SECTION 7

[MAIN UNIT]

REF ORDER
NO. NO.
IC6 1110006350 S.IC LM2902PWR
IC8 1110005771 S.IC S-80942CNMC-G9CT2G
IC9 1110003201 S.IC TA31136FNG (EL)
IC10 1130011581 S.IC 24LC64T-I/SN G
IC12 1190001350 S.IC M62364FP 600D
IC13 1130006221 S.IC TC4W53FU (TE12L,F)
IC14 1110006221 S.IC AK2346P-E2/P
IC15 1110001811 S.IC TA7368FG (5,ER)
IC16 1110002751 S.IC TA75S01F (TE85R,F)
IC17 1110005350 S.IC NJM2870F05-TE1-#FZZB
IC19 1110006380 S.IC LM2904PWR
IC20 1130009090 S.IC LC75834W-TLM-E
IC21 1130010100 S.IC LMX2352TMX/NOPB
IC22 1140011511 S.IC HD64F2238BTF13V
IC23 1110006380 S.IC LM2904PWR
IC24 1110002751 S.IC TA75S01F (TE85R,F)
IC25 1130007021 S.IC TC7S66FU (TE85L,F)
Q2 1590003321 S.FET TPC6103 (TE85L,F)
Q3 1590003290 S.TR UNR9213J-(TX)
Q4 1560000841 S.FET 2SK1829 (TE85R,F)
Q5 1580000731 S.FET 3SK293 (TE85L,F)
Q6 1580000760 S.FET 3SK299-T1 U73
Q7 1530002601 S.TR 2SC4215-O (TE85R,F)
Q14 1530003260 S.TR 2SC5006-T1
Q15 1530003260 S.TR 2SC5006-T1
Q16 1530002920 S.TR 2SC4226-T1 R25
Q17 1530002920 S.TR 2SC4226-T1 R25
Q18 1590001400 S.TR XP1214 (TX)
Q19 1590003290 S.TR UNR9213J-(TX)
Q20 1530002851 S.TR 2SC4116-BL (TE85R,F)
Q21 1560000541 S.FET 2SK880-Y (T5RICOM,F)
Q22 1530002851 S.TR 2SC4116-BL (TE85R,F)
Q24 1510000920 S.TR 2SA1577 T106 Q
Q25 1510000920 S.TR 2SA1577 T106 Q
Q26 1520000450 S.TR 2SB1132 T100 Q
Q27 1590001190 S.TR XP6501-(TX) .AB
Q28 1590003230 S.TR UNR9113J-(TX)
Q29 1530003260 S.TR 2SC5006-T1
Q38 1590003290 S.TR UNR9213J-(TX)
Q40 1590003290 S.TR UNR9213J-(TX)
Q41 1590001190 S.TR XP6501-(TX) .AB
Q42 1520000450 S.TR 2SB1132 T100 Q
Q43 1590003400 S.TR UNR9112J
Q44 1590003270 S.TR UNR9210J-(TX)
Q45 1590003230 S.TR UNR9113J-(TX)
Q46 1590003290 S.TR UNR9213J-(TX)
Q502 1560001360 S.FET 2SK3019 TL
Q503 1590003290 S.TR UNR9213J-(TX)
D5 1160000060 S.DIO DAN202U T106
D6 1790001260 S.DIO MA2S077-(TX)
D8 1790001250 S.DIO MA2S111-(TX)
D9 1750000711 S.VCP HVC350BTRF-E
D10 1750000711 S.VCP HVC350BTRF-E
D11 1750000711 S.VCP HVC350BTRF-E
D12 1720000570 S.VCP MA368 (TX)
D13 1750000711 S.VCP HVC350BTRF-E
D14 1750000711 S.VCP HVC350BTRF-E
D15 1750000711 S.VCP HVC350BTRF-E
D16 1750000581 S.DIO 1SV307 (TPH3,F)
D17 1790001260 S.DIO MA2S077-(TX)
D18 1790001250 S.DIO MA2S111-(TX)
D19 1750000711 S.VCP HVC350BTRF-E
D20 1750000711 S.VCP HVC350BTRF-E
D21 1160000060 S.DIO DAN202U T106
D23 1750000940 S.DIO ISS400 TE61
D24 1750000711 S.VCP HVC350BTRF-E
D25 1750000711 S.VCP HVC350BTRF-E
D28 1790001670 S.DIO RB706F-40T106
FI1 2030000150 S.MLH FL-335 (46.350 MHz)
FI2 2020001530 CER CFWLB450KFFA-B0
X1 6070000191 S.DCR CDBKB450KCAY24-R0
X2 6050011931 S.XTL CR-781A (15.3 MHz)
X5 6050011730 S.XTL CR-765 (3.6864 MHz)
X6 6050011830 S.XTL CR-774 (12.288 MHz)
L7 6200007690 S.COL LQW2BHN18NJ03L
6200007700 S.COL LQW2BHN22NJ03L
L8 6200007690 S.COL LQW2BHN18NJ03L
6200007700 S.COL LQW2BHN22NJ03L
L8 6200007710 S.COL LQW2BHN27NJ03L
L9 6200007680 S.COL LQW2BHN12NJ03L
L11 6200007680 S.COL LQW2BHN12NJ03L
L12 6200007881 S.COL ELJRF 33NJFB
6200007921 S.COL ELJRF 15NJFB q, o, !1 , @0 only
L13 6200005510 S.COL ELJND R27J-F
q: GT [MTG-01] w: GT [MTE-01] e: GT [USA-01] r: GT [USA-02] t: GT [GEN-01]
y: GT [GEN-02] u: GT [EUR-01] i: GT [AUS-02] o: GT [CHN-01] !0 : GT [USA-04]
