Page 1: Vacuum Cleaner
VCDC08** VCDC12** VCDC15** VCDC20** Vacuum Cleaner user manual ✻ Before operating this unit, please read the instructions carefully. English ✻ For indoor use only. imagine the possibilities Thank you for purchasing a Samsung product. - Page 2 safety information SAFETY INFORMATION • Before operating the appliance, please read this manual thoroughly and retain it for your reference. WARNING • Because these following operating instructions cover various models, the characteristics of your vacuum cleaner may differ slightly from those WARNING described in this manual.
- Page 3 safety information IMPORTANT SAFEGUARDS 1. Read all instructions carefully. Before switching on, make sure that the voltage of your electricity supply is the same as that indicated on the rating plate on the bottom of the cleaner. 2. WARNING : Do not use the vacuum cleaner when rug or floor is wet.
- Page 4 machine before unplugging from the electrical outlet. Disconnect the plug from the electrical outlet before changing the dust bag or dust container. To avoid damage, please remove the plug by grasping the plug itself, not by pulling on the cord. 8.
-
Page 5: Table Of Contents
contents ASSEMBLING THE CLEANER ON/OFF Switch OPERATING THE CLEANER Power Cord Power-Control Using accessory MAINTAIN TOOLS AND FILTER Maintain floor tools Emptying the dust bin When to clean the dust pack Cleaning the dust pack Cleaning the outlet filter Change the battery (option) TROUBLESHOOTING contents _05... - Page 6 assembling the cleaner OPTION OPTION • Features may vary according to model. • Please do not press the button of dust bin handle when carrying machine. • For storage, park the floor nozzle. 06_ assembling...
-
Page 7: On/Off Switch
operating the cleaner ON/OFF SWITCH 1) BODY CONTROL TYPE 2) HANDLE CONTROL TYPE • When removing the plug from the electrical outlet, grasp the plug, not the cord. CAUTION POWER CORD operating _07... -
Page 8: Power-Control
POWER-CONTROL BODY-CONTROL TYPE / ON/OFF TYPE • HOSE To reduce suction for cleaning draperies, small rugs, and other light fabrics, pull the tap air until the hole is open. • BODY (BODY-CONTROL TYPE ONLY) MIN = For delicate surface e.g. net curtains. -
Page 9: Using Accessory
maintain tools and filter USING ACCESSORY Pipe (Option) • Adjust the length of the telescopic pipe by sliding the length control button located in the center of the telescopic pipe back and forth. • To check for blockages, separate the telescopic pipe and adjust to shorten. -
Page 10: Maintain Floor Tools
maintain tools and filter MAINTAIN FLOOR TOOLS 2-Step Brush (Option) • Adjust the inlet lever according to the floor • Remove waste matter surface. completely if the inlet is blocked. Carpet Cleaning Carpet Cleaning Floor Cleaning Floor Cleaning Power Pet Plus Brush (Option) For improved pickup of pet hair and fibre on... - Page 11 Pet Brush (Option) For improved pick-up of pet hair and fibre on carpets. Frequent vacuuming of hair or pet fur may cause a falling-off of the rotation due to matters tangled around the drum. In this case, clean the drum with care. Blanket brush (Option) Clogs on turbine keep brush from turning, thus need to be unclogged as follows.
- Page 12 maintain tools and filter Mini turbo brush (Option) - To replace brush-roller 1. If a clog is present or debris is visible, unscrew the two screws on the back of the Mini turbo brush to remove the faceplate and clear any obstructions. 2.
-
Page 13: Emptying The Dust Bin
EMPTYING THE DUST BIN 1. Once dust reaches the 2. Take the dust bin out 3. Separate the dust bin dust full mark, or sution by pressing the button. cover. is noticeably reduced during cleaning, empty the dust bin. click click 4. -
Page 14: When To Clean The Dust Pack
maintain tools and filter WHEN TO CLEAN THE DUST PACK If suction is noticeably reduced during cleaning, please check the dust pack as indicated below. Turn the vacuum power to ‘MAX’. HANDLE CONTROL TYPE HANDLE CONTROL TYPE BODY CONTROL TYPE BODY CONTROL TYPE If suction is noticeably reduced with the inlet floating 10cm above flat floor, clean it. -
Page 15: Cleaning The Dust Pack
CLEANING THE DUST PACK 1. Remove the dust bin and dust pack as shown. 2. Remove the sponge and filter from the dust pack. 3. Wash the sponge and the filter of the dust pack with water. 4. Let the sponge and filter dry in the shade for more than 12 hours. -
Page 16: Cleaning The Outlet Filter
Replacement filters are available at your local OPTION Samsung distributor. CHANGE THE BATTERY (OPTION) 1. When the vacuum cleaner dows not work, replace the batteries. If the problem persists, please contact our authorized dealer. - Page 17 troubleshooting PROBLEM SOLUTION • Check cable, pulg and socket. Motor dows not start. • Leave to cool. Suction force is gradually • Check for blockage and remove. decreasing. • Pull the cord out 2-3m and push down the cord Cord does not rewind fully. rewind button.
- Page 18 [English] According to Commission Regulation (EU) No 665/2013 and No 666/2013 Supplier Samsung Electronics., Co. Ltd Model VCDC08RH VCDC08SH VCDC15RH VCDC15SH VCDC15QV Energy Efficiency Class Annual Energy 34.0 52.0 Consumption (kWh/yr) Carpet Cleaning Performance Class Hardfloor Cleaning Performance Class...
- Page 19 memo...
- Page 20 If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care center. COUNTRY CALL OR VISIT US ONLINE AT 0845 SAMSUNG (7267864) www.samsung.com/uk SOUTH AFRICA 0860 7267864(SAMSUNG) www.samsung.com/za DJ68-00665A-07...
