Craftsman 151.37664 Operator's Manual

18 in. reel mower
Hide thumbs

Advertisement

Quick Links

OPERATOR'S MANUAL
MANUEL DEL OPERADOR
18 in. REEL MOWER
XXXXXXXXXXXXXXXXXXXXXXXXXX
Model No.
151.37664
Número de modelo
151.37664
By Adam Radzinski at 2:49 pm, Oct 10, 2014
WARNING:
To reduce the risk of injury, the user must read and understand the operator's manual
before using this product.
ADVERTENCIA:
Sears Brands Management Corporation, Hoffman Estates, IL 60179 USA
Visit the Craftsman web page: www.craftsman.com
Visite el sitio web de Craftsman: www.craftsman.com
Para reducir el riesgo de lesiones, el usuario debe leer y comprender el manual del operador
antes de usar este producto.
Save this manual for future reference
Guarde este manual pare futuras consulta

Advertisement

loading

  Related Manuals for Craftsman 151.37664

  Summary of Contents for Craftsman 151.37664

  • Page 1 Para reducir el riesgo de lesiones, el usuario debe leer y comprender el manual del operador antes de usar este producto. Sears Brands Management Corporation, Hoffman Estates, IL 60179 USA Visit the Craftsman web page: www.craftsman.com Visite el sitio web de Craftsman: www.craftsman.com Save this manual for future reference Guarde este manual pare futuras consulta...
  • Page 2: Table Of Contents

    WITH PROOF OF SALE a defective product will be replaced free of charge. For warranty coverage details to obtain free replacement, visit the web page: www.craftsman.com/warranty This warranty is void if this product is ever used while providing commercial services or if rented to another person.
  • Page 3: English

    SAFETY INFORMATION ■ Never intentionally strike or hit trees, fences, etc. This IMPORTANT SAFETY INSTRUCTIONS can cause injuries or severely damage the reel mower mechanisms. IMPORTANT! READ AND UNDERSTAND ■ Make sure your reel mower is in a safe operating ALL INSTRUCTIONS.
  • Page 4: Safety Information

    SAFETY INFORMATION ■ Plan your mowing pattern in such a way as to CHILD SAFETY avoid discharging material toward roads, sidewalks, Tragic accidents can occur if the operator is not aware bystanders, etc. of the presence of children. ■ Always wear a face mask or a dust mask when ■...
  • Page 5: Symbols

    SYMBOLS Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to operate the product better and safer. SYMBOL NAME DESIGNATION/EXPLANATION To reduce the risk of injury user must read and understand Read The Operator’s Manual operator’s manual before using this product.
  • Page 6: Features

    FEATURES PRODUCT SPECIFICATIONS Cutting path ............................18" (45 cm) Height adjustments ......................3/4 - 2 1/2" (1.9-6.3 cm) Number of blades ..........................5 Helical blades Weight ............................29.3 lbs (13.3 kg) KNOW YOUR LAWN MOWER REAR BAG See Figure 1. The rear bag prevents grass clippings from being The safe use of this product requires an understanding scattered across your lawn as you mow.
  • Page 7: Assembly

    ASSEMBLY UNPACKING ASSEMBLING THE HANDLE See Figure 3-4. Before attempting to assemble, empty carton and compare parts with parts list below. NOTE: Do not completely tighten bolts until assembly is complete. ■ Carefully remove the product and any accessories from the box. ■...
  • Page 8: Operation

    OPERATION CUTTING HEIGHT ADJUSTMENT CHECKING THE ADJUSTMENT See Figure 9. See Figure 11. ■ The cutting height of the mower adjusts from 3/4 - ■ Turn mower upside down. 2 1/2″ (1.9 - 6.3 cm) with 9 positions for adjustment ■...
  • Page 9: Care And Maintenance

    CARE AND MAINTENANCE ■ Minimum care is required to ensure smooth operation of your mower. ■ To avoid damage to mower or cutting blades, keep area to be mowed free from debris. ■ For best results, regularly apply lubricant to mower’s cutting surfaces, cutting reel axle shaft and wheels.
  • Page 10: Illustrated Parts List

    CRAFTSMAN 18in. REEL MOWER – MODEL NUMBER 151.37664 The model number will be found on a label attached near left wheel. TO PURCHASE REPLACEMENT PARTS, CALL 1-888-331-4569 10 ― English...
  • Page 11 CRAFTSMAN 18in. REEL MOWER – MODEL NUMBER 151.37664 The model number will be found on a label attached near left wheel. TO PURCHASE REPLACEMENT PARTS, CALL 1-888-331-4569 ITEM NO. PART NO. DESCRIPTION Soft grip 100106451-001 Top handle 100106452-01 Middle handle...
  • Page 12 CRAFTSMAN 18in. REEL MOWER – MODEL NUMBER 151.37664 The model number will be found on a label attached near left wheel. TO PURCHASE REPLACEMENT PARTS, CALL 1-888-331-4569 ITEM NO. PART NO. DESCRIPTION C-clip 100106455-004 Washer Wheel assy. 100104820-01 Supporting assy.(L)
  • Page 13 See this section for all of the fi gures referenced in the operator’s manual. Consulte esta sección para ver todas las fi guras a las que se hace referencia en el manual del operador. Fig. 1 A - Upper handle (Agarradera superior) B - Middle handle (Agarradera central) C - Lower handle (Agarradera inferior) D - Rear bag (Bolsa trasera)
  • Page 14 Fig. 2 Fig. 2 A - Top handle (Agarradera superior) B - Center handle pieces (Piezas centrales de la agarradera) C - Lower handle (Agarradera inferior) D - Foam grip (Asidero de espuma) E - Carriage bolts (Pernos de soporte) F - Knobs (Perilla) G - Reel mower body (Cuerpo de la podadora de carrete) H - Rear bag (Bolsa trasera)
  • Page 15 Fig. 5 Fig. 6 Fig. 7 Fig. 8...
  • Page 16 Fig. 9 Fig. 10 Underside of mower (xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx) A - Height adjustment lever (Ajuste de la altura) A - Adjustment screw (Tornillo de ajuste) Fig. 11 A - Paper (Papel) B - Blade (xxxxxxxxxx) C - Cutting bar (Barra de corte)
  • Page 17 Para respuestas a preguntas o problemas, y ordenar piezas o pedir servicio para la reparación de su equipo. To help us help you, register your product at www.craftsman.com/registration Para poderte ayudar mejor, registra tu producto en www.craftsman.com/registration Join the Craftsman Club today!
