innovair UV36C2DB1 Installation Manual

Floor ceiling vortex

Hide thumbs

Table Of Contents

FLOOR CEILING VORTEX

INSTALLATION GUIDE

UV36C2DB1

UV48C2DB1

UV60C2DB1

Contents

www.innovair.com

Table of Contents

Need help?

Do you have a question about the UV36C2DB1 and is the answer not in the manual?

Questions and answers

Summary of Contents for innovair UV36C2DB1

Page 2: Table Of Contents
Outdoor unit installation (Top Discharge Unit) ..21 Refrigerant pipe installation ........23 Drainage pipe installation.........26 Vacuum Drying and Leakage Checking ....30 Additional refrigerant charge ........31 Engineering of insulation .........32 10. Engineering of electrical wiring .......33 11. Test operation............34 Installation ©2015 Innovair Corporation. All Rights Reserved. www.innovair.com...
Page 3: Installation Procedure
Drainage pipe installation Drainage pipe installation and insulation and insulation Vacuum drying and leakage checking Additional refrigerant charge Insulation the joint part of refrigerant pipe Wiring connection and electric safety checking Test operation Installation ©2015 Innovair Corporation. All Rights Reserved. www.innovair.com...
Page 4: Location Selection
If is built over the unit to prevent direct sunlight, rain exposure, direct strong wend, snow and other scraps accumulation, make sure that heat radiation from the condenser is not restricted. More than 30cm More than 60cm (Service space £ More than 30cm More than 60cm More than 70cm Installation ©2015 Innovair Corporation. All Rights Reserved. www.innovair.com...
Page 5: Indoor Unit Installation
3. Indoor unit installation 3.1 Ceiling & floor indoor unit installation 3.4.1 Service space for indoor unit 3.4.2 Bolt pitch ¤ Ceiling installation Capacity (Btu/h) 1200 48K, 60K 1565 ¥ Wall-mounted installation Installation ©2015 Innovair Corporation. All Rights Reserved. www.innovair.com...
Page 6 Install the tapping screws onto the wall.(Refer to picture below) 3.4.4 Install the main body ¤ Ceiling installation (The only installation method for the unit with drain pump) Remove the side board and the grille. Installation ©2015 Innovair Corporation. All Rights Reserved. www.innovair.com...
Page 7 MCAC-UTSM-2010-10 Test Operation Locate the hanging arm on the hanging screw bolt. Prepare the mounting bolts on the unit. Put the side panels and grilles back. Installation ©2015 Innovair Corporation. All Rights Reserved. www.innovair.com...
Page 8 Hang the indoor unit by insert the tapping screws into the hanging arms on the main unit. (The bottom of body can touch with floor or suspended, but the body must install vertically.) Installation ©2015 Innovair Corporation. All Rights Reserved. www.innovair.com...
Page 9: Outdoor Unit Installation (Top Discharge Unit)
Check the local weather bureau for the expected snow accumulation in your area. Isolate the unit from rain gutters to avoid any possible wash out of the foundation. On roof installation Installation ©2015 Innovair Corporation. All Rights Reserved. www.innovair.com...
Page 10 Step 6: Assemble unit to cement pad using 4 1/4” * 2” Hex washer head cement screws make sure not to over tighten. Step 7:Finish unit assembly process as indicated in installation manual. Installation ©2015 Innovair Corporation. All Rights Reserved. www.innovair.com...
Page 11: Refrigerant Pipe Installation
5.2.7 Drill holes if the pipes need to pass the wall. 5.2.8 According to the field condition to bend the pipes so that it can pass the wall smoothly. 5.2.9 Bind and wrap the wire together with the insulated pipe if necessary. Installation ©2015 Innovair Corporation. All Rights Reserved. www.innovair.com...
Page 12 Precautions should be taken to prevent heat damage to service valve by wrapping a wet rag around it as shown in following picture. Also, protect all painted surfaces, insulation, during brazing. After brazing cool joint with wet rag. Installation ©2015 Innovair Corporation. All Rights Reserved. www.innovair.com...
Page 13 If the throttle part of indoor unit is separate design, it must be connected before connecting the pipe to indoor unit. Make sure the throttle part is horizontally installed. Connect to indoor unit Connect to the pipe Horizontal Installation ©2015 Innovair Corporation. All Rights Reserved. www.innovair.com...
Page 14: Drainage Pipe Installation
(mm) PVC25 For branch pipe PVC32 PVC40 PVC50 1440 Could be used for confluence pipe PVC63 2760 PVC75 5710 PVC90 8280 Attention: Adopt PVC40 or bigger pipe to be the main pipe. Installation ©2015 Innovair Corporation. All Rights Reserved. www.innovair.com...
Page 15 If the indoor unit has high extra static pressure and without water pump to elevate the condensate water, such as high extra static pressure duct unit , the water storage pipe should be set to avoid converse flow or blow water phenomena. Installation ©2015 Innovair Corporation. All Rights Reserved. www.innovair.com...
Page 16 Each indoor unit of the system should be installed it. The installation should be considering the convenience for future cleaning. Blowhole Indoor unit Indoor unit Plug Plug 6.2.9 The end of drainage pipe shall not contact with ground directly. Installation ©2015 Innovair Corporation. All Rights Reserved. www.innovair.com...
Page 17 During normal operation, the plug shall be filled in to prevent leakage. 6.4 Insulation work of drainage pipe Refer the introduction to the insulation engineering parts. Installation ©2015 Innovair Corporation. All Rights Reserved. www.innovair.com...
Page 18: Vacuum Drying And Leakage Checking
Leakage test: After the vacuum degree reaches -755mmHg, stop vacuum drying and keep the pressure for 1 hour. If the indicator of vacuum gauge does not go up, it is qualified. If going up, it indicates that there is moisture or leak source. Installation ©2015 Innovair Corporation. All Rights Reserved. www.innovair.com...
Page 19: Additional Refrigerant Charge
The refrigerant should be charged in liquid state. Before recharging, The air in the flexible pipe and manifold gauge should be exhausted. After finished refrigerant recharge process, check whether there is refrigerant leakage at the connection joint part.(Using gas leakage detector or soap water to detect). Installation ©2015 Innovair Corporation. All Rights Reserved. www.innovair.com...
Page 20: Engineering Of Insulation
9.2.2 Purpose of drainage pipe insulation The temperature of condensate drainage water is very low. If insulation is not enough, it shall form dew and cause leakage to damage the house decoration. Installation ©2015 Innovair Corporation. All Rights Reserved. www.innovair.com...
Page 21: Engineering Of Electrical Wiring
The wiring with different voltage should not be in one wire tube. Ensure that the color of the wires of outdoor and the terminal No. are same as those of indoor unit respectively. Installation ©2015 Innovair Corporation. All Rights Reserved. www.innovair.com...
Page 22: Test Operation
Whether there is vibration or abnormal noise during operation. Whether the generated wind, noise, or condensed of by the air conditioner have influenced your neighborhood. Whether any of the refrigerant is leaked. Installation ©2015 Innovair Corporation. All Rights Reserved. www.innovair.com...
