Icom IC-F43GT Service Manual page 12

Jul. 2008
MODEL
IC-F43GT
(Ten-key)
IC-F44GT
(Ten-key)
IC-F43GS
(4-key)
IC-F44GS
(4-key)
Jul. 2008
SERVICE MANUAL
ADDENDUM
CONTENTS
PARTS LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
BOARD LAYOUTS . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
VOLTAGE DIAGRAM . . . . . . . . . . . . . . . . . . . . . . . . . 9
VERSION
VERSION
ABBREVIATION
MTG-01 [2]
USA-01 [4]
USA-02 [5]
USA-03 [9]
USA-04 [12]
GEN-01 [6]
GEN-02 [7]
AUS-02 [10]
CHN-01 [11]
CHN-02 [1]
SEA-01 [13]
MTE-01 [3]
EUR-01 [8]
MTG-01 [15]
USA-01 [18]
USA-02 [19]
USA-03 [23]
USA-04 [25]
GEN-01 [20]
GEN-02 [21]
AUS-02 [24]
MTG-02 [16]
CHN-01 [26]
CHN-02 [14]
MTE-01 [17]
EUR-01 [22]
FREQUENCY CHANNEL
RANGE SPACING
400–470 MHz
450−512 MHz
380−430 MHz
400–470 MHz 12.5/25.0 kHz
450−520 MHz
400–470 MHz
12.5/25.0 kHz
400–470 MHz
12.5/20.0/25.0 kHz
400–470 MHz
450−512 MHz
380−430 MHz
400–470 MHz
12.5/25.0 kHz
450−520 MHz
400–470 MHz
12.5/25.0 kHz
400–470 MHz
12.5/20.0/25.0 kHz
