Page 1: Operating Instructions
Only use appliance after first reading these instructions! Operating instructions Exhaust air dryers topLine pro TA 9340... - Page 2 Symbols Please read the instructions. Warnings are marked with a warn- ing triangle. The text gives information how a dangerous situation can be avoided. Signal words indicate the severity of the danger, if not avoided. Warning means that possible personal injuries, and potentially life-threat- ening injuries may occur.
-
Page 3: Dear Customer
Please read these instructions carefully to enable you to use all the possibilities and advantages of your new dryer. Please note in particular the safety informations. We hope you will be very happy with your new Schulthess dryer. Your Schulthess Maschinen AG... -
Page 4: Table Of Contents
Contents Safety and safety measures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 Disposal . - Page 5 Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25 Language (temporarily) .
-
Page 6: Safety And Safety Measures
Safety and safety measures Use in accordance with the intended purpose The enclosed documents contain The dryer is suitable exclusively for important information on the the drying of all textiles intended installation, use and safety of the for this treatment according to their dryer. - Page 7 Safety while handling and Warning operating Risk of injury! Climbing onto the dryer may cause Warning it to tip and cause injuries. Danger of electric shock! Never climb onto the appliance. ► Do not connect an appliance ► Do not sit, lean or support your- ►...
- Page 8 Safety for children Warning Risk of fire! Warning Items containing heat sensitive Risk of injury! substances can ignite during the Children are in danger of injury or drying process. life-threatening situations, when Never dry laundry in your dryer ► playing with the machine. that has been cleaned with Keep children under 3 years ►...
- Page 9 Safety during installation The maximum load is 8 kg of dry textiles. Warning Dry clean laundry in the dryer ► Risk of injury! only. If the machine is to be placed on a Before starting a programme, ► plinth, it must be mounted accord- make sure that there is no ing to the installation instructions, foreign object in the drum.
-
Page 10: Disposal
Disposal Packaging from your new machine Disposal of your old machine All packaging materials used are environ- Please do not keep your old machine and mentally friendly and reusable. under no circumstances dispose of it Return the packaging to the retailer or in your normal waste. -
Page 11: Environmentally Compatible Drying
Environmentally Drying the laundry compatible drying Remove easy care laundry from the ► dryer in a slightly damp state if possi- dry) and allow to finish (Slightly Notice drying in the air. Over drying causes Wringing wet laundry: waste of energy! creases. -
Page 12: Machine Description
Machine description Control and display area Loading door Cooling grid... - Page 13 Cotton Extra dry Cotton Cabinet dry Easy Care Cabinet dry Display and buttons Prrogramme groupe On / Off Additional programmes Back in the menu Programmes Scroll backwards Mixed laundry Scroll forwards Options Start programme Gentle plus Open the door Reverse + Language (temporary) / Settings Page number programme menu...
-
Page 14: Drying
Drying Preparing the appliance Selecting programme Check whether the fluff filter is ► Drying / Cleaning the in place (see Cotton Extra dry fluff filter). Switch on the power supply. ► Cotton Cabinet dry Turn on machine Easy care Cabinet dry On / Off Press button ►... -
Page 15: Starting The Programme
Skipping to the next Adding laundry programme step Make sure that there is no foreign body ► in the drum (coins, nails, paper clips, Cotton etc.). 1:08 h max. 8.0 kg Cabinet dry Distribute the laundry evenly in the ► Drying drum. -
Page 16: Cancelling The Programme
Cancelling the programme Programme stopped Cotton 0:32 h Add laundry and close door. max. 8.0 kg Cabinet dry Drying Follow the directions on the display. ► Cancel Forward Programme end Cancel Press the light bar next to until ► 0:01 h is displayed. -
Page 17: Cleaning The Fluff Filter
Cleaning the fluff filter Notice It may happen that a supposedly When fabrics are used, the fibres proper cleaned filter becomes imper- are rubbed (laundry fluff), which are meable, due to a fine, invisible coat released when the fabrics are dried, remaining in the filter meshes. -
Page 18: Programme Survey
Programme survey Always check the care symbols on the fabrics h:min = Duration / rpm = Spin speeds / kWh = Power consumption (Approximate values) Cotton and line h:min 8,0 kg Cotton Mangle moist Terry towels, tea towels, hand towels, bed linen, underwear, 0:28 1200 cotton socks... -
Page 19: Easy Care Laundry
Easy care laundry Non-iron synthetic and mixed fibres and cotton with non-iron trim, e.g. viscose, cupro, modal, polyester h:min Easy care Iron damp 4,0 kg Anoraks, covers 0:19 ► For laundry to be ironed 0:16 4,0 kg Easy care Slightly dry Shirts, blouses, sportswear, bed and table linen, sweat suits 0:24 ►... -
Page 20: Additional Programmes
Mixed laundry h:min 4,0 kg Mixed laundry Cabinet dry For mixed laundry made of cotton and easy care textiles 0:35 (e.g. sportswear and terry towelling) ► For laundry which will not be ironed or only lightly ironed Additional programmes h:min 3,0 kg Shirts, blouses Iron damp Shirts and blouses (max. -
Page 21: Wetclean
h:min 8,0 kg Terry towels Extra dry Terry towels, bath towels, bathrobes etc. made of cotton 0:59 1200 0:54 1400 0:49 1600 Impregnating Extra dry 3,0 kg Newly impregnated sports and leisure jackets, weather 1:17 gear, ski wear ► Machine drying sets the impregnant ►... -
Page 22: Special Programmes
Special programmes Mixed laundry Wetclean This programme is optimised for drying In Wetclean mode, washed laundry mixed laundry made of cotton and can be gently pre-dried with this synthetic. programme. The laundry is then ready for the Additional programmes appropriate finishing process. Use these programmes for best results when drying a variety of textiles, such as e.g. -
Page 23: Time Preset
Time preset The selected programme starts ► automatically when the start time is reached. Time preset With the option ► Pressing the start button again can- ► start time of the programme can be cels time preset and the washing pro- delayed and thus suit your lifestyle gramme can be started immediately. -
Page 24: Time
Time When calling up timed programmes, the minimum programme duration is displayed. The drying time can be adjusted to ► the kind and amount as well as the dryness level of the laundry. Timed drying 0:20 h max. 4.0 kg Time Increase the programme duration by ►... -
Page 25: Settings
Settings Your washing machine has default settings from the factory. The settings Language can be adapted to the users individual English Italian needs either when first used or later using the following functions. Français Españo The settings can only be changed if no Deutsch wash programme is running. -
Page 26: Menu Settings
Menu Settings Data Default settings ► * = Default settings – By pressing the on the light bar, you can change the month and day (keep finger pressed to scroll rapidly) Confirm entry by pressing the light bar ► Cotton Extra dry next to OK. -
Page 27: More Settings
More settings Brightness display 50 * ► The following settings are not available The background light intensity can for all appliances. be continuously adjusted from 20 to 100 % (hold bar for fast forward). Language Confirm entry with OK. Deutsch * ►... - Page 28 Child lock Switching off the machine Off * Settings for switching of the machine ► automatically: ► The child lock is to prevent accidental ► starting, changing or deletion of a Machine always remains switched on. programme by small children. On * ►...
- Page 29 Default settings The settings can be reset to default (state as delivered). Default settings Reset to default setting? Confirm the reset with Yes. ► All settings are reset to default. Reduced mains power No * ► ► If the connected load is reduced, the programme times will be extended accordingly.
-
Page 30: Cash-Card / Prepaid Card
Cash-Card / Prepaid Card Selecting the programme Insufficient credit on card Select the desired programme (see If there is not enough credit on the ► Drying / Selecting programme user card to cover the programme price, starting). the following message will appear in the display. -
Page 31: Cleaning And Maintenance
Cleaning and Maintenance Caution Cleaning the fluff filter Drying / Cleaning the fluff Danger of electric shock! filter. Switch off the power supply to the ► machine before cleaning. Cleaning the filter holder Under no circumstances spray the ► machine with water. Do not use a steam cleaner. -
Page 32: Cleaning The Moisture Sensor
Cleaning the moisture sensor After longer operation, small deposits (lime, fabric refiner) can form on the front inner side of the drum on both sides of the longish moisture sensors. With moisture controlled programmes, this can result in the desired level of dryness not being reached. -
Page 33: Problems
Problems Warning Improper repairs can result in severe accidents, damages and operation malfunctions! Do not make any changes, manipulations or attempt repairs using tools such as screw- drivers, etc. E R RO R MESS AGE S Child lock active (is not lit!) and at the Hold the bar in the upper right ►... - Page 34 ER RO R ME SS AGE S C A S h - C A R D / P R E P A I D C A R D Turn card Turn the card over. ► Not enough balance There is not enough credit on the card. Insert different user Use a card which has credit.
- Page 35 The drying target When warm, laundry feels more moist than it actually is! was not achieved Remove the laundry from the dryer and let it cool. ► When still moist: Drying / Cleaning the fluff Clean the fluff filter (see ►...
- Page 36 ER RO R ME SS AGE S F – – Acknowledge the error message with OK. «Error F ––» ► is displayed Machine restarts. Select a programme again and press button ► Acknowledge the error message with OK. «Error F ––» ►...
-
Page 37: Technical Specifications
Technical specifications A-weighted continuous sound level The measured continuous sound level is below 70 dB(A). Customer service Check whether you can correct the fault Give customer services the error message yourself before you call customer service F –– and the product and appliance number (see chapter Problems). -
Page 38: Notes
Notes... - Page 40 Headquarters and Production Schulthess Maschinen AG Landstrasse 37, 8633 Wolfhausen ZH Tel . + 41 (0) 55 253 51 11 www .schulthess .ch Österreich Schulthess Maschinen GmbH A-1130 Wien, Hetzendorferstrasse 191 Tel . + 43 (0) 1 803 98 00 www .schulthess .at...
