Meter Description
1.
Infrared sensor (top)
2.
Laser source (top)
3.
LCD Temperature Display
4.
Mode button
5.
Laser pointer and Down arrow button
6.
Backlight and Up arrow button
7.
Measure button (MEAS)
Note: Battery compartment is on rear of meter
Specifications
General Specifications
Range/Resolution
Accuracy
Temperature
Coefficient
Display
Measurement rate
Response time
Spectral Response
Emissivity
Detection element
Optical lens
Laser pointer
Field of view
Operating conditions
Storage conditions
Auto Power off
Standby consumption < 9mA
Power supply
Battery life
Dimensions / Weight
o
-4 to 1022
F (-20 to 550
±2% of reading or ± 6
o
(@ 64.4 to 82.4
F (18 to 28
A ±0.2% of reading or ±0.36
change in accuracy per
o
o
> 82.4
F(28
C) or < 64.4
3-1/2 digit (2000 count) backlit LCD with over-range and low
battery indication
1 reading per second
1 second
6 to 14 µm nominal
Adjustable from 0.10 to 1.00 (in 0.01 steps)
Thermopile
Fresnel Lens
Color: Red (670nm) Power: <1mW class II
D/S = Approx. 10:1 ratio (D = distance, S = spot)
o
32 to 122
F (0 to 50
o
-4 to 140
F (0 to 60
After 20 seconds of inactivity
Four (4) 'AAA' 1.5 V batteries
30 hours (continuous) typical with carbon-zinc battery (laser
pointer and backlight off)
6.7 x 1.7 x 1.6" (170 x 44 x 40mm) / 5.6 oz.(160g)
3
1
3
4
5
o
o
o
C) / 1
F/
C
o
o
F/3
C (whichever is greater)
o
C) ambient temperature)
o
o
F (0.2
C) (whichever is greater)
o
o
F/
C change in ambient temperature
o
o
F (18
C)
o
C) and < 70% relative humidity
o
C) and < 80% relative humidity
2
MODE
6
7
403265 Version 1.3 Feb 2003
