1 / 5 REV.: 20180216 GUIDE # 31741 Page REGULAR INSTALLATION ADDENDUM - SUGGESTED WIRING CONFIGURATION INSTALLATION RÉGULIÈRE ADDENDA - SCHÉMA DE BRANCHEMENT SUGGÉRÉ Vehicle functions supported in this diagram (functional if equipped) | Fonctions du véhicule supportées dans ce diagramme (fonctionnelles si équipé) VEHICLE YEARS VEHICULES...
Page 2
This guide may change without notice. See www.fortin.ca for latest version. 2 / 5 Page Ce guide peut faire l’objet de changement sans préavis. Voir www.fortin.ca pour la récente version. DESCRIPTION | DESCRIPTION Parking Light Switch Ignition switch Commutateur des feux destationnement Commutateur d’Ignition...
Page 3
This guide may change without notice. See www.fortin.ca for latest version. 3 / 5 Page Ce guide peut faire l’objet de changement sans préavis. Voir www.fortin.ca pour la récente version. WIRING CONNECTION | GUIDE DE BRANCHEMENTS OUT RS20 ISARM IN RS8...
Page 4
This guide may change without notice. See www.fortin.ca for latest version. 4 / 5 Page Ce guide peut faire l’objet de changement sans préavis. Voir www.fortin.ca pour la récente version. PROGRAMMING PROCEDURE | PROCÉDURE DE PROGRAMMATION Do not use the grey key.
Page 5
The installation in every case is the sole responsibility of the installer performing the work and FORTIN ELECTRONIC SYSTEMS assumes no liability or responsibility whatsoever resulting from any type of installation, whether performed properly, improperly or any other way.
