INTRODUCTION

Thank you for purchasing the Modeltech SE5a Scout ARF. Before completing the final assembly of your new
airplane, please carefully read through this instruction manual in its entirety. Doing so will ensure your success
the first time around!
Prebuilt from High-Quality Balsa and Light Plywood
Precovered with Real Iron-On, Heat-Shrink Covering Material
Wire-Spoke Wheels and Scale Steel Landing Gear Strut Assembly
Prepainted Fiberglass Cowling
Metal Center-Cabane Struts and Precovered Outer Struts
Includes Most Hardware - Fuel Tank, Pushrods, Engine Mount, Etc.
Fast and Easy Assembly - Over 70 High-Resolution Digital Photos and Drawings to Guide You
This instruction manual is designed to guide you through the entire assembly process of your new airplane in the least
amount of time possible. Along the way you'll learn how to properly assemble your new airplane and also learn tips that
will help you in the future. We have listed some of our recommendations below. Please read through them before
beginning assembly.
Please read through each step before beginning
assembly. You should find the layout very complete and
straightforward. Our goal is to guide you through
assembly without any of the headaches and hassles
that you might expect.
There are check boxes next to each procedure. After
you complete a procedure, check off the box. This will
help prevent you from losing your place.
Cover your work table with brown paper or a soft cloth,
both to protect the table and to protect the parts.
If you should find a part missing or damaged, or have any questions about assembly,
Phone: (714) 963-0329
CHECK IT OUT!
We urge you to come check out our website at http://globalservices.globalhobby.com. There you will find public
message boards frequented by other Modeltech product owners and the Modeltech support staff. This is a great place to learn
about new Modeltech products, get help and suggestions for your current Modeltech products or just simply hang out and chat with
people that share your same interests.
To enable us to better serve your needs, please include your email address with any correspondence you send to us.
Your email address will be added to our Customer Service Database so you will automatically receive free updates and
tech notices for your particular product. You will also receive repair status updates (if applicable) and other important
information about your product as it becomes available.
Global Hobby Distributors will not disclose the information it collects to outside parties. Global Hobby Distributors does not sell,
trade, or rent your personal information to others . Your privacy is important to us.
MODELTECH SE5a SCOUT ARF FEATURES
please contact us at the address below:
Global Services
18480 Bandilier Circle
Fountain Valley CA 92708
Fax: (714) 964-6236
IMPORTANT INFORMATION ABOUT YOUR EMAIL ADDRESS
Keep a couple of small bowls or jars handy to put the
small parts in after you open the accessory bags.
We're all excited to get a new airplane in the air, but take
your time. This will ensure you build a straight, strong and
great flying airplane.
If you come across this symbol
an important point or an assembly hint.
Email: service@globalhobby.net
3
, it means that this is
