G3512 and G3532
DOMINATORPLUS Grills
INSTALLATION and
SERVICING INSTRUCTIONS
This appliance must be installed and serviced by a competent person as stipulated by the
Gas Safety (Installation & Use) Regulations.
IMPORTANT
The installer must ensure that the installation of the appliance is in conformity with these instructions
and National Regulations in force at the time of installation. Particular attention MUST be paid to:
Gas Safety (Installation & Use) Regulations
Health And Safety At Work etc. Act
Local and National Building Regulations
Fire Precautions Act
The appliance has been CE-marked on the basis of compliance with the Gas Appliance Directive for
the Countries, Gas Types and Pressures as stated on the data plate.
WARNING
TO PREVENT SHOCKS, ALL APPLIANCES WHETHER GAS OR ELECTRIC,
:
MUST BE EARTHED.
On completion of the installation, these instructions should be left with the Engineer-in-Charge for
reference during servicing. Further to this, The Users Instructions should be handed over to the User,
having had a demonstration of the operation and cleaning of the Appliance.
IT IS MOST IMPORTANT THAT THESE INSTRUCTIONS BE CONSULTED BEFORE INSTALLING
AND COMMISSIONING THIS APPLIANCE. FAILURE TO COMPLY WITH THE SPECIFIED
PROCEDURES MAY RESULT IN DAMAGE OR THE NEED FOR A SERVICE CALL.
PREVENTATIVE MAINTENANCE CONTRACT
In order to obtain maximum performance from this unit we would recommend that a maintenance
contract be arranged with SERVICELINE. Visits may then be made at agreed intervals to carry out
adjustments and repairs. A quotation will be given upon request to the contact numbers below.
WEEE Directive Registration No. WEE/DC0059TT/PRO
At end of unit life, dispose of appliance and any replacement
parts in a safe manner, via a licenced waste handler.
Units are designed to be dismantled easily and recycling of all
material is encouraged whenever practicable.
Falcon Foodservice Equipment
HEAD OFFICE AND WORKS
Wallace View, Hillfoots Road, Stirling. FK9 5PY. Scotland.
SERVICELINE CONTACT
Phone: 01438 363 000
Fax: 01438 369 900
Detailed recommendations are contained in
Institute of Gas Engineers published documents:
IGE/UP1, IGE/UP/2
BS6173 and BS5440
T100787 Ref.2

Advertisement

loading

Related Manuals for Falcon Dominator Plus G3512

Summary of Contents for Falcon Dominator Plus G3512

  • Page 1 Units are designed to be dismantled easily and recycling of all material is encouraged whenever practicable. Falcon Foodservice Equipment T100787 Ref.2 HEAD OFFICE AND WORKS Wallace View, Hillfoots Road, Stirling. FK9 5PY. Scotland.
  • Page 2 IMPORTANT INFORMATION Warranty Policy Shortlist Warranty does not cover :- Correcting faults caused by incorrect installation of a product. Where an engineer cannot gain access to a site or a product. Repeat commission visits. Replacement of any parts where damage has been caused by misuse. Engineer waiting time will be chargeable.

  • Page 3: Section 1 - Installation

    SECTION 1 - INSTALLATION UNLESS OTHERWISE STATED, PARTS WHICH HAVE BEEN PROTECTED BY THE MANUFACTURER ARE NOT TO BE ADJUSTED BY THE INSTALLER. 1.1 MODEL NUMBERS, NETT WEIGHTS 1.3 VENTILATION and DIMENSIONS Adequate ventilation must be provided to supply sufficient fresh air for combustion and allow easy removal of Width Depth Height...

  • Page 4: Section 2 - Assembly And Commissioning

    8.55 32,100 Note G3532 grill 6.65 25,100 Mounting accessories are available. Contact Falcon Sales, an equipment distributor or place of purchase. 1.8 INJECTOR DIAMETERS - Natural Gas a) Unpack unit and place it in position using separate Model Main burner(s)

  • Page 5: Section 3 - Servicing And Conversion

    2.5.2 Setting The Gas Pressure Ensure gas supply is disconnected before commencing. a) Check pressure during commissioning. A suitable Only reconnect gas supply after all conversion work has gauge must be connected to test point located on been completed. injector manifold (situated behind front control facia). Natural to Propane b) Turn on main gas valve at supply to unit.

  • Page 6: Section 4 - Spares And Accessories

    3.3 CLEANING 3.6 GAS TAPS 3.3.1 Burners Note Burners should be cleaned periodically to maintain Plugs and bodies are machined in pairs and are maximum performance detailed User therefore not interchangeable. Always clean one tap at Instructions. Burners are best cleaned with a wire brush; a time.
