Page 1: Operating Instructions
Only use appliance after first reading these instructions! Operating instructions Heat pump dryer Spirit topLine 810... - Page 2 Symbols Please read the instructions. Warnings are marked with a warning triangle! The text gives information how a dangerous situation can be avoided! Signal words indicate the severity of the danger, if not avoided. Warning means that possible personal injuries, and potentially life-threatening injuries may occur Important...
-
Page 3: Dear Customer
Please read these instructions carefully to enable you to use all the possibilities and advantages of your new dryer. Please note in particular the safety informations and the enclosed guarantee and customer services booklet. We hope you will be very happy with your new Schulthess dryer. Your Schulthess Maschinen AG... -
Page 4: Table Of Contents
Contents Safety and safety measures ..........6 Disposal . - Page 5 Cleaning and Maintenance ..........31 Cleaning the machine .
-
Page 6: Safety And Safety Measures
Safety and safety measures The enclosed documents contain Do not let children carry out clean- important information on the instal- ing and user maintenance without lation, use and safety of the dryer. supervision. Keep the documents safe for other Safety while handling users or subsequent owners. - Page 7 Always unplug the machine from If a puddle forms on the floor near ► the power source before carrying the appliance (hose tear, leak, etc.), out maintenance work. wipe it dry and eliminate the cause (see Problems). If the machine is not needed for ►...
- Page 8 Safety for children Safety during installation Warning Warning Risk of injury! Risk of injury! Children are in danger of injury or If the machine is to be placed on a life-threatening situations, when plinth, it must be mounted accord- playing with the machine. ing to the installation instructions, ►...
-
Page 9: Observe When Drying
Observe when drying The fluff filters must be inserted when operating this machine. ► Never operate the machine with damaged fluff filters. Keep the area surrounding the ► dryer free of dust and fluff. The fluff filters must be cleaned ►... -
Page 10: Disposal
Disposal Packaging from your new machine Disposal of your old machine All packaging materials used are environ- Please do not keep your old machine and mentally friendly and reusable. All card is under no circumstances dispose of it in made of 80 – 100 % recycled paper. Wood is your normal waste. -
Page 11: Environmentally Compatible Drying
Environmentally Preparing the laundry compatible drying Do up all zips, hooks and eyes. ► Button up duvet covers and pillowcases. ► Tie together loose belts, apron strings Notice etc. Dripping wet laundry: waste of energy! Drying the laundry Remove as much water as possible from ►... -
Page 12: Machine Description
Machine description Control and display area Loading door Maintenance hatch Cooling grid... - Page 13 Cotton Extra dry Cotton Cabinet dry Easy Care Cabinet dry On / Off Back in the menu Scroll backwards Scroll forwards Start programme Open the door Standard programme Language (temporary) / Settings Page number programme menu...
-
Page 14: Drying
Drying Preparing the appliance Selecting programme and starting Check whether the fluff filters are ► in place (see Drying / Clean fluff filters). Cotton Extra dry Switch on the power supply. ► Cotton Cabinet dry Turn on machine On / Off Easy care Slightly dry Press button ►... -
Page 15: Changing The Programme
Changing the programme Adding laundry Make sure that there is no foreign body in ► the drum (coins, nails, paper clips, etc.). Changing the programme before Distribute the laundry evenly in the ► programme start drum. Return to the main menu with the ►... -
Page 16: Interrupting The Programme
Cancelling the programme Skipping to the next programme step Cotton Cotton 1:08 h max. 9.0 kg Cabinet dry max. 8.0 Cabinet dry Drying Cancel Forward Cancel Forwa Forward Press the light bar next to ► until the desired programme step is Cancel Press the light bar next to until... -
Page 17: Adding More Laundry
0:01 h max. 8.0 kg Adding more laundry Remove the laundry otton 0:32 h Programme end, crease protection Open the door Press button ► max. 8.0 kg binet dry (is not lit!). ntle Drying ancel Forward Press button Open the door ►... -
Page 18: Cleaning The Fluff Filters
Cleaning the fluff filters When fabrics are used, the fibres are rubbed (laundry fluff), which are released when the fabrics are dried, collecting in the fluff filters in the door opening. Clogged fluff filters may affect the drying process. Rub your hand over the inside of the ►... - Page 19 Descaling the fluff filters Cleaning the filter daily If the coat cannot be brushed away, a commercial descaler spray must be used to dissolve it. Spray the descaler on the entire filter ► surface and leave it to take effect. In case of stubborn coats place one layer of kitchen roll onto the filter surface and spray descaler on it to ensure the...
-
Page 20: Cleaning The Air Filter
Cleaning the air filter Use your hand or a damp cloth to extract ► all the fluff and dust that has collected on the inside of the ventilation flap. Clean the air filter once a week Remove the filter ► Open the cooling grid. -
Page 21: Switching Off The Machine
Rub your hand over the air filter to ► remove the fluff. Replace the air filter and close the ► cooling grid. Switching off the machine On / Off Press button until ► the display turns off. Unplug the machine, when not used ►... -
Page 22: Programme Survey
Programme survey Always check the care symbols on the fabrics h:min = Duration / rpm = Spin speeds / kWh = Power consumption (Approximate values) Most efficient programme for cotton textiles according to regulation (EU) no. 932 / 2012 The following standard programme (marked with ) is suitable for drying normally wet cotton textiles and is most efficient regarding the combined energy consumption. -
Page 23: Easy Care Laundry
h:min 8,0 kg Cotton Extra dry Towelling bathrobes and bed linen 1:37 1200 (no underwear or socks) 1:28 1400 ► For particularly thick or multilayered fabrics 1:20 1600 Easy care laundry Non-iron synthetic and mixed fibres and cotton with non-iron trim, e.g. viscose, cupro, modal, polyester h:min Easy care Iron damp... -
Page 24: Time Drying
Time drying Non-iron synthetic and mixed fibres and cotton with non-iron trim, e.g. viscose, cupro, modal, polyester h:min 8,0 kg Time drying For extra drying time for multi-layer textlies (e.g. sleeping – – – bags) or for drying single laundry items, such as for example terry towelling ►... -
Page 25: Programme Options
Programme options By also selecting one or more options, ► Notice a wash programme can be specifically tailored to the particular characteristics To increase the dryness level in gener- of the laundry. al (for all programmes), the function Dryness level increased Programme options are only activated must be ►... -
Page 26: Settings
Settings Your washing machine has default set- tings from the factory. The settings can Language be adapted to the users individual needs English Italia either when first used or later using the following functions. Français Españ The settings can only be changed if no Deutsch Rumants wash programme is running. -
Page 27: Menu Settings
Menu Settings Data Default settings ► * = Default settings – By pressing the on the light bar, you can change the month and day (keep finger pressed to scroll rapidly) Confirm entry by pressing the light bar ► Cotton Extra dry next to OK. -
Page 28: More Settings
More settings Brightness display 50 * ► The following settings are not available The background light intensity can be for all appliances. continuously adjusted from 20 to 100 % (hold bar for fast forward). Language Confirm entry with OK. Deutsch * ►... - Page 29 Child lock On * ► The machine is automatically switched Off * ► off, when the programme has ended ► or when there is no further action taken The child lock is to prevent accidental after turning the machine on. starting, changing or deletion of a Standby + programme by small children.
-
Page 30: Cash-Card / Prepaid Card
Cash-Card / Prepaid Card Selecting the programme Insufficient credit on card Select the desired programme (see If there is not enough credit on the user ► Drying / Selecting programme card to cover the programme price, the starting). following message will appear in the display. -
Page 31: Cleaning And Maintenance
Cleaning and Maintenance Caution Cleaning the fluff filters Drying / Cleaning the fluff Danger of electric shock! filters. Switch off the power supply to the ► machine before cleaning. Cleaning the filter holder Under no circumstances spray the ► machine with water. Do not use a steam cleaner. -
Page 32: Cleaning The Moisture Sensor
Cleaning the moisture sensor Self-cleaning After longer operation, small deposits (lime, fabric refiner) can form on the The dryer is equipped with an automatic front inner side of the drum on both self-cleaning function. sides of the longish moisture sensors. At the end of each programme and also With moisture controlled programmes, during the drying process, if necessary,... -
Page 33: Problems
Problems Warning Improper repairs can result in severe accidents, damages and operation malfunctions! Do not make any changes, manipulations or attempt repairs using tools such as screw- drivers, etc. E R RO R ME SSAG E S (is not lit!) and at the Child lock active Hold the bar in the upper right ►... - Page 34 Insert filter «C» Ensure the fluff filter is placed correctly behind the ► Displayed at start service flap. Press button ► Displayed while Ensure the fluff filter is placed correctly behind the ► programme is running service flap. Press the light bar next to Continue. ►...
- Page 35 M AC hI NE OPER AT IO N Machine does not Check whether the mains power is switched on (wall / plug). ► start when pressing Check whether all the fuses are intact or the safety switch ► the On / Off has tripped.
- Page 36 The fluff filters are blocked with fluff or scale deposits. Drying / Cleaning the fluff Clean the fluff filters (see ► filters). Reverse + Laundry gets tangled Use the programme option ► Drum lighting does The LED is defective. not work For safety reasons the LED must only be replaced by the customer service or a qualified specialist.
-
Page 37: Technical Specifications
Technical specifications Product data sheet for household washing dryer according to EC regulation no. 392 / 2012 Schulthess Model name / label Spirit topLine 810 Nominal capacity kg 8,0 Dryer type Heat pump dryer Energy efficiency class A +++ (highest efficiency) to D (lowest efficiency) -
Page 38: Customer Service
Customer service 24 h telephone service: Check whether you can correct the fault yourself before you call customer service Tel. 0844 888 222 (see chapter Problems). Fax 0844 888 223 If advice is required, costs may be incurred if a service technician is required, even Give customer services the error message during the guarantee period. - Page 40 Headquarters and Production Schulthess Maschinen AG Landstrasse 37, 8633 Wolfhausen ZH Tel. + 41 (0) 55 253 51 11 info@schulthess.ch www.schulthess.ch Austria Schulthess Maschinen GmbH A-1130 Wien, Hetzendorferstrasse 191 Tel. + 43 (0) 1 803 98 00 www.schulthess.at Brief instruction Follow the safety instructions in this manual! Turn on the power switch and open the water tap.
