Cub Cadet CC5090 Operator's Manual

Quick Instructions to
Assemble Straight
Shaft String
Trimmers
for complete instructions, refer to the
Assembly Instructions of the unit's
manual.
Quick Instructions
to Start Engine
for complete instructions, refer to the
Starting/ Stopping Instructions of the
unit's manual.
Quick Instructions to
®
Replace SplitLine
Trimmer Line
For replacement line, call
1-877-282-8684 or go to an
authorized service dealer.
For complete line installation,
refer to Line Replacement
replacement section of the
unit's manual.
Wind line tightly in direction of arrow.
Split other end of SplitLine
IMPORTANT: READ OPERATOR'S MANUAL THOROUGHLY AND FOLLOW THE SAFE OPERATION PRACTICES BEFORE OPERATING THE UNIT.
NEED HELP?
PART NO. 769-04919 P00
Operator's Manual
Read and understand all instruction, warning and danger labels on the unit.
Install the cutting attachment shield on
the shield mount by inserting the three
(3) screws into the shield mount. Tighten
securely with a flat blade screwdriver.
NOTE: The cutting shield MUST be
installed when operating the unit as a
trimmer.
Unleaded
Gasoline
Press primer bulb 10x and move
choke lever to Position 1.
Fill fuel tank with fresh fuel.
Choke Lever
Move choke lever to
Position 2.
Push 6"-7" ends into
®
back 6"-7". the holding slots.
CALL 1–877-282-8684 IN U.S. OR 1–800–668–1238 IN CANADA
DO NOT RETURN THIS PRODUCT
For Assistance please call 1-877-282-8684 (U.S.) or 1-800-668-1238 (Canada)
or visit www.cubcadet.com or www.cubcadet.ca
Remove the cap from the Place D-handle over the shaft housing and
boom. Push the bottom add-on onto the bottom clamp at minimum of 6
into the coupler. Turn the knob inches from the end of the shaft grip.
clockwise to tighten. Tighten the screws with an appropriate
tool until the handle is secure.
Choke Lever
Primer
Bulb
Crouch in starting
position.
Choke Lever
3 to 5 X
Continue to squeeze
Pull starter rope 3 to 5 times.
throttle control and
Making sure to keep throttle
move the choke
squeezed, run unit for 30-60
lever to Position 3.
seconds to warm up.
Spool
Spring
Inner
Reel
Bump
Knob
Unscrew bump knob Insert 10' of 0.105"SplitLine
clockwise. Remove hole in top of reel. Pull most of line
inner reel and spring. through hole until 3"-4" remains.
Insert lines through eyelets in spool.
Insert spring and reel into spool.
CC5090
4-Cycle Trimmer/
Brushcutter
6 in.
Min.
Tip unit so that the back of the engine
is facing up in a vertical position.
Remove the oil fill plug from the
crankcase and pour the entire bottle
of 4-cycle oil into the oil fill hole.
NOTE: Do not mix gas and oil
PRESS the lockout in;
Pull the rope 5 times.
SQUEEZE and HOLD throttle
control for ALL further steps.
DIDN'T START?
If unit still fails to start, refer
to the operator's manual for
Continue squeezing the
throttle control and run unit for troubleshooting information
additional 30 to 60 seconds to
complete warm up. The unit
may be used during this time.
3"-4"
®
through Bend short end and push it
into the other hole. Pull tight.
Hold the inner reel in place. Pull lines firmly to release
Tighten Bump Knob from holding slots.
counterclockwise.
5 X
Repeat these instructions.
additional starting and
(6/09)
