BATTERY CHARGING

I Battery caution

CAUTION NEVER short the terminals.
NEVER mix old and new batteries.
NEVER incinerate used battery cells. Internal battery gas may
cause explosion.
Make sure all battery cells are the same brand, type and capacity.
AVOID over charging— The BP-202 can be charged when the AC
adapter or the DC power cable with a DC power supply is con-
nected. To prevent over charging, the IC-4088S has charging timer
that automatically disconnecting the charging line electronically
after 15 hours from charging. However, the charging timer will reset
and start charging again when disconnect then re-connecting the
AC adapter or DC power cable more than 1 min. interval.
Recommended temperature range for charging: +10˚C to +40˚C
NEVER connect an AC adapter or DC power cable with an external
DC power supply that outputs lower than 5.7 V DC and more than
6.3 V DC voltage when charging the installed BP-202.
The optional BP-202
batteries and can be charged approx. 300 times. Charge the battery
pack before first operating the transceiver or when the battery pack
becomes exhausted.
If the battery pack seems to have no capacity even after being fully
charged, completely discharge it by leaving the power ON all day.
Then, fully charge the battery pack again.
If the battery pack still does not retain a charge (or very little), a new
battery pack must be purchased.
D D Operating period
Depending on the installed battery, the operating period of the
transceiver varies. Refer to p. 24 for operating period details.
includes rechargeable Ni-Cd
BATTERY PACK
