Specifications

Amplifier Section
Rated Output Power
All channels:
Maximum Output Power
Dynamic Power
THD (Total Harmonic Distortion)
Damping Factor
Input Sensitivity and Impedance
Output Level and Impedance
Phono Overload
Frequency Response
Tone Control
Signal to Noise Ratio
Speaker Impedance

Video Section

Input Sensitivity/Output Level and Impedance
Component Video Frequency Response
Tuner Section
FM Tuning Frequency Range
AM Tuning Frequency Range
Preset Channel
Digital Tuner (North American models only):
126
North American and Taiwan:
100 watts minimum continuous
power per channel, 8 ohm loads, 2
channels driven from 20 Hz to 20
kHz, with a maximum total
harmonic distortion of 0.08% (FTC)
115 watts minimum continuous power
per channel, 8 ohm loads, 2 channels
driven at 1 kHz, with a maximum total
harmonic distortion of 0.7% (FTC)
125 watts minimum continuous power
per channel, 6 ohm loads, 2 channels
driven at 1 kHz, with a maximum total
harmonic distortion of 0.1% (FTC)
European, Australian and Asian:
×
7 ch 160 W at 6 ohms, 1 kHz, 1 ch
driven (IEC)
×
7 ch 175 W at 6 ohms, 1 kHz, 1 ch
driven (JEITA)
240 W (3 Ω, Front)
210 W (4 Ω, Front)
120 W (8 Ω, Front)
0.08%
60 (Front, 1 kHz, 8 Ω)
200 mV/47 kΩ (LINE)
2.5 mV/47 kΩ, (PHONO MM)
200 mV/470 Ω (REC OUT)
70 mV (MM 1 kHz 0.5%)
5 Hz - 100 kHz/+1 dB - 3 dB (LINE)
±10 dB, 50 Hz (BASS)
±10 dB, 20 kHz (TREBLE)
106 dB (LINE, IHF-A)
80 dB (PHONO, IHF-A)
4 Ω - 16 Ω
1 Vp-p/75 Ω (Component and S-Video Y)
0.7 Vp-p/75 Ω (Component P
/C
B B
0.28 Vp-p/75 Ω (S-Video C)
1 Vp-p/75 Ω (Composite)
5 Hz - 100 MHz - 3 dB
North American and Taiwan:
87.5 MHz - 107.9 MHz
Others: 87.5 MHz - 108.0 MHz, RDS
North American and Taiwan:
530 kHz - 1710 kHz
Others: 522 kHz - 1611 kHz
40
SIRIUS
General
Power Supply
Power Consumption
Dimensions (W
Weight

■ Video Inputs

HDMI
Component
S-Video
Composite

■ Video Outputs

HDMI
Component
S-Video
Composite

■ Audio Inputs

Digital Inputs
Analog Inputs
■ Audio Outputs
Analog Outputs
Multichannel Pre Outputs
Subwoofer Pre Outputs
Speaker Outputs
Phones
, P /C )
R R
■ Control Terminal
MIC
RS232
IR Input
12 V Trigger Out
Specifications and features are subject to change without
notice.
North American and Taiwan:
AC 120 V, 60 Hz
Others: AC 220 - 240 V, 50/60 Hz
North American and Taiwan: 6.2 A
Others: 600 W
× ×
H D)
× ×
435 175 379 mm
× ×
17-1/8" 6-7/8" 14-15/16"
12.6 kg (27.8 lbs.)
IN 1, IN 2, IN 3, IN 4, IN 5,
AUX(Front)
IN 1, IN 2
DVD/BD, VCR/DVR, CBL/SAT,
GAME
DVD/BD, VCR/DVR, CBL/SAT,
GAME, AUX(Front)
OUT
MONITOR OUT
MONITOR OUT, VCR/DVR OUT
MONITOR OUT, VCR/DVR OUT
Optical: 2 (Rear), 1 (Front)
Coaxial: 3 (Rear)
DVD/BD, VCR/DVR, CBL/SAT,
GAME, AUX(Front), TV/TAPE, CD,
PHONO
TV/TAPE, VCR/DVR,
ZONE2 LINE OUT
7
2
Main (L, R, C, SL, SR, SBL, SBR, LH,
RH, LW, RW) + ZONE2 (L, R)
1
Yes
1
1
1
