AudioSource Amp Seven T Owner's Manual

Stereo power amplifier with internal bridging

Download this manual

Stereo Power Amplifier with Internal Bridging

We hope that you will enjoy your AudioSource Amp Seven T. Please take a few moments to read this manual, and be sure

to retain this document for future re f e rence. Note: If any part of this product is damaged or missing, do not contact your

A u d i o S o u rce dealer. Please call us directly at 800-435-7115.

Using the Controls/Front Panel

Power

This front panel button will manually switch the Amp Seven T on or off. A multicolored LED indicates its power status. To use the

Auto On feature, leave this front panel switch in the on position.

Speaker Selector

The Amp Seven T has two pairs of speaker outputs. Press button A to activate the A outputs. Press button B to activate the B outputs.

Both A and B outputs may be used simultaneously, provided the combined impedance does not fall below 2 ohms. Before pressing

either of the speaker selector buttons, be sure that the level controls are set at the minimum position.

Input Level Controls

These knobs adjust the incoming signal level and thereby act as volume controls. We recommend that you set these at

midpoint and use your signal source (receiver, CD player, preamplifier, etc.) to adjust the volume.

Amp Seven T

Owner's Manual

Need help?

Do you have a question about the Amp Seven T and is the answer not in the manual?

Page 1 Speaker Selector The Amp Seven T has two pairs of speaker outputs. Press button A to activate the A outputs. Press button B to activate the B outputs. Both A and B outputs may be used simultaneously, provided the combined impedance does not fall below 2 ohms. Before pressing either of the speaker selector buttons, be sure that the level controls are set at the minimum position.
Page 2 Manual/Auto Power Switch (Rear Panel) In the Auto mode, the Amp Seven T will turn on automatically when an input signal is sensed. In the absence of an input signal, the Amp Seven T will shut down automatically. (In the Auto mode, the front panel power switch should always remain in the on posi- tion.) In the Manual mode, use the front panel power switch to activate the Amp Seven T.
Page 3 All other servicing should be referred to qualified service personnel. Product Servicing In the event that your Amp Seven T fails to operated properly, please contact the dealer where you purchased the unit. Or you may contact AudioSource directly for further assistance.
Page 4 Amp Seven T Specifications Amplifier Power Output ..200 watts per channel Total Harmonic Distortion ....<0.04% Intermodulation Distortion ....<0.04% Frequency Response .
