AC/DC CURRENT

NOTE: The meter defaults to AC measurement. Press the "SEL"
button to toggle between AC and DC modes. The AC or DC icon
10
on the LCD indicates which mode is selected.
1. Attach test leads to the appropriate jacks and rotate function
selector switch
• For AC/DC currents >400mA and <10A: Insert RED test lead into
10A jack
3
function selector switch
Red lead Black lead
• For mA AC/DC currents <400mA: Insert RED test lead into
V jack
5
function selector switch
• For µA DC currents <400µA: Insert RED test lead into
V jack
5
function selector switch
OPERATING INSTRUCTIONS
to the appropriate setting as follows:
2
, and BLACK test lead into COM jack
, and BLACK test lead into COM jack
Black lead Red lead
, and BLACK test lead into COM jack
Black lead Red lead
to the 10A AC/DC
2
to the mA AC/DC
2
to the µA AC/DC
2
, and rotate
4
setting.
, and rotate
4
setting.
, and rotate
4
setting.
11
