WEBVIEWER*
S e t u p > I m a g e Q u a l i t y
A d j u s t t h e M E G A p i x ® P A N O ™ c a m e r a ' s I m a g e s e t t i n g s . C h a n g e s w i l l
a p p l y t o a l l f o u r ( 4 ) s e n s o r s .
1. BASIC SETTINGS
a. Active Noise Filter (Smart 3D DNR™ Digital Noise Reduction) – Control the level of noise in
the image. Select from Off, Low, Medium and High. The higher the level, the more the camera
will manipulate the image to reduce digital noise, but it will also increase lagging when motion
occurs. By default, the 3D DNR settings are set to Low.
b. Local Exposure – Set the camera's exposure time from Auto or manually from 1X ~ 4X.
c. BLC (Backlight Compensation) – This setup option allows you to adjust the camera's capture
of light when there is strong backlight in the
camera's Field of View [FoV]. By default,
BLC is set to OFF.
d. Exposure Control – In case the camera's
image is flickering, adjust the value on this
setting. By Default, Exposure Control is set
to 60GHz.
2. Press 'Preview' to review changes before
saving.
3. Press 'Apply' to save changes.
4. Press 'Cancel' to exit without saving.
5. Press 'Reset Factory' to return all settings to
their default values.
