Attach the Matrox input cable
2
Attach one end of the cable provided with
your Matrox product to the connector on
your computer. Attach the other end of the
cable to the connector labeled
your Matrox product.
If your graphics hardware has an HD-15
connector, use the Matrox HD-15 to HD-15
cable to connect your Matrox product.
If your graphics hardware has a DVI
connector, use the Matrox DVI to HD-15
cable to connect your Matrox product.
Connect the first monitor
3
Use your monitor cable to connect your
preferred monitor to the connector labeled
(
CENTER
product.
Connect the second monitor
4
Use your monitor cable to connect your
second monitor to the connector labeled
(
LEFT
product.
on
INPUT
) on your Matrox
) on your Matrox
Matrox input cable
(HD-15 to HD-15)
Monitor cable
(HD-15)
Monitor cable
(HD-15)
