TECHNICAL SPECIFICATIONS – ENGINE
ENGINE
Design
Displacement
Bore / Stroke
Compression ratio
Fuel
Valve timing
Valve diameter
Valve clearance, cold
Crankcase bearing
Conrod bearing
Piston pin bearing
Piston
Piston rings
Engine lubrication
Engine oil
Quantity of engine oil
Primary drive
Clutch
Transmission
Gear ratio
Ignition system
Ignition timing
Generator
Spark plug
Electrode distance
Cooling system
Cooling liquid
Starting aid
#
JASO T903 MA
TEMPERATURE
0°C
32°F
5W/40
Engine oil
Only use fully synthetic engine oils that meet the JASO
MA quality requirements (see information on the can).
KTM recommends Motorex Power Synt 4T in the 10W/50
viscosity (for temperatures over 0°C, 32°F) or 5W/40
(for temperatures under 0°C, 32°F).
950 LC8
Liquid-cooled, 2-cylinder 4-stroke engine with 75° V arrangement with balancer shaft and electric starter
942 ccm
100/60 mm
11.5:1
unleaded premium fuel with at least RON 95
4 valves controlled over bucket tappet and 2 camshafts, camshaft drive with gears/chain
Intake: 38 mm Exhaust: 33 mm
Intake: 0,15 mm Exhaust: 0,25 mm
Friction bearings (2 main bearings / 1 supporting bearing)
Friction bearing
Dual-fuel bearing
Light alloy – forged
1 compression ring, 1 taper face ring, 1 single-piece oil scraper ring with spiral-type expander
Dry sump with 2 trochoidal pumps (pressure pump and suction pump)
SAE 5W/40, 10W/50 (Motorex Power Synt 4T) #
approx. 3.0 liters during oil/filter change
Straight-toothed spur wheels 67 : 35
Multi-disc clutch in oil bath
6-speed claw shifted
1st gear 35:12
2nd gear 32:15
3rd gear 30:18
4th gear 27:20
5th gear 27:24
6th gear 26:27
breakerless transistorized electronic ignition system with digital ignition advance
5° from TDC at 1200 rpm
12V 450W at 6000 rpm
NGK CR 8 EK
0.6 mm
liquid cooled, permanent circulation of cooling liquid through water pump
2.1 liters, 50% antifreeze, 50% water, at least –25° C
0.9 kW electric starter
BASIC CARBURETOR SETTING
Type of carburetor
Main jet
Main air jet
Idling jet
Idle air jet
Idle air cutoff jet
Jet needle
10W/50
Needle position
Mixture control screw open
Starting jet
»
(ROZ 80 - 94 for other ignition curve)
CVRD 43
155 (front) / 160 (rear)
40
42
50
80
NDFB
2nd from top
2 1/4 turns
68
49
