Spare Part List - Whirlpool WA 2340/WS-D Service Manual

20.04.2000 / Page 4
Doc. No: 4812 712 11609

Spare part list

Model WA 2340/WS-D
Service No. 855491303001
Version 855491303001
Pos. No. 12NC Code Description
001 0 4812 440 18996 Cabinet
003 0 4812 464 48097 Traverse Rear top degre
011 0 4812 500 18068 Foot variable
021 0 4812 440 19329 Front
021 1 4812 440 19331 Flap Filter
024 0 4812 440 18997 Panel, rear
025 0 4812 440 18989 Holder Control
030 0 4812 310 38181 Table top
040 0 4812 417 18787 Hinge
040 1 4812 417 28009 Insert
053 0 4812 459 38011 Plinth
061 1 4812 466 88456 Counter weight Ring
080 0 4812 466 48056 Shock absorber 800-1000
084 0 4812 466 58001 Silent block
086 0 4812 401 18409 Holder Shock Absorber
086 2 4812 401 18412 Stopper
110 0 4812 498 18139 Handle,door
130 0 4812 417 28046 Lock Door
130 1 4812 417 28045 Pin Door Lock
131 0 4812 417 28047 Plate Door lock
131 1 4812 417 28048 Plate Doorlock Lower
141 0 4812 450 68218 Door glass
143 0 4812 440 18988 Glassdoor frame
144 0 4812 459 28043 Frame,door glas
144 1 4812 498 18137 Knob Door safety
144 2 4812 492 58023 Spring Door Safety
144 3 4812 290 68153 Holder,adjust. Door Safety
190 0 4812 466 68507 Door bellow
190 1 4812 492 18015 Strap Fix. Bellow
190 2 4812 492 98011 Strap
200 0 4812 418 18181 Tub
201 0 4812 464 48002 Bottom tub
210 0 4812 520 18011 Crosspiece Agg. 1
220 0 4812 418 18198 Drum 800-1000
223 0 4819 515 28244 Drum lifter
228 0 4812 418 18094 Crosspiece,drum
271 0 4812 358 18007 V-ribbed belt 1260 J5
272 0 4812 528 58004 Pulley
272 1 4812 532 28006 Bushing conical
292 0 4812 530 58003 Gasket tub bottom
301 0 4812 452 19215 Control panel 5+1
303 0 4812 498 18138 Handle, drawer
322 0 4812 452 19227 Insert panel WA 2340/WS-D
324 0 4812 440 18992 Lid Rearcover
331 0 4812 413 48222 Knob
331 1 4812 413 18191 Adapter f. Knob
332 0 4812 410 28544 Push button Start
332 1 4812 410 28543 Push button Options
341 2 4812 450 38003 Indicator Spin-Speed
342 0 4812 413 18192 Program indic.
342 1 4812 278 88006 Slide Indicator
342 2 4812 413 18193 Cam Indicator
342 3 4812 413 18194 Spring
351 1 4812 134 48191 Lamp Door
354 1 4812 134 48179 Pilot lamp Timer
WA 2340/WS-D
8554 913 03001
Pos. No. 12NC Code
401 0
401 1
421 0
430 0
451 0
490 0
490 1
504 0
511 0
571 0
581 0
620 1
621 0
621 2
630 0
653 0
701 0
701 0
701 0
701 1
702 0
707 0
707 1
708 1
711 0
712 0
713 0
717 0
717 1
717 2
717 3
717 5
718 0
718 1
750 0
753 1
754 0
760 0
760 1
781 0
781 1
783 0
783 3
786 0
786 1
786 2
787 0
794 2
794 5
901 0
901 2
901 3
902 1
903 0
903 5
Whirlpool Europe
S E R V I C E
Customer Service
Description
4812 361 58118 Motor BK-MASK 3 MCA45BKD1
4812 362 48004 Brush,carbon motor CESET
Interf.filter 1,00 µ F
4812 121 18142
4812 360 18362 Pump
4812 259 28669 Heating element
4819 321 18136 Cable,mains 2m
4812 321 28367 Strain relief
4812 282 18452 Timer
4812 413 48223 Selector Temp./Spin
4812 281 28368 Valve,magnet Single
4812 271 28357 Pressostat 1 Level
4812 276 18238 Switch Options
4812 276 18239 Switch Start/Start-Delay
4812 276 18241 Switch Speed Reduction
4812 280 58019 Door lock
4812 134 48189 Guide,light On/Off
4812 530 28081 Hose, inlet 3/8Z cpl. 5m
4812 530 28082 Hose, inlet 3/8Z cpl. 3m
4819 530 28928 Hose, inlet
4822 480 50159 Sieve inlet
4812 530 28811 Hose Valve/D. Container
4812 526 48031 Nozzle Distribution
4812 526 48028 Nozzle
4812 530 48141 Bend
4812 418 88025 Dispenser BK,WH-3CH
4812 418 78036 Drawer Detergent
4812 418 88019 Flap Detergent Container
4812 418 78925 Bowden cable
4812 321 38013 Lever , Nozzle
4812 321 38012 Holder,adjust.
4812 278 88007 Slide
4812 310 18381 Cam
4812 526 48027 Siphon 3 - Chamber
4812 418 88018 Accessory
4812 530 48139 Boiler
4812 418 68125 Chamber,air
4812 530 28838 Drainhose
4812 480 58075 Filter Set Pump
4812 418 68138 Gasket Sieve / Rough
4812 530 28815 Hose,draining
4812 530 28818 Hose
4812 530 28816 Hose Pressostat
4812 530 18001 Connection Part
4812 530 28812 Hose Draining
4812 462 79641 Stopper
4812 462 79642 Threaded cap
4812 530 28819 Hose with hole
4812 530 58005 O-Ring
4812 530 58015 Gasket
4812 401 18054 Clamp,hose
4812 401 18401 Strap
4812 401 18414 Clamp,hose
4812 255 18204 Holder Hose outlet
4812 290 88043 Bracket Door lock
4812 290 88048 Cable clamp
