GV-NET Card V3.2
The GV-NET Card is a RS-485 / RS-232 interface converter. This Card connects to the RS-
232 port or USB port on your computer, and allows RS-485 devices, such as PTZ domes, to
be connected through the Card.
System Requirements
If the GV-NET/IO Card is listed as Prolific USB-to-Serial Comm Port under Windows
Device Manager, GV-System version 8.2 or above is required. If the GV-NET/IO Card is
listed as XR21B1411 USB UART under Windows Device Manager, GV-System version
8.5.7.0 or above is required.
To see how to check the device name under Windows Device Manager, refer to Installing
USB Driver later in this Installation Guide.
Packing List
1. GV-NET Card x 1
2. RJ-11 to DB9 Cable x 1
3. RJ-11 to USB Cable x 1
4. Pin Internal USB Cable x 1
5. Pin to 4-Pin Mini Power Cable x 1
February 10, 2015
1
Advertisement
Table of Contents
Related Manuals for GeoVision GV-NET Card V3.2
Summary of Contents for GeoVision GV-NET Card V3.2
- Page 1 GV-NET Card V3.2 The GV-NET Card is a RS-485 / RS-232 interface converter. This Card connects to the RS- 232 port or USB port on your computer, and allows RS-485 devices, such as PTZ domes, to be connected through the Card.
- Page 2 Connects to the USB Mini Power Cable Connectors on the PC's motherboard GV-Net Card V3.2 Connections Note: The GV-NET Card only provides RS-485 / RS-232 data conversion; the connection to the GV-Video Capture Card is not required. February 10, 2015...
- Page 3 Connections with Two Video Capture Cards If your system is equipped with two video capture cards, connect the GV-NET/IO Card to the video capture card of 1-16 channels. Connections in NET/IO Card Mode For the connections in the NET/IO Card Mode, please follow the instructions below: •...
- Page 4 You can connect a RJ-11 to USB Cable to the PC's USB Port when a RS-485 device is connected. (Allowed for AC/DC Output Voltage) GV Video Capture Card PTZ Dome RS-485+ RS-485- With 2-pin header RJ-11 to USB Cable Connects to PC's USB Port Note: It is required to install the USB driver.
- Page 5 Connections In I/O Box Mode For the connections in the I/O Box Mode, please follow the instructions below: • It is not necessary to connect the GV-NET/IO Card to GV-Video Capture Card. • Connect the GV-NET/IO Card to the PC by one of the following three ways. Note: When you want to use any of GV-I/O 12-In Card and GV-I/O 12-Out Card with GV-Net/IO Card, it is required to use both of 12-In Card and 12-Out Card together for work.
-
Page 6: Switching Modes
3. You can connect a 3-Pin Internal USB Cable to the USB Connectors on the PC's Motherboard. (Allowed for DC Output Voltage only) Chaining together with GV Video Capture Card GV-NET/IO Card V3.1 or later / GV-IO USB (white) DM (D-) (green) DP (D+) 3-pin Internal... -
Page 7: Dip Switch
Extended Connections Via the RS-485 connectors, up to 4 GV-NET/IO Cards can be chained together when the GV- NET/IO Card is on the I/O Box mode. For extended connections, the address assignment is shown below. Note: When the GV-NET/IO Card is set to the I/O Box Mode, it can have extended connections with GV-I/O Boxes. -
Page 8: Installing Usb Driver
1. Insert the software DVD. It will run automatically and pop up a window. 2. Click Install GeoVision USB Devices Driver. This dialog box appears. 3. Click Install to install the drivers. When the installation is complete, this message will appear: Install Successfully. -
Page 9: Specifications
Specifications 32-bit Windows XP / Vista / 7 / 8 / Server 2008 64-bit Windows 7 / 8 / Server 2008 / Server 2012 Input Input Input Signal Dry Contact, Wet Contact 9~30V AC / DC Relay Output Relay Status Normal Open Output USB Connection...
