Summary of Contents for Ski-Doo 2006 MX Z

  • Page 2: Safety Warning

    In USA, products are distributed by BRP US Inc. In Canada, products are distributed by Bombardier Recreational Prod- ucts Inc. The following are trademarks of Bombardier Recreational Products Inc. or its subsidiaries. ® SKI-DOO ROTAX ‘ ® ® MX-Z Printed in Canada. (mmo2006-007 DR) ®™...
  • Page 3 ® Dear 2006 MX Z X 440 owner, informations in the 2006 REV Series Operator's Guide (P/N 520 000 547) also apply to your MX Z X 440 except for the following. __________________________...

  • Page 4: Table Of Contents

    TABLE OF CONTENTS VEHICLE INFORMATION RACING APPLICATION ......... . . CONTROLS/INSTRUMENTS/EQUIPMENT .

  • Page 5: Vehicle Information

    VEHICLE INFORMATION __________________________...

  • Page 6: Racing Application

    RACING APPLICATION For racing application, the main jets have to be replaced according to the chart found on belt guard. __________________________...

  • Page 7: Controls/Instruments/Equipment

    CONTROLS/INSTRUMENTS/EQUIPMENT NOTE: See description of numbered items in 2006 REV Series Op- erator’s Guide (P/N 520 000 547) except for the following. 1) Brake/Parking Brake Pilot Lamp (Red) This pilot lamp is disabled (does not light up) on the MX Z X 440. WARNING Make sure parking brake is fully disengaged before operating the snowmobile.

  • Page 8: Tether Cord Cut-Out System

    12) Tether Cord Cut-Out System General The tether cord cut-out system prevents snowmobile to runaway, if the operator accidently falls off, by shutting off the engine. WARNING Always disconnect tether cord when leaving vehicle unattend- ed and keep in a secured location. Operation Attach tether cord to clothing eyelet then snap tether cord cap over post before starting engine.

  • Page 9: Fuel Level

    mmo2006-007-002_a 1. Low beam 2. High beam 18) Fuel Level Open fabric door to see the fuel level through the translucent fuel tank. 1. Fabric door __________________________...

  • Page 10: Pre-Heat Switch

    43) Pre-Heat Switch Racing Application Only NOTE: This switch is disabled (not operative) on vehicles modified for warranty validation. To run engine with 91 octane number fuel (R + M)/2 inside North America (95 RON outside North America), this switch must be disabled. 1.

  • Page 11: Recommended Fuel And Oil

    RECOMMENDED FUEL AND OIL Fuel Vehicles with Valid Warranty (Pre-Heat Switch Disabled) Use premium unleaded gasoline, available from most service stations or oxygenated fuel containing a maximum total of 10% of ethanol or methanol or both. The gasoline used must have the following recommended minimum octane number.
  • Page 12 Oil must be mixed with fuel at the ratio of 33:1 in a jerrycan then, be poured in the fuel tank. Refer to chart below as a guideline to properly premix oil with fuel. Use only two-stroke engine injection oil, sold by authorized SKI-DOO dealers. MODEL...
  • Page 13 CAUTION: The XP-S synthetic 2-stroke oil is specially formu- lated and tested for the severe requirements of the 453 engine. Use of any other brand two-stroke oil may void the limited war- ranty. Use only XP-S synthetic 2-stroke oil. There is no known equivalent on the market for the moment.
  • Page 14 _________________________...

  • Page 15: Operating Instructions

    OPERATING INSTRUCTIONS Engine Starting Procedure • Re-check throttle control lever operation. • Ensure that the emergency cut-out switch is in the ON position. • Ensure the tether cut-out cap is in position and that the cord is attached to your clothing. •...
  • Page 16 1. Low speed compression adjuster (flat screwdriver) 2. High speed compression adjuster (17 mm wrench) Center and Front Springs CAUTION: Make sure that center spring and both front springs are still preloaded when front of vehicle is off the ground. Max- imum spring preload is 25 mm (1 in).

  • Page 17: Specifications

    SPECIFICATIONS NOTE: Because of its ongoing commitment to product quality and innovation, BRP reserves the right, at any time, to make changes in design and specifications and/or to make additions to, or improve- ments in its products without imposing any obligation upon itself to install them on its products previously manufactured.
  • Page 18 MODEL MX Z X 440 30 - 35 mm Deflection (1-3/16 - 1-3/8 in) Track tension Force 7.3 kg (16 lb) Equal distance between Track alignment edges of track guides and slider shoes 417 300 297 Drive belt part number Wear limit width mm (in) 34.7 (1-3/8)
  • Page 19 MODEL MX Z X 440 XP-S synthetic chaincase oil Chaincase oil type (P/N 413 803 300) (12 x 355 mL) Ethyl glycol/water mix (50% coolant, 50% distilled water) Mixture Use coolant specifically designed for aluminum Coolant engines (P/N 413 711 802) Premix (16 x 1 L) XP-S mineral injection...
  • Page 20 _________________________...

  • Page 21: Maintenance Information

    MAINTENANCE INFORMATION __________________________...

  • Page 22: Engine System

    ENGINE SYSTEM Coolant Pump Shaft Oil Reservoir CAUTION: Vehicle must be on a level surface before checking any fluid levels. Use XP-S mineral injection oil (P/N 413 802 900) (12 x 1 L). Fill up to mark. Cooling System CAUTION: Vehicle must be on a level surface before checking any fluid levels.

  • Page 23: Drive System

    DRIVE SYSTEM Brake Fluid Level CAUTION: Vehicle must be on a level surface before checking any fluid levels. Check brake fluid (DOT 4) in reservoir on handlebar for minimum lev- el. Add recommended fluid (DOT 4) as required. Refer to SPECIFI- CATIONS for recommended fluid.
  • Page 24 WRONG TOOL — DO NOT USE ON MX Z X 440 PROPER TOOL TO BE USED ON MX Z X 440 _________________________...
  • Page 25 PROPER TOOL OPENING DRIVEN PULLEY OF MX Z X 440 __________________________...
  • Page 26 _________________________...

  • Page 27: Warranty

    WARRANTY __________________________...

  • Page 28: Limited Warranty Validation

    LIMITED WARRANTY VALIDATION Because of its racing application, the 2006 MX Z X 440 is shipped from the factory with high compression ratio (CR) combustion cham- ber inserts installed. To validate limited warranty coverage and to run engine with 91 oc-...
