Summary of Contents for KKT KOLBE EB8200ED
- Page 1 User’s manual for your built-in electric oven Model: EB8200ED Version: 1.0 / 140707...
-
Page 2: Safety Instructions
This device is intended solely for preparation of food in the household or si- milar conditions and is not suitable for commercial use. (Loss of warranty). KKT KOLBE is not liable for damage caused by improper use, failure to follow the operating instructions and inappropriate use! -
Page 3: Safety Precautions
Safety precautions Warning • When the oven is first switched on, it may give off an • Care should be taken to avoid touching heating ele- unpleasant smell. This is due to the bonding agent ments inside the oven. used for the insulating panels within the oven. This is •... -
Page 4: Dear Customer
Thank you! Dear customer, thank you for the trust placed in us and for the purchase of this KKT KOLBE device. Your new ap- pliance is designed for the requirements in your- household. Please read this user’s and instruction manual ca- refully, which describes the capabilities and opera- tion of your KKT KOLBE-mounted device. -
Page 5: Table Of Contents
Table of content 1. Using the device 1.1 Control panel 1.2 Energy saving tips 1.3 Types of heating / functions 2. The oven interior 2.1 Construction 2.2 Telescopic runners 2.3 Device fan 3. Application 3.1 Roast 3.2 Grilling & baking 3.3 Baking 3.4 Boiling down 3.5 Unfreezing... -
Page 6: Using The Device
Using the device Control panel Temperature Semi-automatic Type of heating Kindersicherung „Duration“ Semi-automatic „Stop“ Timer working Time (Time of day, timer) „P“ = Preset or Thermometer-Icon Minute minder „d“ = Demo mode (lights up as long as on/off appliance heats up) Energy saving tips •... -
Page 7: Types Of Heating / Functions
Types of heating Types of heating Defrost In this mode only air circulation without heating is turned on. You can use it for gentle defrosting of frozen food. Top-/ bottom heating elements Default Temperature: 200 °C The top and bottom work together to provide convectional cooking. - Page 8 Types of heating Circular heating element with fan Default temperature: 170° An element around the convection fan provides an additional source of heat for convection style cooking. In convenction mode, the fan automatically turns on to improve air circulation within the oven and creates an even heat for cooking.
-
Page 9: Inside The Oven
Inside the oven Bottom heat elements + fan The lower radiator and the air circulation fan are on. Ideal for the preparation of pastries, cakes in shapes and sheets. We recommend that you use one of the lower rack levels. Top heating element Only the upper heater is in operation. -
Page 10: Application
Application Roasting Baking For roasting the top and bottom heat or hot air can be For baking, the top and bottom or the hot air may be used. used. If in the baking table no special pastries types are specified, select the information to a similar pastry or •... -
Page 11: Application Table
Application Defrost By air circulation at room temperature, thawing of food gets accelerated. Use the defrost function. • To thaw, cream and butter cream cakes, pies and pastries, bread and rolls, frozen fruits are suitable. • For a uniform thawing, rotate or stir defrosted in between. Application table Food Insertion... -
Page 12: Programming
Programming First use The operating mode can be changed any time during operation by pressing the keys. The temperature The oven should be thoroughly cleaned first. The oven for you can adjust by the two buttons + and – keys. about 20 minutes at 200 degrees heat up (Procedure: See below);... - Page 13 Programming Beep tone • Turn on the oven with this button: • Then press the button P. Now the appliance will start wor- king in the stored configuration. • Each operation of a switch or control surface is confirmed by a beep. Also reaching the set temperature is displayed by this acknowledgment.
-
Page 14: Time Functions
Programming 2. Semi-automatic function „DURATION“ Time functions The oven has an electronic clock which not only displays the current time, but also the device can reliably accor- ding to your specifications automatically turn on and off. The following functions are possible: 1. - Page 15 Programming • After reaching the point of time, the sign "STOP" and the and 10 minutes and fry complete this operation on time at time display (0:00) starts to flash and a buzzer will ring. 12:00 clock in order to switch it off afterwards. •...
-
Page 16: Care And Cleaning
Care and cleaning Care and cleaning Oven • The oven is easier to clean when it is still slightly warm. Simple remove grease splashes with rinse water. • For cleaning, don’t use steam cleaners. • Use conventional oven cleaner for stubborn or severe •... -
Page 17: Telescopic Runners
Care and cleaning Remove the hook in racks Remove accessories such as rust and baking sheet. Hook in racks at the clamping point slightly push down (2 in figure) and the oven wall down. Swivel hook in racks inside and unhook at the top (1 in figure) Insert hook in racks Insert the siderails up in the holes and swing it down. -
Page 18: Troubleshooting
Troubleshooting Oven door The oven door is fitted with three successive positioned glass panes. For cleaning the inner and middle glass plate can be removed. • Whenever the door of the oven is removed, the clips should be opened. Rinse the glasses with warm water and special glass cleaner. - Page 19 Troubleshooting Accessoires Grill grid Roast grid • Grills • for frying • Cake mold • Griddle Universal baking tray Deep baking tray • Great cake • For gravy and sauces • biscuits • Frozen foods • Fat / juice collection pan Baking sheet trays •...
-
Page 20: What To Do In Case Of Problems
Troubleshooting What to do in case of problems? Unqualified persons should perform the repairs on this unit because of electric shock and short circuit hazard. Repairs ge- nerally only be carried out by a licensed professional. The oven doesn’t heat up. Device fuse tripped in the house installation? Temperature controller and the function selector switch set correctly? -
Page 21: Installation And Connection Of The Device
Installation and connection of the device Installation in a floor cabinet The device may only be connected by a qua- Phase lified person. The furnace must be installed according to the instructions. Remove the Ground protective strip from the door. After installing, remove the protective strip from the interior Neutral surfaces of the oven. - Page 22 Connection to the power supply Connection to the power supply Foll owing cable types are suitable for the device: phase H05 RR-F , Min 1.1m 3x 2.5mm ground During this operation, the appliance must be neutral disconnected from the mains! •...
-
Page 23: General Information
General information Data sheet Manufacturer KKT KOLBE Model EB8200ED Mains voltage 220-240V ~50/60Hz or 50Hz Volume 53/58 Liter 2.750 W – 3.300 W Power consumption Temperature 60 – 250 °C Energy efficiency class* Weight 38,0 kg – with packaging 41,8 kg... - Page 24 Thank you for reading. We wish you much success and joy with your device. Version: 1.0 / 140626...
