1.5.2 Rear View
No. Name
1
Network
2
Audio Out
3
VGA
4
HDMI
5
USB
6
DC 12V
6
1
3
2
Figure 1-3
Function
Connect to the network.
Connects to a speaker.
Connect to a VGA monitor.
Connect to an HDMI supported display device.
Connect to a GV-Joystick V2, USB mouse, or USB storage device.
Connect to power by using the supplied power adapter.
6
4
5
