WEBVIEWER*
S e t u p > I m a g e Q u a l i t y
A d j u s t t h e M E G A p i x ® P A N O ™ c a m e r a ' s I m a g e s e t t i n g s . C h a n g e s w i l l
a p p l y t o a l l f o u r ( 4 ) s e n s o r s .
1. EXPOSURE SETTING
a. Metering Mode – This is the region of interest for the exposure settings. The camera's
exposure will be determined by the selected Metering Mode, affecting the camera's bright
levels. Select an option from the available drop-down options.
b. Custom Metering Area – If 'Custom' is selected in the Metering Mode, adjust the Metering
Mode position in the camera's FoV. Select an option from the available drop-down options.
c. Exposure Target Factor – Higher values mean the image will settle to something brighter.
Lower values mean the image will appear
darker.
d. Shutter Time Limit – Set the shutter's
minimum and maximum speeds from the
available options. Select 1/7.5 to set more
exposure time to light. This setting is used
to make movements look natural/ unfrozen.
Select 1/8000 to set less exposure time to
light. This settings is used to catch fast
moving objects.
e. Sensor Max Gain – Maximum light gain
settings in low light conditions. Select from
26dB (least light), 30dB, 36dB to 42dB
(most light). Default value is 36dB
f. Fastest Exposure – Set the shutter speed
from the available options between 1/25
and 1/32000. Select 1/25 to set more
exposure time to light. This setting is used
to make movements look natural/ unfrozen.
Select 1/32000 to set less exposure time to
light. This settings is used to catch fast
moving objects.
