Dryer WT14
Contents
1
Safety instructions ....................................................................................................... 2
2
Machine parameters ..................................................................................................... 3
3
Settings for the customer ............................................................................................ 5
4
Test programmes .......................................................................................................... 5
5
Operating data .............................................................................................................. 8
6
Error messages ............................................................................................................ 9
7
Replacement of control and power boards ............................................................... 11
8
Drying programmes W WT14 EFH W1 80 .................................................................. 13
9
Drying programmes WT14 EFH K 80 ......................................................................... 16
10
Drying programmes WT14 MFH W2 80 ..................................................................... 19
11
Drying programmes WT14 MFH K 80 ........................................................................ 22
12
Drying programmes WT14 MFH A 80 ........................................................................ 24
13
Overview of the model types and machine parameters (Settings ex factory) ........ 27
14
Documents overview .................................................................................................. 32
638 155 AL
Service instructions
Dryer WT14
page 1 / 34
Service instructions
11 / 2016
Advertisement
Table of Contents
Related Manuals for Schulthess WT14
Summary of Contents for Schulthess WT14
-
Page 1: Service Instructions
Operating data ......................8 Error messages ......................9 Replacement of control and power boards ............... 11 Drying programmes W WT14 EFH W1 80 ..............13 Drying programmes WT14 EFH K 80 ................. 16 Drying programmes WT14 MFH W2 80 ..............19 Drying programmes WT14 MFH K 80 ................ -
Page 2: Safety Instructions
Dryer WT14 Service instructions 1 Safety instructions In addition to the safety instructions provided in the installation instructions and in the operating instructions, the following safety instructions are to be followed: Repairs may only be carried out by trained and qualified specialists. -
Page 3: Machine Parameters
Dryer WT14 Service instructions 2 Machine parameters Setting of machine parameters To start theSettings menu, press the 11 button in the main menu. (MFH: first of all hold down button 11 for 2 secs until the Settings menu appears) By pressing down the arrow button 4 for a long time (5 seconds), you can access page 2 of the settings menu. - Page 4 Dryer WT14 Service instructions 2.2 UI-Table (User Interface) This setting allows the adjustment of the control system to the various models. IMPORTANT: If you change the UI table and save these changes, the machine is automatically reset to default settings.
-
Page 5: Settings For The Customer
Dryer WT14 Service instructions 2.9 Filter cleaning display No display 5 programmes After the set number of programmes have run, the message "Clean filter C" up to is displayed. The message disappears when the filter is removed. 25 programmes 2.10 Maintenance interval No instruction to maintain the machine will appear. - Page 6 Dryer WT14 Service instructions 4.1 High-voltage test (for production) For the high-voltage test, the drive motor is run for two minutes in the same direction. The fan is also operated and after 30 seconds, the condensate pump will also start up. All other consumers are switched off.
- Page 7 Dryer WT14 Service instructions Inspection of the drive. The drum will rotate clockwise for 10 seconds, then it will stop for 2 seconds, rotate counterclockwise for 10 seconds, stop for 2 seconds, etc. 4.6 Fan motor The drum motor will be actuated for 2 minutes. The process air fan also runs on the axle of the drum motor.
-
Page 8: Operating Data
Dryer WT14 Service instructions 5 Operating data Using this function, the operating data stored in the control PCB are displayed. 5.1 Calling up the operating data In the Settings menu, the Operating data menu can be called up on the second page. The operating data code (28-39-17) must be entered for access. -
Page 9: Error Messages
Dryer WT14 Service instructions 6 Error messages Two different types of error messages exist: Error messages in the form of a plain text display These errors can usually be corrected by the user. Error messages F These errors must be corrected by a service technician. - Page 10 Dryer WT14 Service instructions Display Error type Cause Reaction Error door lock Door did not open The door lock is overheated, Door release is disabled for after repeated defective or the control 30 sec. to cool down the coil. H-14...
-
Page 11: Replacement Of Control And Power Boards
Dryer WT14 Service instructions 7 Replacement of control and power boards 7.1 Replacing a control board When the control PCB starts up for the first time, the "high-voltage test" and the "drying programme" test programme are automatically executed. The test programmes can be terminated using "Cancel". -
Page 13: Drying Programmes W Wt14 Efh W1 80
Dryer WT14 Service instructions 8 Drying programmes W WT14 EFH W1 80 Progr. Spun Reduced Spun Normal Spun Max.temp. in max. Programme wash load the drum number 1200 rpm (55%) 1400 rpm (50%) 1600 rpm (44%) [kg] [min] [kWh] [min]... - Page 14 Dryer WT14 Service instructions [kg] [min] [kWh] [min] [°C] [min] [kWh] [°C] Easy care iron damp 33 * Express 30 * Easy care slightly dry 47 * Express 38 * Easy care cabinet dry 58 * Gentle plus 59 *...
- Page 15 Dryer WT14 Service instructions Progr. Spun Spun Not spun Max.temp. max. Programme wash load number 600 rpm (45%) 800 rpm (38%) in the drum [kg] [min] [kWh] [min] [°C] [min] [kWh] [°C] Reconditioning 10-90 timed drying cold ** Pollenclean **...
-
Page 16: Drying Programmes Wt14 Efh K 80
Dryer WT14 Service instructions 9 Drying programmes WT14 EFH K 80 Progr. Spun Reduced Spun Normal Spun max. Max.temp. in Programme wash load number 1200 rpm (55%) 1400 rpm (50%) 1600 rpm (44%) the drum [kg] [min] [kWh] [min] [kWh]... - Page 17 Dryer WT14 Service instructions Progr. Spun Spun Not spun Max.temp. max. Programme wash load number 600 rpm (45%) 800 rpm (38%) in the drum [kg] [min] [kWh] [min] [°C] [min] [kWh] [°C] Easy care iron damp 46 * Express 32 *...
- Page 18 Dryer WT14 Service instructions Progr. Spun Spun Not spun Max.temp. max. Programme wash load number 600 rpm (45%) 800 rpm (38%) in the drum [kg] [min] [kWh] [min] [°C] [min] [kWh] [°C] Reconditioning 10-90 timed drying cold ** The display shows the time for "Laundry spun normal”...
-
Page 19: Drying Programmes Wt14 Mfh W2 80
Dryer WT14 Service instructions 10 Drying programmes WT14 MFH W2 80 Progr. Spun Reduced Spun Normal Spun max. Max.temp. in Programme wash load number 1200 rpm (55%) 1400 rpm (50%) 1600 rpm (44%) the drum [kg] [min] [kWh] [min] [kWh]... - Page 20 Dryer WT14 Service instructions Progr. Spun Spun Not spun Max.temp. max. Programme wash load number 600 rpm (45%) 800 rpm (38%) in the drum [kg] [min] [kWh] [min] [kWh] [°C] Easy care iron damp Express Easy care slightly dry Express...
- Page 21 Dryer WT14 Service instructions Progr. Spun Spun Not spun Max.temp. max. Programme wash load number 600 rpm (45%) 800 rpm (38%) in the drum [kg] [min] [kWh] [min] [kWh] [°C] Easy care iron damp 10-90 Express Programmes without moisture measurement...
-
Page 22: Drying Programmes Wt14 Mfh K 80
Dryer WT14 Service instructions 11 Drying programmes WT14 MFH K 80 Progr. Spun Reduced Spun Normal Spun max. Max.temp. in Programme wash load number 1200 rpm (55%) 1400 rpm (50%) 1600 rpm (44%) the drum [kg] [min] [kWh] [min] [kWh]... - Page 23 Dryer WT14 Service instructions Progr. Spun Spun Not spun Max.temp. max. Programme wash load number 600 rpm (45%) 800 rpm (38%) in the drum [kg] [min] [kWh] [min] [kWh] [°C] Easy care iron damp Express Easy care slightly dry Express...
-
Page 24: Drying Programmes Wt14 Mfh A 80
Dryer WT14 Service instructions 12 Drying programmes WT14 MFH A 80 Progr. Spun Reduced Spun Normal Spun max. Max.temp. in Programme wash load number 1200 rpm (55%) 1400 rpm (50%) 1600 rpm (44%) the drum [kg] [min] [kWh] [min] [kWh]... - Page 25 Dryer WT14 Service instructions Progr. Spun Spun Not spun Max.temp. max. Programme wash load number 600 rpm (45%) 800 rpm (38%) in the drum [kg] [min] [kWh] [min] [kWh] [°C] Easy care iron damp Express Easy care slightly dry Express...
- Page 26 Dryer WT14 Service instructions Progr. Spun Spun Not spun Max.temp. max. Programme wash load number 600 rpm (45%) 800 rpm (38%) in the drum [kg] [min] [kWh] [min] [kWh] [°C] Reconditioning 10-90 timed drying cold ** Programmes without moisture measurement...
-
Page 27: Overview Of The Model Types And Machine Parameters (Settings Ex Factory)
Optical interface Power outage type display interval programme end AutoStart Schulthess 8640.1 Electric Schulthess Spirit 640 7713.1 8 kg WT14 EFH W1 80 Schulthess 8630.1 Electric Schulthess Spirit 630 7712.1 8 kg WT14 EFH W1 80 Schulthess 8620.1 Electric Schulthess Spirit 620 7711.1... - Page 28 Optical interface Power outage type display interval programme end AutoStart Merker 2149.1 Electric Merker Vento Prestige 8 kg WT14 EFH W1 80 Merker 2147.1 Electric Merker Vento Comfort 8 kg WT14 EFH W1 80 Merker 2146.1 Electric Merker Vento Standard...
- Page 29 Optical interface Power outage type display interval programme end AutoStart Rodus 7703.1 Electric Schulthess Schulthess Spirit 620 8 kg WT14 EFH W1 80 Rodus 7704.1 Electric Schulthess Schulthess Spirit 640 8 kg WT14 EFH W1 80 Küppersbusch 7707.1 Electric Kueppersbusch TD 1940.0 W / AT...
- Page 30 AutoStart Schulthess Spirit 9350.1 Electric Schulthess Without topLine TC 9350 8 kg WT14 MFH K 80 Schulthess Spirit 9340.1 Electric Schulthess Without topLine TC 9340 WT14 MFH A 80 8 kg Merker 2153.1 Electric Merker...
- Page 31 Dryer WT14 Service instructions Version Code Door hinge left Plinth with Lint filter drawer Combined heating e/s Drain valve PrePaid Card system integrated not used Drain pump Water recovery Aquastop Reduced connection power Programme extension module Steam valve water-controlled Soft or rain water connection...
-
Page 32: Documents Overview
Dryer WT14 Service instructions 14 Documents overview Installation Product Operating Tower Brand, Model Block diagram Installation plan number instruction positioning plan instruction Schulthess 8640.1 638448 638302 (d) 638326 (f) 983146 638430 638431 Spirit 640 (de fr it en) 638327 (i) 638328 (e) - Page 33 Dryer WT14 Service instructions Installation Product Operating Tower Brand, Model Block diagram Installation plan number instruction positioning plan instruction Merker 2146.1 638448 638467 (d) 638468 (f) 983146 638430 638431 Vento Standard (de fr it en) 638469 (i) 638470 (e) (de en)
- Page 34 538812 (d), 538850 (f) , 538851 (i) , 538852 (e) Instructions for the use Payment system 538800 (de fr it en) Use the spare parts portal to search for spare parts: http://spareparts.schulthess.ch (search Spare parts catalogue for requested model, e.g. Schulthess / Household / Spirit 540)
