Adjusting the Trend Recording Format (TREND, Dot-printing
model)
Key Operation
ESC
DISP
3 sec
PRINT
CH UP
PRINT
CH UP
ESC
CH UP DISP
3 sec
NOTE
If you press the [ESC] key in the middle of setting, the indication returns to the

6.7 Adjusting the Trend Recording Format (TREND, Dot-printing model)

This recorder prints in FIX or AUTO mode.
In FIX mode, dot printing is performed with a constant interval regardless of the chart
speed (approx. 20 sec).
AUTO mode is provided to prevent the chart from being damaged during repetitive dot
printing. This mode is useful for low chart speeds. The chart is protected from damage
because the printout timing changes with the chart speed (approx. 20 to 90 sec).
Single printout
(0.5mm dia.)
Repetitive dot
printing
FIX
The initial value is 'AUTO'. To set the trend recording mode, proceed as follows:
Indication
Press the [DISP] key for three seconds to enter the SET mode.
Select the [
the [ENT] key.
Specify AUTO or FIX using the [
[ENT] key.
[
[DISP] key for three seconds to return to the OPERATION
mode.
[ ] and already set data will be aborted.
AUTO
Discription
] display using the [
] key. Then press the
] is displayed and the setting is completed. Press the
] key, and press
