innovair IUS0736C21 Owner's Manual

Innovair ceiling and floor type air conditioner
Hide thumbs Also See for IUS0736C21:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Service Manual
OWNER'S
MANUAL

Ceiling And Floor Type

Thank you very much for purchasing our air conditioner,
Before using your air conditioner, please read this manual carefully and keep it for future reference.

Advertisement

Table of Contents
loading

Related Manuals for innovair IUS0736C21

Summary of Contents for innovair IUS0736C21

  • Page 1: Ceiling And Floor Type

    OWNER'S MANUAL Ceiling And Floor Type Thank you very much for purchasing our air conditioner, Before using your air conditioner, please read this manual carefully and keep it for future reference.
  • Page 2 INDOOR UNIT OUTDOOR UNIT Fig.1 INDOOR UNIT OUTDOOR UNIT Connecting pipe Air flow louver (at air outlet) Air inlet Air inlet (with air filter in it) Installation part Air outlet Display panel Remote controller Drain pipe NOTE All the pictures in this manual are for explanation purpose only. They may be slightly different from the air conditioner you purchased(depend on model).

  • Page 3: Table Of Contents

    It is not good for your health to expose your body to the CONTENTS PAGE air flow for a long time. Do not insert fingers, rods or other objects into the air IMPORTANT SAFETY INFORMATION............1 inlet or outlet. TEMPORARY OPERATIONS..............2 When the fan is rotating at high speed, it will cause injury.

  • Page 4: Temporary Operations

    2. TEMPORARY OPERATIONS Do not operate the air conditioner with a wet hand. An electric shock may happen. The air conditioner consists of the indoor unit, the outdoor unit, Do not touch the heat exchanger fins. (See Fig.1) the connecting pipe and the remote controller. These fins are sharp and could result in cutting injuries.

  • Page 5: Air Conditioner Operations And Performance

    For inverter type,this switch is used for after-sales service purpose only,the user should not push it. NOTE For fixed-frequency type,this function is used to operate the unit temporarily in case you misplace the remote controller or its If air conditioner is used outside the above conditions, it may batteries are exhausted.

  • Page 6: Adjusting Air Flow Direction

    5. ADJUSTING AIR FLOW DIRECTION Check and remove everything that might be blocking inlet Auto-swing and outlet vents of indoor units and outdoor units. Press SWING button, the louver will swing up and down Clean air filters and casings of indoor units. automatically.

  • Page 7: Following Symptoms Are Not Air Conditioner Troubles

    Symptom 3: White mist comes out of a unit Symptom 3.1: Indoor unit When humidity is high during cooling operation If the interior of an indoor unit is extremely contaminated, the temperature distribution inside a room becomes uneven. It is necessary to Air Inlet clean the interior of the indoor unit.

  • Page 8: Troubleshooting

    8. TROUBLESHOOTING Troubles and causes of air conditioner If one of the following malfunctions occur, stop operation, shut off the power, and contact with your dealer. The operation lamp is flashing rapidly (5Hz) This lamp is still flashing rapidly after turn off the power and turn on again. (See in Table 8-1) Remote controller receives malfunction or the button does not work well.
  • Page 9 Table 8-1 Malfunction Running lamp Timer lamp Defrosting lamp Alarm lamp EEPROM malfunction flash flash Room temperature sensor checking channel is abnormal flash Water-level alarm malfunction flash Outdoor unti malfunction flash flash flash flash Evaporator temperature sensor malfunction flash Condenser temperature sensor malfunction flash Table 8-2...
  • Page 10 Table 8-3 Symptoms Causes Solution Check whether the MODE When the automatic mode is indicated on the display is selected, the air conditioner will "AUTO" automatically change the fan The fan speed can not be speed. changed. When dry operation is selected, Check whether the MODE the air conditioner automatically indicated on the display is...
  • Page 11 QS01U-006AW The design and specifications are subject to change without prior notice for product improvement.Consult with the sales agency or manufacturer for details...
