- Page 1 MG248 series LCD Monitor User Guide...
- Page 2 Product warranty or service will not be extended if: (1) the product is repaired, modified or altered, unless such repair, modification of alteration is authorized in writing by ASUS; or (2) the serial number of the product is defaced or missing.
-
Page 3: Table Of Contents
Contents Notices......................iv Safety.information..................v Care.&.Cleaning................... vi Takeback.Services..................vii Chapter.1:..Product.introduction 1.1. Welcome!..................1-1 1.2. Package.contents................1-1 1.3.1 Front view ............... 1-2 1.3.2 Back view ................ 1-3 1.3.3 GamePlus Function ............1-4 1.3.4 GameVisual Function ............1-5 Chapter.2:..Setup 2.1. -
Page 4: Notices
Notices Federal.Communications.Commission.Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: • This device may not cause harmful interference, and • This device must accept any interference received including interference that may cause undesired operation. -
Page 5: Safety.information
Safety information • Before setting up the monitor, carefully read all the documentation that came with the package. • To prevent fire or shock hazard, never expose the monitor to rain or moisture. • Never try to open the monitor cabinet. The dangerous high voltages inside the monitor may result in serious physical injury. • If the power supply is broken, do not try to fix it by yourself. Contact a qualified service technician or your retailer. • Before using the product, make sure all cables are correctly connected and the power cables are not damaged. If you detect any damage, contact your dealer immediately. • Slots and openings on the back or top of the cabinet are provided for ventilation. Do not block these slots. Never place this product near or over a radiator or heat source unless proper ventilation is provided. • The monitor should be operated only from the type of power source indicated on the label. If you are not sure of the type of power supply to your home, consult your dealer or local power company. • Use the appropriate power plug which complies with your local power standard. • Do not overload power strips and extention cords. Overloading can result in fire or electric shock. • Avoid dust, humidity, and temperature extremes. Do not place the monitor in any area where it may become wet. Place the monitor on a stable surface. • Unplug the unit during a lightning storm or if it will not be used for a long period of time. This will protect the monitor from damage due to power surges. • Never push objects or spill liquid of any kind into the slots on the monitor cabinet. • To ensure satisfactory operation, use the monitor only with UL listed computers which have appropriate configured receptacles marked between 100-240V AC. -
Page 6: Care.&.Cleaning
AEEE.yönetmeliğine.uygundur Care & Cleaning • Before you lift or reposition your monitor, it is better to disconnect the cables and power cord. Follow the correct lifting techniques when positioning the monitor. When lifting or carrying the monitor, grasp the edges of the monitor. Do not lift the display by the stand or the cord. -
Page 7: Takeback.services
These documents are not part of the standard package. Takeback Services ASUS recycling and takeback programs come from our commitment to the highest standards for protecting our environment. We believe in providing solutions for our customers to be able to responsibly recycle our products, batteries and other components as well as the packaging materials. - Page 8 viii...
-
Page 9: Welcome
Thank you for purchasing the ASUS LCD monitor! The latest widescreen LCD monitor from ASUS provides a broader, brighter and crystal-clear display, plus a host of features that enhance your viewing experience. With these features, you can enjoy the convenience and delightful visual... -
Page 10: Front View
Monitor introduction 1.3.1. Front.view 5-way) button: • Turns on the OSD menu. Enacts the selected OSD menu item. • Increases/Decreases values or moves your selection up/down/left/right. • Displays the input selection bar when the monitor enters standby mode or displays the “NO SIGNAL“ message. button •... -
Page 11: Back View
DisplayPort. This port is for connection for a DisplayPort compatible device. Audio-in.port. This port connects PC audio source by the bundled audio cable. Earphone.jack. This port is only available when an HDMI/DisplayPort cable is connected. Kensington.lock.slot. Control.buttons. ASUS MG248 Series LCD Monitor... -
Page 12: Gameplus Function
1.3.3. GamePlus.Function The GamePlus function provides a toolkit and creates a better gaming environment for users when playing different types of games. The crosshair overlay with four different crosshair options lets you choose the one that best suits the game you're playing. -
Page 13: Gamevisual Function
In the Racing mode, the following function(s) are not user-configurable: Saturation, Skin Tone, Sharpness, ASCR. • In the sRGB mode, the following function(s) are not user-configurable: Brightness, Contrast, Saturation, Color Temp., Skin Tone, Sharpness, ASCR. ASUS MG248 Series LCD Monitor... - Page 14 Chapter 1: Product introduction...
-
Page 15: Assembling.the.monitor.arm/Base
Attach the base into the arm, making sure the tab on the arm fits into the groove on the base. Fix the base to the arm by fastening the bundled screw. We recommend that you cover the table surface with soft cloth to prevent damage to the monitor. ASUS MG248 Series LCD Monitor... -
Page 16: Adjusting.the.monitor
Adjusting the monitor • For optimal viewing, we recommend that you look at the full face of the monitor, then adjust the monitor to the angle that is most comfortable for you. • Hold the stand to prevent the monitor from falling when you change its angle. •... -
Page 17: Detaching.the.arm.(For.vesa.wall.mount)
Use a screwdriver to remove the screw on the hinge (Figure 3), then remove the hinge. (Figure 1) (Figure 2) (Figure 3) We recommend that you cover the table surface with soft cloth to prevent damage to the monitor. ASUS MG248 Series LCD Monitor... -
Page 18: Connecting.the.cables
Connecting the cables Connect the cables as the following instructions: •. To.connect.the.power.cord: Connect the power adapter securely to the monitor’s DC input. Connect one end of the power cord to the power adapter and the other end to a power outlet. •. -
Page 19: Osd.(On-Screen.display).Menu
R a c i n g Mode C i n e ma Mode R TS/ RPG Mode FP S Mode s R G B Mode U s e r Mo de Please refer to “1.3.4 GameVisual Function”. ASUS MG248 Series LCD Monitor... - Page 20 Blue.Light.Filter In this function, you can adjust the blue light filter level. ASUS MG248 Blue Light Filter RacingMode HDMI 1080p 60Hz L e ve l 0 L e ve l 1 L e ve l 2 L e ve l 3 L e ve l 4 •.
- Page 21 4:3 is only available when input source is in 4:3 format. 1:1 is not available when Adaptive-Sync is on. OverScan is only available for the HDMI input source. •. VividPixel:.Enhances the outline of the displayed picture and generates high-quality images on screen. ASUS MG248 Series LCD Monitor...
- Page 22 •. ASCR: Turns on/off the ASCR (ASUS Smart Contrast Ratio) function. •. Adaptive-Sync.(DisplayPort only) Allows an Adaptive-Sync supported* graphics source to dynamically adjust display refresh rate based on typical content frame rates for power efficient, virtually stutter free and low-latency display update.
- Page 23 •. Information: Shows the monitor information. •. Power.Indicator: Turn the power LED indicator on/off. •. Power.Key.Lock: Enables or disables the power key. •. All.Reset: “Yes” allows you to restore the default settings. ASUS MG248 Series LCD Monitor...
- Page 24 MyFavorite Loads/Saves all settings on the monitor. ASUS MG248 MyFavorite RacingMode HDMI 1080p 60Hz S e tt ing 1 S e tt ing 2 S e tt ing 3 Chapter 3: General Instructions...
-
Page 25: Specifications.summary
664 x 415 x 221 mm (package) Weight.(Esti.) 5.2 kg (Net); 7.7 kg (Gross) Multi-languages 21 languages (English, French, German, Italian, Spanish, Dutch, Portuguese, Russian, Czech, Croatian, Polish, Romanian, Hungarian, Turkish, Simplified Chinese, Traditional Chinese, Japanese, Korean, Thai, Indonesia, Persian) ASUS MG248 Series LCD Monitor... -
Page 26: Troubleshooting.(Faq)
Accessories. DisplayPort cable (optional), HDMI cable (optional), DVI (Dual-Link) cable (optional), Audio cable, power adapter, power cord, Driver and Manual disc, Quick start guide, warranty card Compliance.and.Standards UL/cUL, CB, CE, ErP, FCC, CCC, CU, RCM, BSMI, VCCI, RoHS, J-MOSS, WEEE, Windows 7 &... -
Page 27: Supported.operating.mode
60Hz 49.306KHz 1280x800 60Hz 49.702KHz 1280x800 75Hz 62.795KHz 1280x960 60Hz 60KHz 1280x1024 60Hz 63.981KHz 1280x1024 75Hz 79.976KHz 1366x768 60Hz 47.712KHz 1440x900 60Hz 55.469KHz 1440x900 60Hz 55.935KHz 1440x900 75Hz 70.635KHz 1680x1050 60Hz 64.674KHz 1680x1050 60Hz 65.29KHz ASUS MG248 Series LCD Monitor... - Page 28 Resolution.Frequency Refresh.Rate. Horizontal 1920x1080 60Hz 66.587KHz 1920x1080 60Hz 67.5KHz 1920x1080* (DVI/DP/HDMI) 85Hz 95.43KHz 1920x1080* (DVI/DP/HDMI) 100Hz 113.3KHz 1920x1080* (DVI/DP/HDMI) 120Hz 137.2KHz 1920x1080* (DVI/DP) 144Hz 158.11KHz 640x480P (HDMI) 59.94/60Hz 31.469KHz/31.5KHz 720x480P (HDMI) 59.94/60Hz 31.469KHz/31.5KHz 720x576P (HDMI) 50Hz 31.25KHz 1280x720P (HDMI) 50Hz 37.5KHz 1280x720P (HDMI) 59.94/60Hz...
- Page 29 (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Steve Chang / President Representative Person’s Name : Signature : Date : Feb. 25, 2016 Ver. 140331 ASUS MG248 Series LCD Monitor 3-11...
