4.5.1 Overall connection plan ROTEX HPSU compact

Fig. 4-16 Overall connection diagram - for electrical connection during device installation

FA ROTEX HPSU compact (V5) •

Set-up and installation

Explanation of symbols and abbreviations in this

chapter see tab. 4-2 and tab. 4-3.
