SECTION 4: REPLACEMENT PARTS

Global stocks a complete line of replacement parts for your Modeltech SE5a Scout ARF. Listed below are the replacement
parts that are available along with their respective part numbers for easy ordering convenience. We suggest ordering
directly from your local dealer. If your dealer does not stock Modeltech products, you can order directly from us at the
address shown below:
Phone: (714) 963-0329
Modeltech SE5a Scout ARF - Complete ............... 123680
Instruction Manual ................................................. 120033
Wing Set (Top) ....................................................... 120034
Wing Set (Bottom) ................................................. 120035
Fuselage Set .......................................................... 120036
Stabilizer Set .......................................................... 120037
Fiberglass Cowling ................................................ 120038
Outer Strut Set ....................................................... 120039

SECTION 5: A NOTE ABOUT COVERING

The covering material used on the Modeltech SE5a Scout ARF is real iron-on, heat-shrink covering material, not cheap
"shelf paper." Because of this, it is possible with heat and humidity changes that the covering on your airplane may
wrinkle or sag. This trait is inherent in all types of heat-shrink material. To remove any wrinkles that might be visible
you will need to purchase, or borrow from a fellow modeler, a heat iron. If you need to purchase one, the Global Heat
Sealing Iron # 360900 is recommended.
Follow this simple procedure to remove the wrinkles:
Plug in and turn on the sealing iron to the medium-high temperature setting. Allow the sealing iron to heat up for
approximately 5 - 7 minutes.
After the sealing iron has reached temperature, lightly apply the sealing iron to the wrinkled section of the covering.
Move the sealing iron slowly over the wrinkled section until the covering tightens and the wrinkles disappear.
IMPORTANT You will notice that the color of the covering will darken when it is heated. When the covering cools
back down, it will return to its normal color.
If the color layer smears from any of the seams the temperature of the sealing iron is too hot. Turn the temperature dial
down and wait about 5 minutes for the sealing iron to adjust to the lower temperature. You can remove any excess color
streaks using a paper towel soaked with a small quantity of Acetone.
PRO TIP
We do not suggest storing your airplane in an extremely hot environment (like the back of your car in direct
sunlight) for any length of time. The extreme heat could cause the covering material to wrinkle or sag and possibly
damage the fragile components of the radio system.
Global Services
18480 Bandilier Circle
Fountain Valley CA 92708
Fax: (714) 964-6236
http://globalservices.globalhobby.com
Center-Cabane Strut Set ........................................ 120040
Plastic Detail Parts ................................................. 120041
Hardware Set .......................................................... 120042
Fuel Tank Set (240cc) ............................................. 120043
Landing Gear Assembly (No Wheels) .................... 120044
Decal Set ................................................................ 120045
Wire-Spoke Wheels (1 Pair) ................................... 237800
7
