RIP

Routing Information Protocol is an Internet protocol you can set up to share routing table information with other routing devices on
your LAN, at your ISP's location, or on remote networks connected to your network. Most small home or office networks do not
need to use RIP; they have only one Router, such as the DSL Router, and one path to an ISP. In these cases, there is no need to
share routes, because all Internet data from the network is sent to the same ISP gateway.
FIELD
Interface
The name of the interface on which you want to enable RIP.
Receive Mode
Indicate the RIP version in which information must be passed to the routing device in order for it to be accepted into its routing table.
Send Mode
Indicate the RIP version this interface will use when it sends its route information to other devices.
NetComm Wireless VDSL/ADSL Dual Band AC1200 WiFi Gigabit Modem Router with VoIP
38
DESCRIPTION
