2.3 Detaching the arm (for VESA wall
mount)
The detachable arm/base of this monitor is specially designed for VESA wall
mount.
To detach the arm/base:
1. Have the front of the monitor face down on a table.
2. Remove the rubbers in the four screw holes. (Figure 1)
3. Remove the base (Figure 2).
4. Use a screwdriver to remove the screw on the hinge (Figure 3), then remove
the hinge.
(Figure 1)
2
(Figure 3)
We recommend that you cover the table surface with soft cloth to prevent
damage to the monitor.
ASUS MG248 Series LCD Monitor
1
1
2
(Figure 2)
2-3
