page 52: The Test Menu

    Chapter 3: Configuration and commissioning 5. Press F2 (Exit) to exit the menu. Repeat to enable a disabled feature or device. Notes • Active outputs cannot be disabled. • Devices or zones in alarm are not disabled until the control panel is manually reset.
  • Page 53 Chapter 3: Configuration and commissioning Repeat the above steps to end the zone test. When an alarm is activated in a zone in test: • The zone test is confirmed on the LCD while the alarm is active • If a zone board is installed and the corresponding zone is included on the zone board, then the zone alarm LED is flashing or steady (depending on the source of the alarm) •...
  • Page 54 Chapter 3: Configuration and commissioning Testing output group activation To test output group activation: 1. Select Test from the Main menu, and then select Output group. 2. Select the ID of the output group you want to test, and then select YES (to activate the output group) or NO (to deactivate the output group).

  • Page 55: The Reports Menu

    Chapter 3: Configuration and commissioning Testing batteries Select Battery test to test the batteries. For more information on battery status messages, see “Battery maintenance” on page 111. To test the batteries: 1. Select Test from the Main menu. 2. Select Battery test. A message confirming battery status displays on the LCD.
  • Page 56 Chapter 3: Configuration and commissioning Report Description Zone status [1] Displays the current status information for zones. Zone mapping [1] Displays which devices are assigned to each zone in your fire system. Device status [1] Displays the current status information for control panel devices. Device information available in real time includes: instant, mean, maximum, and minimum analog values, alarm level, communication error rate, and the loop input contamination level.
  • Page 57 Chapter 3: Configuration and commissioning 4. Select Reports from the Main menu. 5. Select Event log, and then select Backup. 6. Follow the on-screen instructions. 7. Press F2 (Exit) to exit. 8. Remove the flash drive as described in “Removing a USB device” on page Note: If your flash drive is not recognized by the control panel, reformat it as FAT32 from a PC and try again.

  • Page 58: The Password Setup Menu

    Chapter 3: Configuration and commissioning The Password setup menu Use the Password setup menu to change your maintenance password and to manage operator user accounts. Changing your password Select Change password to change your password. You cannot change passwords for other maintenance users. To change your password: 1.

  • Page 59: Installer Level Operation And Configuration

    Chapter 3: Configuration and commissioning 4. Press F4 (Enter), and then press F1 (Back). 5. Press F1 (Save), F3 (Apply), F4 (Discard), or F2 (Exit). Remember to apply saved settings from the Main menu. To create a new operator user account: 1.

  • Page 60: Id Configuration

    Chapter 3: Configuration and commissioning Table 21: Control panel configuration Option Description ID configuration Configures the control panel Firenet ID (for the fire network) and description. The description is displayed on the LCD when the control panel is in standby. Date and time Configures the control panel date and time, and to synchronize the date and time in a fire network.

  • Page 61: Regional Options

    Chapter 3: Configuration and commissioning To change the ID or description: 1. Select Panel setup from the Main menu. 2. Select ID configuration. 3. Enter the ID, description, and installation name. 4. Press F4 (Enter), and then press F1 (Back). 5.

  • Page 62: Firenet Configuration

    Chapter 3: Configuration and commissioning Firenet configuration Select Firenet to configure the control panel fire network and repeater settings shown in the table below. Table 23: Firenet configuration options Option Description Firenet map Displays all detected control panels, to add control panels to the fire network, or to remove control panels from the network.
  • Page 63 Chapter 3: Configuration and commissioning Firenet opmode Available network operation modes are shown below. Table 24: Firenet operation modes Mode Description Stand-alone Configures a stand-alone control panel. This is the default setting for fire alarm control panels. Networked Configures a networked control panel. See description below. Repeater Configures a networked repeater.
  • Page 64 Chapter 3: Configuration and commissioning 3. Select the control panel from the list, and then select YES (to repeat the control panel) or NO (to stop repeating the control panel). 4. Press F4 (Enter), and then press F1 (Back). 5. Press F1 (Save), F3 (Apply), F4 (Discard), or F2 (Exit). Remember to apply saved settings from the Main menu.
  • Page 65 Chapter 3: Configuration and commissioning Command filter Select Command filter to configure the types of commands sent to the fire network in control panels with the corresponding global controls configured. The commands that can be configured are shown in the table below. Table 25: Command filter configuration options Command Description...

  • Page 66: Communications Configuration

    Chapter 3: Configuration and commissioning 4. Press F4 (Enter), and then press F1 (Back). 5. Press F1 (Save), F3 (Apply), F4 (Discard), or F2 (Exit). Remember to apply saved settings from the Main menu. Communications configuration TCP/IP Select TCP/IP to configure TCP/IP settings. The default TCP/IP settings are shown in the table below.
  • Page 67 Chapter 3: Configuration and commissioning Email accounts Select Email accounts to manage the email accounts for remote monitoring and to configure the notifications sent to each email address. For correct operation, TCP/IP and email server details must be configured (see “Email server” below). Note: Maintenance users are also able to modify settings for this service.

  • Page 68: Other Settings

    Chapter 3: Configuration and commissioning Note: Polling settings for the SNTP server must be enabled separately – see “Auto date and time” on page 75. To configure the SNTP server: 1. Select Panel setup from the Main menu, and then select Communications. 2.
  • Page 69 Chapter 3: Configuration and commissioning To change the configuration: 1. Select Panel setup from the Main menu. 2. Select Other settings, and then select Fault notification. 3. For each notification type, select YES to enable notifications or NO to disable notifications.
  • Page 70 Chapter 3: Configuration and commissioning To change the configuration: 1. Select Panel setup from the Main menu. 2. Select Other settings, and then select Device LEDs. 3. Select YES or NO. 4. Press F4 (Enter), and then press F1 (Back). 5.

  • Page 71: Load/Save Configuration

    Chapter 3: Configuration and commissioning 5. Press F4 (Enter), and then press F1 (Back). 6. Press F1 (Save), F3 (Apply), F4 (Discard), or F2 (Exit). Remember to apply saved settings from the Main menu. VdS Settings Select VdS settings to configure the alarm display format (standard format or VdS 2540 format).
  • Page 72 Chapter 3: Configuration and commissioning Note: If your flash drive is not recognized by the control panel, reformat it as FAT32 from a PC and try again. If the problem persists, try a different flash drive. To load a configuration: 1.

  • Page 73: Expansion Board Configuration

    Chapter 3: Configuration and commissioning 4. Press F1 (Save), F3 (Apply), F4 (Discard), or F2 (Exit). Remember to apply saved settings from the Main menu. Expansion board configuration Select Expansion boards to add an installed expansion board to the control panel configuration.
  • Page 74 Chapter 3: Configuration and commissioning To prepare custom screen images: 1. Convert the graphics file to BIN format using a graphics file converter or the Configuration Utility. 2. Save the converted file as logo1.bin at the path “\_Panels\xxx\bitmap\” on a USB flash drive.

  • Page 75: System Update

    Chapter 3: Configuration and commissioning System update Caution: Updating the control panel firmware may delete the current installation configuration data. Always back up your configuration data before updating the control panel firmware. Select System update to load control panel firmware updates provided by the manufacturer.

  • Page 76: Dact Configuration

    Chapter 3: Configuration and commissioning Table 30: Printer configuration options Option Description Used Configures the printer status (used or not used) RportMd [1] Configures the external printer for report printing NWEvent [2] Configures the printing of system events for all control panels in the network Alarm [2] Configures the printing of alarm events...
  • Page 77 Chapter 3: Configuration and commissioning General configuration Select General configuration to configure the DACT status (used or not used) and event reporting settings. Configuration options are shown in the table below. Table 32: General DACT configuration options Option Description Default value Used Configures the DACT status (used or not used) Not used...
  • Page 78 Chapter 3: Configuration and commissioning 5. Press F4 (Enter), and then press F1 (Back). 6. Press F1 (Save), F3 (Apply), F4 (Discard), or F2 (Exit). Remember to apply saved settings from the Main menu. CMS configuration Select CMS configuration to configure central monitoring station settings. Up to six monitoring stations can be added.
  • Page 79 Chapter 3: Configuration and commissioning 4. Configure all required settings. 5. Press F4 (Enter), and then press F1 (Back). 6. Press F1 (Save), F3 (Apply), F4 (Discard), or F2 (Exit). Remember to apply saved settings from the Main menu. PSTN configuration Select PSTN configuration to configure public switched telephone network settings.

  • Page 80: Panel Activation Key

    Chapter 3: Configuration and commissioning Option Description Default value Description Configures the description Password Configures the network password Period Configures the heartbeat period (in seconds) 60 s Fails Configures the minimum number of consecutive heartbeat failures required to indicate a communication error with the central monitoring station To change the configuration:...

  • Page 81: Auto Date And Time

    Chapter 3: Configuration and commissioning Auto date and time Select Auto date and time to configure automated date and time settings. Configuration options are shown in the table below. Table 38: Auto date and time options Option Description Default value SNTP [1] Enables polling a configured SNTP server Disabled...

  • Page 82: Field Configuration

    Chapter 3: Configuration and commissioning To change the configuration: 1. Select Panel setup from the Main menu. 2. Select BMS Config. 3. Configure all required settings. Initpan is only required when using Modbus in Zonepoint mode. Zonepoint mode implements Modbus services for 32 networked fire panels with consecutive addresses (for example, 1 to 32 if the address of the first panel is defined as 001 in InitPan).

  • Page 83: Loop Device Configuration

    Chapter 3: Configuration and commissioning 3. Press F4 (Enter), and then press F1 (Back). 4. Press F1 (Save), F3 (Apply), F4 (Discard), or F2 (Exit). Remember to apply saved settings from the Main menu. Autosetup will: • Assign all initiating devices (including zone modules) to zone 1 •...

  • Page 84: Zone Configuration

    Chapter 3: Configuration and commissioning Address device Select Address device to assign an address to a loop device. Note: You must install, address, and then remove devices one-by-one. To allocate a device address: 1. Select Field setup from the Main menu, and then select Address device. 2.
  • Page 85 Chapter 3: Configuration and commissioning Remote zones The control panel also considers an additional zone called remote zone (REMT) which spans all the zones in the system outside the control panel zones range. This virtual zone can be configured like any other zone in the system and it is important to define output group activation requirements when the panel receives remote alarms.
  • Page 86 Chapter 3: Configuration and commissioning To change the configuration: 1. Select Field setup from the Main menu, and then Zone configuration. 2. Select General config. 3. Make the required configuration changes. 4. Press F4 (Enter), and then press F1 (Back). 5.
  • Page 87 Chapter 3: Configuration and commissioning Configuring the number of global zones helps to avoid zone overlap in installations where zone numbering is configured to avoid sharing some zones across the network. By configuring this setting, the same number of shared zones is maintained after upgrading the control panel firmware to version 3.5 (or later) and unexpected cross-panel activations are avoided.
  • Page 88 Chapter 3: Configuration and commissioning To change the zone configuration settings: 1. Select Field setup from the Main menu, and then Zone configuration. 2. Select Zone configuration, and then select the corresponding zone from the list of zones displayed. 3. Make the required configuration changes. 4.
  • Page 89 Chapter 3: Configuration and commissioning Option Description sD(B) The alarm is confirmed by the same detector but with longer inhibition time than the sD(A) confirmation option. Alarms generated by a manual call point are not confirmed and activate a control panel alarm immediately. aDaZ (type B EN 54-2) The alarm is confirmed by the same detector or by a different detector in the same local area.
  • Page 90 Chapter 3: Configuration and commissioning Table 47: Zone operating modes Operating mode Description Mixed The zone may contain a mix of automatic and manual alarm devices. Manual [1] The zone only allows manual call points (or inputs configured for MCP operation mode). Auto [1] The zone only allows detectors (or inputs configured for detector operation mode).

  • Page 91: Panel I/O Configuration

    Chapter 3: Configuration and commissioning Panel I/O configuration Panel input configuration Configurable options for control panel inputs are shown below. Table 48: Configurable options for control panel inputs Option Description Type Configures the input operation mode Control Enables or disables an input Input types are shown in Table 49 below.
  • Page 92 Chapter 3: Configuration and commissioning Type Description Manual call point alarm. This input type can be used for connecting to aspirating detector Fire2 outputs. PREAL Prealarm (unlatched). This input type can be used for connecting to aspirating detector Action outputs. Activation resets the panel remotely.
  • Page 93 Chapter 3: Configuration and commissioning Type Description KEYSW Keyswitch access. Activation enables the Operator access level for the control panel (no password required). Only one input per control panel can be configured to use this mode. To enable or disable a control panel input: 1.
  • Page 94 Chapter 3: Configuration and commissioning 6. Select the output Class (Class A or Class B). The default setting is Class B. 7. Press F4 (Enter), and then press F1 (Back). 8. Press F1 (Save), F3 (Apply), F4 (Discard), or F2 (Exit). Remember to apply saved settings from the Main menu.

  • Page 95: Output Groups

    Chapter 3: Configuration and commissioning Output groups Select Output groups to configure the control panel output groups. Control panel outputs must be assigned to output groups for activation. An output group is a collection of outputs of the same type that activate and deactivate at the same time (they are commanded simultaneously).
  • Page 96 Chapter 3: Configuration and commissioning Configurable options for output groups are shown below. Table 53: Configurable options for output groups Option Description Group_n Configures the output group number Type Configures the output group type Control Enables or disables the output group [BLANK] Output description To configure a default output group:...
  • Page 97 Chapter 3: Configuration and commissioning 8. Press F1 (Save), F3 (Apply), F4 (Discard), or F2 (Exit). Remember to apply saved settings from the Main menu. Output group activation Output groups can be activated by any of the following: • Zone activation with delays •...
  • Page 98 Chapter 3: Configuration and commissioning To configure delayed output group activation: 1. Select Field setup from the Main menu, and then select Output groups. 2. Select Confirmations, and then select the output group to configure. A list of the available output groups that allow alarm confirmation configuration is displayed.

  • Page 99: Activation Configuration

    Chapter 3: Configuration and commissioning By default, all programmable buttons are set to sounder group 1. Note: Evacuation panels operating in NEN 2575 mode can only assign sounder output groups to the programmable buttons. Evacuation panels operating in other modes can assign any of the available output group types to the buttons. Remember to create the output groups that you need before configuring the programmable buttons.
  • Page 100 Chapter 3: Configuration and commissioning Option Description Per zone Configures the activation of output groups for each individual zone in alarm. For each zone, a different output group activation delay (including no activation) can be assigned for each configured output group. General delays Configures sounder silence disable time, maximum acknowledge time or extended fire routing delays, and warning time for second stage sounders...
  • Page 101 Chapter 3: Configuration and commissioning 6. If required, enter a warning delay (in minutes and seconds) for sounder output groups in applications using warning tones (second stage sounders). A warning delay is only observed if the corresponding warning time is also configured (see “Warning time”...
  • Page 102 Chapter 3: Configuration and commissioning To configure per zone delay options: 1. Select Field setup from the Main menu, and then select Activation configuration. 2. Select Per zone. 3. Select the zone, and then select the output group whose delay you want to configure for the selected zone.
  • Page 103 Chapter 3: Configuration and commissioning General delays Select General delays to configure region-specific investigation times or advanced delay options. Configurable options for general delays are shown in the table below. Table 57: Configurable options for general delays Field Description InvMode Investigation mode.
  • Page 104 Chapter 3: Configuration and commissioning 5. If warning tones are required (for second stage sounders), select Warning time, and then enter the time value (in seconds). Check the WrnT_4E check box to change from the warning tone to evacuation tone only if a manual call point alarm is detected. If a delay is required before the warning tone begins, configure the warning delay for the corresponding output group.
  • Page 105 Chapter 3: Configuration and commissioning Setting Description FREXT_ACK Extended fire routing delay (typically for Scandinavia). The configured fire routing delay starts to count down when the control panel reports a detector alarm. If the alarm is acknowledged during the configured fire routing delay (by pressing the Panel Silence button), then the extended fire routing delay becomes the active delay.
  • Page 106 Chapter 3: Configuration and commissioning Note: The table above indicates the minimum and maximum values when Inv_Ack is not enabled (any configured investigation time starts when the alarm is detected). If Inv_Ack is enabled, the maximum investigation time is 600 seconds less the configured investigation time, and the minimum is 0.

  • Page 107: Loop Class Configuration

    Chapter 3: Configuration and commissioning Figure 25: Detector alarm with standard delay (no second stage) Evacuation tone Time Delay Sounders silence disable time Note: This feature is not available for control panels operating in NBN S21-100 or EN 54 Evacuation mode (any configured sounder silence disable times are ignored).

  • Page 108: Tests

    Chapter 3: Configuration and commissioning 4. Press F4 (Enter), and then press F1 (Back). 5. Press F1 (Save), F3 (Apply), F4 (Discard), or F2 (Exit). Remember to apply saved settings from the Main menu. Tests Diagnostics Select Diagnostics for tools to support troubleshooting during installation. The diagnostics tests available are shown in the table below.

  • Page 109: Password Setup

    Chapter 3: Configuration and commissioning Table 62: Individual device diagnostics tests Polling mode [1] Description STA_AB, STA_A, STA_B Configures status polling mode AV1_AB, AV1_A, AV1_B Configures analogue value 1 polling mode AV2_AB, AV2_A, AV2_B Configures analogue value 2 polling mode GRP_AB, GRP_A, GRP_B Configures group status polling mode [1] AB, A, and B indicate the loop channel used.
  • Page 110 Chapter 3: Configuration and commissioning Managing users Select Manage users to edit, delete, or create operator, maintenance, or installer user accounts. The control panel allows for a maximum of 20 user accounts (all user levels combined). To edit a user account: 1.
  • Page 111 Chapter 3: Configuration and commissioning Secure access Select Secure access to configure the control panel to allow secure or nonsecure access. The default setting is for secure access (all username and password information must be entered at each login). • If nonsecure access is selected, the control panel automatically prefills the last username and password combination entered for login •...

  • Page 112: Commissioning

    Chapter 3: Configuration and commissioning Commissioning After the control panel and corresponding devices are installed and configured, the system must be commissioned. Check the following: • That the fire system is designed in accordance with all required regulations and standards •...
  • Page 113 Chapter 3: Configuration and commissioning KFP-A Series Installation Manual...

  • Page 115: Maintenance

    Chapter 4 Maintenance Summary This chapter includes information on fire alarm system and battery maintenance. Content Fire alarm system maintenance 110 Battery maintenance 111 KFP-A Series Installation Manual...

  • Page 116: Fire Alarm System Maintenance

    Chapter 4: Maintenance Fire alarm system maintenance To ensure correct functioning of your control panel and fire alarm system, and compliance with all European regulations, the following maintenance checks should be followed. Caution: Ensure that fire routing (where configured) has been disabled or that the fire brigade has been notified of any planned fire alarm tests.

  • Page 117: Battery Maintenance

    Chapter 4: Maintenance Battery maintenance The control panel requires two 12 V, rechargeable, sealed lead-acid batteries with 7.2, 12, or 18 Ah capacity. Compatible batteries for this product are shown in Table 64 below. Batteries are located inside the control panel cabinet and must be installed in series.
  • Page 118 Chapter 4: Maintenance Replacing batteries Batteries must be replaced periodically as recommended by the manufacturer. The useful life of the battery is approximately 4 years. Avoid the total discharge of the batteries. Always use the recommended replacement batteries. To replace the batteries: 1.

  • Page 119: Technical Specifications

    Chapter 5 Technical specifications Summary This chapter provides technical specifications for your control panel. Content Loop specifications 114 Power supply specifications 114 Battery and battery charger specifications 115 LCD specifications 115 Communication port specifications 116 Fire network specifications 116 Input and output specifications 116 Internal printer specifications 118 Mechanical and environmental specifications 119 KFP-A Series Installation Manual...

  • Page 120: Loop Specifications

    Chapter 5: Technical specifications Loop specifications Loop configuration Class A or Class B Loop protocol Kilsen Isolators At least one isolator per loop (we recommend one isolator for every 32 devices) Number of loop devices 250 max. (125 detectors and 125 I/O modules/manual call points) Electrical characteristics –...

  • Page 121: Battery And Battery Charger Specifications

    Chapter 5: Technical specifications Typical expansion board current consumption Network board 50 mA at 24 VDC DACT board 45 mA at 24 VDC DACT board (with GPRS board) 100 mA at 24 VDC Loop board [1] 120 mA at 24 VDC Peripherals boards [1] 2010-2-PIB 26 mA at 24 VDC...

  • Page 122: Communication Port Specifications

    Chapter 5: Technical specifications Communication port specifications Ethernet Ethernet 10/100BaseT port (10 Mbps) Note: For increased security, we recommend against using Ethernet for remote connection to the control panel via the Internet. TCP/IP IPv4 USB host port USB 2.0, type A connector USB device port USB 2.0, type B connector Fire network specifications...
  • Page 123 Chapter 5: Technical specifications Configurable outputs [1] Supervision (Class B outputs) Reverse polarity, end-of-line resistor 15 kΩ, 1/4 W Supervision (Class A outputs) Reverse polarity, end-of-line resistor 4.7 kΩ, 1/4 W Maximum output current [2] 750 mA per output at 25 ºC 600 mA per output at 40ºC (small cabinet) 675 mA per output at 40ºC (large cabinet) Maximum electrical...

  • Page 124: Internal Printer Specifications

    Chapter 5: Technical specifications 24V auxiliary output Maximum output current [1] 500 mA at 25ºC 385 mA at 40ºC Configurable options Resettable, not deactivated during reset (default), inactive when mains off, not deactivated when running on batteries (default) [1] Up to a maximum system consumption of 4 A (Imax b). Calculating the maximum output current as a function of the cable length The maximum cable length allowed for an output needs to take into consideration the current required to be supplied by the output.

  • Page 125: Mechanical And Environmental Specifications

    Chapter 5: Technical specifications Mechanical and environmental specifications Mechanical Cabinet dimensions (L x W x H) Small cabinet 410 x 159 x 327 mm Large cabinet 450 x 173 x 550 mm Weight (without batteries) Small cabinet 5.2 kg Large cabinet 7.4 kg Number of cable knockouts Small cabinet...
  • Page 126 Chapter 5: Technical specifications Figure 27: Large cabinet dimensions and views KFP-A Series Installation Manual...
  • Page 127 Chapter 5: Technical specifications Figure 28: Small cabinet dimensions and views KFP-A Series Installation Manual...
  • Page 128 Chapter 5: Technical specifications KFP-A Series Installation Manual...

  • Page 129: Appendix A Default Configurations

    Appendix A Default configurations The following table shows the settings for the default configuration of your panel. Table 66: Default configurations Description Default setting Power supply operation 230 VAC Control panel ID Day/night mode Full day to day mode Control panel network operation Stand-alone Network global commands Network mask...
  • Page 130 Appendix A: Default configurations Description Default setting OUT1, OUT2, etc. (Class B) Sounder output (all zones) Fire output Activated by fire alarms in all zones Fault output Follows the General Fault LED and is activated when there is no fault (fail-to-safe) IN1 and IN2 Technical alarm latched (T_AL) Delays...

  • Page 131: Appendix Bpstn Country Codes

    Appendix B PSTN country codes Use the PSTN country codes in the table below when configuring DACT board settings. Table 67: PSTN country codes Country Code Country Code Country Code Algeria Guam Philippines Argentina Hong Kong Poland Armenia Hungary Polynesia Australia Iceland Portugal...
  • Page 132 Appendix B: PSTN country codes Country Code Country Code Country Code Dubai Martinique Ukraine Equador Mexico Egypt Moldova Uruguay El Salvador Morocco Estonia Netherlands Uzbekistan Finland New Zealand Venezuela France Nigeria Yemen Georgia Norway Zambia Germany Oman Serbia Ghana Pakistan Greece Paraguay Guadeloupe...

  • Page 133: Appendix C Menu Maps

    Appendix C Menu maps Fire alarm control panels Maintenance user level Menu level 1 Menu level 2 Menu level 3 Field Setup Zone configuration Test/Disable t_out Panel setup Date and time Day/Night mode Day/Night schedule Holiday calendar Day/Night setup Communications Email accounts Remove USB device Disable/Enable...
  • Page 134 Appendix C: Menu maps Menu level 1 Menu level 2 Menu level 3 Battery test Reports Event log View all Clear Attention required Revision Firmware revision Configuration revision Serial numbers Contact details Zone status Zone mapping Device status Panel I/O status Output groups status Rules status Firenet status...
  • Page 135 Appendix C: Menu maps Menu level 1 Menu level 2 Menu level 3 Zone configuration Area configuration Test/Disable t_out Panel I/O configuration Panel inputs Panel outputs Output groups Group configuration Confirmations Programmable controls Activation configuration Sounders Fire routing Fire protection Program Per zone General delays...
  • Page 136 Appendix C: Menu maps Menu level 1 Menu level 2 Menu level 3 School bells Device LEDs Pulse activation VdS settings Configuration Restore configuration Load configuration Save configuration Default configuration Expansion boards Load auxiliary files Splash screens Languages Language fonts System update Printer configuration Int.
  • Page 137 Appendix C: Menu maps Menu level 1 Menu level 2 Menu level 3 Remote test Diagnostics Individual device Outputs current Power supply Loop values UI test Indicator test Keyboard test LCD test Battery test Reports Event log View all Clear Attention required Revision Firmware revision...
  • Page 138 Appendix C: Menu maps Menu level 1 Menu level 2 Menu level 3 Password setup Change password Manage users Secure access Fire alarm repeater panels Maintenance user level Menu level 1 Menu level 2 Menu level 3 Panel setup Date and time Day/Night mode Day/Night schedule Holiday calendar...
  • Page 139 Appendix C: Menu maps Menu level 1 Menu level 2 Menu level 3 Event log Attention required Panel I/O status Firenet status PAK list Alarm counter Password setup Change password Manage users Installer user level Menu level 1 Menu level 2 Menu level 3 Field setup Zone configuration...
  • Page 140 Appendix C: Menu maps Menu level 1 Menu level 2 Menu level 3 Buzzer Configuration Restore configuration Load configuration Save configuration Default configuration Expansion boards Load auxiliary files Splash screens Languages Language fonts System update Printer configuration Int. printer configuration Ext.
  • Page 141 Appendix C: Menu maps Menu level 1 Menu level 2 Menu level 3 Revision Firmware revision Configuration revision Serial numbers Contact details Panel I/O status Firenet status Rules status Save/Print reports Current events Event log Attention required Panel I/O status Firenet status PAK list Alarm counter...
  • Page 142 Appendix C: Menu maps KFP-A Series Installation Manual...

  • Page 143: Appendix D Regulatory Information

    Appendix D Regulatory information European standards for fire control and indicating equipment These control panels have been designed in accordance with European EN 54-2, and EN 54-4 standards. In addition, they comply with the following EN 54-2 optional requirements. Table 68: EN 54-2 optional requirements Option Description Output to fire alarm devices [1]...
  • Page 144 Appendix D: Regulatory information European regulations for construction products This section includes both regulatory information and a summary on the declared performance according to the Construction Products Regulation 305/2011. For detailed information refer to the product Declaration of Performance (DoP). Table 69: Regulatory information Certification Certification body...

  • Page 145: Index

    Index custom screens, adding, 67 acoustic indications, 12 alarm display format (VdS Settings), 65 area configuration, 84 DACT autosetup, 76 CMS configuration, 72 Ethernet configuration, 71 GPRS configuration, 73 PSTN configuration, 73 battery date and time compatible batteries, 111 change, 41 fault indications, 111 SNTP options, 75 maintenance, 111...
  • Page 146 Index internal printer configuration, 69 email connection, 22 accounts, 61 loading paper, 23 manage accounts, 44 server configuration, 61 enable device, 45 language files, 68 device type, 45 input, 87 controls, 10 output, 88 icons, 11 zone, 81 LED indications, 6 event filter, 58 loop class configuration, 101 event log...
  • Page 147 Index school bells, 64 service mode, 49 SNTP auto date and time, 75 server configuration, 61 sounders re-sound, 63 system update, 69 TCP/IP settings, 60 USB device, removing, 44 user account create new, 53, 104 delete, 52, 104 edit, 52, 104 user levels, 36 ZI initial zone LED, 80 zone...

This manual is also suitable for:

Kfp-ae2(-s)Kfp-aer(-s)Kfp-af1(-s)Kfp-af1-fb2(-s)Kfp-af2(-s)Kfp-af1-scfb(-s) ... Show all

Table of Contents
