Technical Data - Whirlpool WA 2340/WS-D Service Manual

20.04.2000 / Page 2
Doc. No: 4812 712 11609

Technical data

Dimensions
Height
Width
Depth
Weight
Without packing
Main connection
Voltage
Frequency
Power consumption
Fuse rating
Drum
Volume
Wash spin
Ramp spin
Speed spinning max.
Capacity of dry laundry
Cotton/coloured laundry
Cotton rapid
Easy care
Easy care rapid
Delicate
Wool
Pressostat
Quantity of water washing
cotton/coloured laundry
Easy care
Delicate
Wool
Overflow
Quantity of water rinse
cotton/coloured laundry
Easy care
Delicate
Wool
Overflow
WA 2340/WS-D
8554 913 03001
85.0 cm
59.5 cm
60.0 cm
73 kg
230 V
50 Hz
2.3 kW
10 A
48 l
54 rpm
110 rpm
1000 rpm
800 rpm
600 rpm
5 kg
3 kg
2.5 kg
1.5 kg
1.5 kg
1 kg
~ 6,5 l
~ 6,5 l
~ 12,5 l
~ 12,5 l
~ 30 l
~ 9 l
~ 9 l
~ 14 l
~ 14 l
~ 30 l
Whirlpool Europe
Customer Service
Nominal current
Contacts:
11 - 12
11 - 14
11 - 16
Contactsystem:
11-12-14
11 - 16
Door lock
Lock time
Unlock time
Nominal voltage
Nominal current:
contact 4 - 5
contact 11 - 14
Heating element
Kind of heating Tubular heating element with
NTC-sensor
Nominal voltage
Nominal power
Heat conductor
resistance
Resistance NTC:
0˚C
30˚C
40˚C
50˚C
60˚C
70˚C
95˚C
Inlet valve
Water temperature max.
Rated flow < 1 bar
Pressure range
Nominal voltage
Frequency
Starting voltage < 6 bar
6-10 bar
Nominal current
Nominal power
Nominal resistor (20˚C)
S E R V I C E
4 (4) A
16 (4) A
1 (1) A
jump contacts
slow action contacts
3'' - 6'' (20 ˚C)
60'' - 90''
230 V
1 mA
16 (4) A
230 V
2050 W
Ω
24.1
35.9 kΩ
9.8 kΩ
6.6 kΩ
4.6 kΩ
3.2 kΩ
2.3 kΩ
1.1 kΩ
60 ˚C
8 l/min
0.5 - 10 bar
220 - 240 V
50 Hz
160 V
170 V
35 mA
6 VA
4.06 kΩ
