- Page 1 Series EBD930F 1080p Full High Definition True Day/Night Outdoor IR Ball Camera User’s Manual Copyright © EverFocus Electronics Corp. Release Date: February 2016...
- Page 2 Precautions Do not install the camera near electric or magnetic fields. Install the camera away from TV/radio transmitters, magnets, electric motors, transformers and audio speakers since the electromagnetic fields generated from these devices may distort the video image or otherwise interfere with camera operation. Never disassemble the camera beyond the recommendations in this manual nor introduce materials other than those recommended herein.
- Page 3 Safety Notice Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
-
Page 4: Table Of Contents
Contents 1. Introduction........................5 Packing List ........................5 Features .......................... 5 2. Cable Description ......................6 3. Installation ........................7 Installation and Adjustment ................... 7 4. Configuration in the OSD Menu ..................11 5. Specifications ........................15... -
Page 5: Introduction
EBD930F eZ.HD IR Mini Ball Camera 1. Introduction The EverFocus eZ.HD Series EBD930F ball camera is equipped with a 1/2.9" SONY 2.24M pixels CMOS sensor and providing high resolution of 1080p. Featured with the Digital Wide Dynamic Range (D-WDR) function, the camera can provide clear images even under back light circumstances where intensity of illumination can vary excessively. -
Page 6: Cable Description
EBD930F eZ.HD IR Mini Ball Camera 2. Cable Description Name Descriptions Power Cable Connect to a 12VDC power source. 1080p, 720p and 960H output, using a 75 Ohm BNC-type Video Output coaxial cable. Optional power pigtail cable. The red wire is positive (+); DC Power Pigtail Cable while the black wire is negative (-). -
Page 7: Installation
EBD930F eZ.HD IR Mini Ball Camera 3. Installation 3.1 Installation and Adjustment For Ceiling Mount / Wall Mount users: Stick the Template Plate on the position where you want to attach the camera. Drill four holes according to the supplied Template Plate, and insert the supplied Plastic Anchors into the holes. - Page 8 EBD930F eZ.HD IR Mini Ball Camera Unscrew the outer housing by twisting it counterclockwise and then remove the outer housing from the camera base. Screw the base plate to the wall or ceiling with supplied four Screws and Hexagon Wrench. a.
- Page 9 EBD930F eZ.HD IR Mini Ball Camera b. If you want to wire the cables through the wall, attach and screw the camera base to the ceiling / wall. Then attach the camera body to the base plate. Connect the camera to the 12VDC power source using the supplied DC Power Pigtail Cable or power adapter.
- Page 10 EBD930F eZ.HD IR Mini Ball Camera Note: The function button is using to control direction, and also to switch video format and video output. Please follow the detailed instruction as below to switch the camera to: Switch between 1080p and 720p (Default, 1080p): Press Upward for 5 Seconds ...
-
Page 11: Configuration In The Osd Menu
EBD930F eZ.HD IR Mini Ball Camera 4. Configuration in the OSD Menu You can use the Joystick on the rear panel of the camera to configure camera settings in the OSD menu. For details on the OSD menu structure as below: Main Sub Menu Sub Menu / Function... - Page 12 EBD930F eZ.HD IR Mini Ball Camera Indoor Outdoor Blue 1-500 Manual 0-100 D→N(Delay) 0-60 N→D(Delay) 0-60 D→N(AGC) 1-255 D→N(Delay) 0-60 Auto N→D(AGC) 1-255 Day & N→D(Delay) 0-60 Night Color Burst Off/On Level 0-15 IR Smart Position, Size,↑,↓, Area →,← IR PWM 0-100 2DNR Middle/Low/Off/High...
- Page 13 EBD930F eZ.HD IR Mini Ball Camera Time 1-15 Default Select Area1,Area2,Area3,Area4 Position, Size,↑,↓, Color →,← Display Position, Size,↑,↓, Mosaic →,← Privacy Position, Size,↑,↓, →,← White, Black, Red, Blue, CYAN, Color Yellow, Green 1.00,0.75,0.50, Trans 0.25 Default Language ENG/CHN1/CHN2/GER/FRA/ITA/SPA/POL/RUS/POR/NED/TUR Live DPC AGC level 0-255 Level...
- Page 14 EBD930F eZ.HD IR Mini Ball Camera Baud Rate 2400,4800,9600,19200 ,38400 Level 0-10 Sharpness Auto Start AGC 0-255 End AGC 0-255 Black Level 0-60 Blue Gain 0-100 Red Gain 0-255 Adjust User,0.45,0.50,0.55,0.60,0.65,0.70,0. Monitor Gamma 75,0.80,0.85,0.90, 0.95,1.00 Blue Gain 0-100 Red Gain 0-100 Off/On Video.
-
Page 15: Specifications
EBD930F eZ.HD IR Mini Ball Camera 5. Specifications EBD930F Pickup Device 1/2.9" Sony 2.24M pixels CMOS Video Format NTSC and PAL(can be switched via OSD) Effective Pixels 1920 (H)x1080(V) Scanning System Progressive Scan Sensitivity 0 lux with IR on Electronic Shutter AUTO/Manual (X30~1/50,000)/FLK Gamma Correction 0.45... - Page 16 FAX: +81 3 5625 8189 www.everfocus.com www.everfocus.co.jp sales@everfocus.com info@everfocus.co.jp Ihr EverFocus Produkt wurde Your EverFocus product is designed and entwickelt und hergestellt mit manufactured with high quality materials qualitativ hochwertigen Materialien and components which can be recycled und Komponenten, die recycelt und and reused.
