Chapter 1: Product Introduction
DI/O & Function Description
55
O
Rotate
360
O
Rotate
Note:
Default: If the default button has been pressed for 1~4 seconds, the camera
will be re-started and all the settings will be reverted to default except IP
address. If pressed for over 5 seconds, the camera will be re-started and all
the settings will be reverted to default including IP address.
Reset: Press to reset the camera.
Copyright © 2013 NEXCOM International Co., Ltd. All Rights Reserved.
SB Module
MB Module
Dehumidi er
Packet
Bracket
Latch
8 PCS LED IR
Illuminator
Board Plate
Line-out Line-in
Ethernet / PoE
Micro SD
Reset
Heater module
DI/O
5 4 3 2 1
DI/O
DI/O Pin Definition & Waterproof
Connector Description
Pin
1
2
3
4
DC12V/
AC24V
5
Default
Gasket
Main body
4
5 4 3 2 1
DI/O
Description
ALM_IN (+)
ALM_IN (-)
ALM_out_NC
ALM_out_COM
ALM_out_NO
Tightening
collar
Waterproof
connector
Seal nut
Strain relief
Gasket
Main body
NCr-302-VHR User Manual
