VIESMANN
Installation and service instructions
for contractors
Vitodens 200-W
Type B2HA, 125 and 150 kW
Wall mounted gas condensing boiler
Natural gas and LPG version
For applicability, see the last page
VITODENS 200-W
Please keep safe.
5623 520 GB
1/2015

Advertisement

Table of Contents
loading

Related Manuals for Viessmann VITODENS 200-W

Summary of Contents for Viessmann VITODENS 200-W

  • Page 1 VIESMANN Installation and service instructions for contractors Vitodens 200-W Type B2HA, 125 and 150 kW Wall mounted gas condensing boiler Natural gas and LPG version For applicability, see the last page VITODENS 200-W Please keep safe. 5623 520 GB 1/2015...
  • Page 2 ■ Statutory regulations for the protection of the envi- For replacements, use only original spare parts ronment supplied or approved by Viessmann. ■ Codes of Practice of the relevant trade associations All current safety regulations as defined by DIN, EN, Safety instructions for operating the system ■...

  • Page 3: Safety Instructions

    Safety instructions Safety instructions (cont.) If you smell flue gas Danger Flue gas can lead to life threatening poisoning. ■ Shut down the heating system. ■ Ventilate the installation site. ■ Close doors to living spaces to prevent flue gases from spreading. Flue systems and combustion air Ensure that flue systems are clear and cannot be sealed, for instance due to accumulation of conden-...

  • Page 4: Table Of Contents

    Index Index 1. Information Symbols ....................Intended use ..................Product information ................Vitodens 200-W, type B2HA ............... ■ 2. Preparing for installation ........................3. Installation sequence Mounting the boiler and making the connections ........10 Removing boiler from packaging and levelling ........10 ■...
  • Page 5 External connections ......128 – 12. Commissioning/service ........................129 reports 13. Specification ........................130 14. Certificates Declaration of conformity ............... 131 Declaration of Conformity for the Vitodens 200-W ......131 ■ Manufacturer's certificate according to the 1st BImSchV [Germany] ..131 15. Keyword index ........................132...

  • Page 6: Symbols

    Information Symbols Symbol Meaning Reference to other document containing further information Step in a diagram: The numbers correspond to the order in which the steps are carried out. Warning of material losses and environ- mental pollution Live electrical area Pay particular attention. Component must audibly click into place.

  • Page 7: Product Information

    Preset for operation with natural gas E and natural gas For conversion to LPG P (without conversion kit), see page 31. In principle the Vitodens 200-W may only be delivered to countries listed on the type plate. For deliveries to alternative countries, approved contractors must arrange individual approval on their own initiative and in accordance with the law of the country in question.
  • Page 8 Preparing for installation Preparing for installation Dimensions and connections Please note To prevent appliance damage, connect all pipework free of load and torque stress. 165.5 165.5 Fig.1 Safety valve Cable entry area at the back Expansion vessel connection G1 Without connection set (accessories) Boiler flow 54 mm With connection set (accessories)
  • Page 9 Preparing for installation Preparing for installation (cont.) Preparing for boiler installation Note This boiler (IP rating IP X4 D) is approved for installa- tion in wet rooms inside safety zone 1 in accordance with DIN VDE 0100, providing the occurrence of hosed water can be ruled out.

  • Page 10: Mounting The Boiler And Making The Connections

    Installation sequence Mounting the boiler and making the connections Removing boiler from packaging and levelling Fig.2 1. Remove packing cushions and keep them safe. 3. Remove the front panel. They are used as a support during levelling. 4. Push packing cushions onto the underside of the 2.

  • Page 11: Fitting The Wall Mounting Bracket

    Installation sequence Mounting the boiler and making the connections (cont.) Fig.3 9 mm drilled holes for attaching lifting gear Please note To prevent damage, do not level boiler without packing cushions. Level boiler with pallet. Fitting the wall mounting bracket Note The enclosed screws and rawl plugs are only suitable for concrete.
  • Page 12 Installation sequence Mounting the boiler and making the connections (cont.) Ø 12 Fig.4 Reference point boiler top edge Top edge finished floor Installation template (included with the boiler) Recommendation...

  • Page 13: Hooking The Boiler Onto The Wall Mounting Bracket And Levelling It

    Installation sequence Mounting the boiler and making the connections (cont.) Hooking the boiler onto the wall mounting bracket and levelling it Fig.5 Connection on the heating water side Fig.6 Expansion vessel connection Cylinder flow Boiler flow...

  • Page 14: Flue Gas Connection

    The labels "System certificate" and "Skoberne GmbH flue system" enclosed with the technical documenta- tion may only be used in conjunction with the Viessmann flue system made by Skoberne. Do not carry out commissioning until the following Danger conditions are met: Leaking or blocked flue systems or an insuffi- Free passage through the flue gas pipes.

  • Page 15: Condensate Connection

    Installation sequence Condensate connection Connect the condensate hose with a constant fall and a pipe vent to the public sewage system or to a neu- tralising system. Fig.8 Gas connection 2. Carry out a tightness test. Note Only use suitable and approved leak detection agents (EN 14291) and devices for the tightness test.
  • Page 16 Installation sequence Opening the control unit enclosure (cont.) Fig.10...

  • Page 17: Electrical Connections

    Installation sequence Electrical connections Fig.11 Radio clock receiver Heating circuit pump or boiler circuit pump Vitotrol 100 UTDB (only for constant temperature control units) When making this connection, remove jumper between "1" and "L". Vitotrol 100 UTA (only for constant temperature control units) Vitotrol 100 UTDB-RF wireless receiver When making this connection, remove jumper...

  • Page 18: Circulation Pump At Plug Sö

    Installation sequence Electrical connections (cont.) Cylinder temperature sensor (part of the DHW Information on connecting accessories cylinder connection set) When connecting accessories observe the sep- KM BUS subscriber (accessories) arate installation instructions provided with ■ Vitotrol 200A or 300A remote control them.
  • Page 19 Installation sequence Electrical connections (cont.) Hydraulic connection/ connection require- Control unit setting Circulation pump setting ments Coding address/group Ext. In Multi boiler system 30:0/Boiler/2 Recommended for t = 15 K Δ ≙ 125 kW: 7.17 m ■ ≙ 150 kW: 8.60 m ■...

  • Page 20: Circulation Pump At Plug Sa

    Installation sequence Electrical connections (cont.) Circulation pump at plug Rated current 2(1) A~ Rated voltage 230 V~ Set function of connected component in coding address "39" Function Code DHW circulation pump 39:0 Heating circuit pump for heating circuit 39:1 without mixer A1 Circulation pump for cylinder heating 39:2 Fig.14...

  • Page 21: External Demand Via 0

    Installation sequence Electrical connections (cont.) External demand via 0 10 V input – ≙ Connection at 0 10 V input to extension EA1. No default set boiler water temperature – – ≙ Ensure DC separation between the earth conductor Set value 10 °C ≙...

  • Page 22: Outside Temperature Sensor

    Installation sequence Electrical connections (cont.) Codes Extension EA1 Plug "4b:2" in group "General"/"1" Set "3A" (DE1), "3b" (DE2) or "3C" (DE3) in group "General"/"1" to 3 or 4. Select effect of the function on the heating circuit pump in coding address "d6" in group "Heating circuit"/"5". ■...

  • Page 23: Power Supply Fö

    Installation sequence Electrical connections (cont.) Power supply and KM BUS connection of accessories Power supply to all accessories via heat source control unit Fig.16 Some accessories with direct power supply Fig.17 Heat source control unit AM1 extension, EA1 extension and/or solar control Extension kit for heating circuit with mixer M2 module, type SM1 Extension kit for heating circuit with mixer M3...

  • Page 24: Routing The Connecting Cables

    Installation sequence Electrical connections (cont.) Routing the connecting cables Please note If connecting cables touch hot components they will be damaged. When routing and securing connecting cables on site, ensure that the maximum permissible temperatures for these cables are not exceeded. Fig.18 LV terminals Communication module...

  • Page 25: Closing The Control Unit Enclosure And Inserting The Programming Unit

    Installation sequence Closing the control unit enclosure and inserting the programming unit Fig.19 Insert programming unit (packed separately) into the control unit support. Note The programming unit can also be inserted into a wall mounting base (accessory) near the boiler. Wall mounting base installation instructions...

  • Page 26: Steps - Commissioning, Inspection And Maintenance

    Commissioning, inspection, maintenance Steps - commissioning, inspection and maintenance Commissioning steps Inspection steps Maintenance steps Page • • • 1. Opening the boiler......................27 • 2. Filling the heating system....................27 • 3. Selecting the language (if required) - only for weather-compensated control units... 28 •...

  • Page 27: Opening The Boiler

    Commissioning, inspection, maintenance Opening the boiler Fig.20 Filling the heating system Fill water Please note Unsuitable fill water increases the level of deposits and corrosion and may lead to boiler damage. ■ Flush the heating system thoroughly before filling. Only use fill water of potable quality. ■...

  • Page 28: Selecting The Language (If Required) - Only For Weather-Compensated Control Units

    Commissioning, inspection, maintenance Filling the heating system (cont.) Total permissible hardness of the fill and top-up water Total heating output Specific system volume < 20 l/kW 20 l/kW to < 50 l/kW 50 l/kW ≥ ≥ ≤ 3.0 mol/m (16.8 °dH) 2.0 mol/m (11.2 °dH) <...

  • Page 29: Venting The Boiler

    Commissioning, inspection, maintenance Setting the time and date (if required) - only… (cont.) Note When time and date have been set, the control unit automatically checks the function of the flue gas tem- perature sensor. The display shows: "Flue gas temp sensor test"...

  • Page 30: Filling The Siphon With Water

    Commissioning, inspection, maintenance Venting the heating system (cont.) 2. Activate venting program (see following steps). 3. Check the system pressure. Note For function and sequence of the venting program, see page 122. Activating the venting function Weather-compensated control unit Constant temperature control unit Service menu Service menu 1.

  • Page 31: Checking The Gas Type

    Commissioning, inspection, maintenance Checking the gas type The boiler is equipped with an electronic combustion 1. Determine the gas type and Wobbe index by asking controller that adjusts the burner for optimum combus- your local gas supply utility or LPG supplier. tion in accordance with the prevailing gas quality.

  • Page 32: Checking The Static And Supply Pressure

    Commissioning, inspection, maintenance Function sequence and possible faults (cont.) Gas train opens Fault EE Check the gas train (control voltage 230 V) and gas sup- ply pressure. Ionisation current builds Fault EE Check setting of ionisation Symbol electrode. Purge the gas line. Burner in operation Shuts down below the set Check the flue system for...
  • Page 33 Commissioning, inspection, maintenance Checking the static and supply pressure (cont.) 1. Close the gas shut-off valve. 2. Undo screw inside test connector "PE" on the gas train, but do not remove it, and connect the pressure gauge. 3. Open the gas shut-off valve. 4.

  • Page 34: Setting The Maximum Heating Output

    Commissioning, inspection, maintenance Setting the maximum heating output The maximum output for heating operation can be limited. The limit is set via the modulation range. The max. adjustable heating output is limited upwards by the boiler coding card. Weather-compensated control unit Constant temperature control unit Service menu Service menu...

  • Page 35: Removing The Burner And Checking The Burner Gasket

    Commissioning, inspection, maintenance Removing the burner and checking the burner gasket Fig.28 1. Turn off the ON/OFF switch on the control unit and 6. Undo gas supply pipe fitting the power supply. 7. Undo six screws and remove the burner. 2.

  • Page 36: Checking The Burner Gauze Assembly And Replacing It If Required

    Commissioning, inspection, maintenance Checking the burner gauze assembly and replacing it if required Fig.29 1. Remove electrodes 4. Insert new burner gauze assembly with new gasket and secure with four Torx screws. 2. Undo six retaining clips on thermal insulation Torque: 3.0 Nm ring and then remove thermal insulation ring...

  • Page 37: Checking The Flue Gas Non-Return Device

    Commissioning, inspection, maintenance Checking the flue gas non-return device Fig.30 1. Undo three screws and remove fan 4. Refit flue gas non-return device 2. Remove flue gas non-return device 5. Refit fan and secure with three screws. Torque: 3.0 Nm. 3.

  • Page 38: Checking And Adjusting The Ignition And Ionisation Electrodes

    Commissioning, inspection, maintenance Checking and adjusting the ignition and ionisation electrodes ±1 Fig.31 Ignition electrodes Ionisation electrode 1. Check the electrodes for wear and contamination. 3. Check the electrode gaps. If the gaps are not as specified or the electrodes are damaged, replace 2.

  • Page 39: Checking The Condensate Drain And Cleaning The Siphon

    Commissioning, inspection, maintenance Installing the burner (cont.) 4. Connect the electrical cables/leads to the corre- sponding components. Checking the condensate drain and cleaning the siphon Note If condensate escapes at vent aperture clean or (if necessary) replace the following drain line. 1.

  • Page 40: Checking Firm Seating Of Electrical Connections 28. Checking All Gas Equipment For Tightness At Operating Pressure

    Commissioning, inspection, maintenance Checking firm seating of electrical connections Checking all gas equipment for tightness at operating pressure Danger Note Escaping gas leads to a risk of explosion. Only use suitable and approved leak detection agents Check all gas equipment for tightness. (EN 14291) and devices for the tightness test.

  • Page 41: Checking The External Lpg Safety Valve (If Installed) 32. Matching The Control Unit To The Heating System

    Commissioning, inspection, maintenance Checking combustion quality (cont.) Select higher/lower heating output Weather-compensated control unit Constant temperature control unit Service menu Service menu 1. Press OK and simultaneously for approx. 4 s. 1. Press OK and simultaneously for approx. 4 s. å...
  • Page 42 (cont.) System version 1 One heating circuit without mixer A1, with/without DHW heating, with low loss header Fig. 35 ID:4605521_1404_03 Vitodens 200-W Circulation pump for cylinder heating Outside temperature sensor (only for weather- DHW cylinder compensated control units) Cylinder temperature sensor...
  • Page 43 System version 2 One heating circuit with mixer M2, with/without DHW heating, with low loss header Fig. 36 ID: 4605522_1404_03 Vitodens 200-W Temperature limiter to restrict the maximum tem- Outside temperature sensor perature of underfloor heating systems Boiler circuit pump...
  • Page 44 System version 3 One heating circuit with mixer M2, with system separation, with/without DHW heating Fig. 37 ID: 4605523_1404_03 Vitodens 200-W Temperature limiter to restrict the maximum tem- Outside temperature sensor perature of underfloor heating systems Flow temperature sensor M2...
  • Page 45 One heating circuit without mixer, one heating circuit with mixer M2 (with extension kit), one heating circuit with mixer M3 (with extension kit) and low loss header (with/without DHW heating) Fig. 38 ID: 4605524_1404_03 Vitodens 200-W Heating circuit pump M2 Outside temperature sensor Extension kit for one heating circuit with mixer M2...

  • Page 46: Adjusting The Heating Curves (Only For Weather-Compensated Control Units)

    Multi boiler system with several heating circuits with mixer and low loss header (with/without DHW heating) Fig. 39 ID: 4605525_1404_02 Vitodens 200-W Extension kit for one heating circuit with mixer M2 Vitotronic 300-K Heating circuit with mixer M3 (heating circuit 3)
  • Page 47 Commissioning, inspection, maintenance Adjusting the heating curves (only for… (cont.) Slope -5 -10 -15 -20 Outside temperature in °C Fig.40 Slope setting ranges: Reduced set room temperature ■ Underfloor heating systems: 0.2 to 0.8 ■ Low temperature heating systems: 0.8 to 1.6 Selecting the set room temperature Individually adjustable for each heating circuit.

  • Page 48: Connecting The Control Unit To The Lon

    Commissioning, inspection, maintenance Adjusting the heating curves (only for… (cont.) Extended menu: å 2. "Heating" 3. Select heating circuit. 4. "Heating curve" 5. "Slope" or "Level" 6. Select heating curve according to the system requirements. Outside temperature in °C Fig.43 Changing the slope Changing the level (vertical parallel offset of the heating curve)

  • Page 49: Scanning And Resetting The "Service" Display

    Commissioning, inspection, maintenance Connecting the control unit to the LON (cont.) Boiler control unit Vitotronic 200-H Vitotronic 200-H Vitocom Viessmann system number. Viessmann system number. Viessmann system number. — Code "98:1" Code "98:1" Code "98:1" LON subscriber fault monitor- LON subscriber fault moni- LON subscriber fault moni- —...

  • Page 50: Fitting The Front Panel

    Commissioning, inspection, maintenance Fitting the front panel Fig.44 Note Ensure the locking screws are fitted before operating. Instructing the system user The system installer should hand the operating instruc- tions to the system user and instruct the user in oper- ating the system.

  • Page 51: Calling Up Coding Level 1

    Code 1 Calling up coding level 1 On weather-compensated control units, codes are ■ displayed as plain text. ■ Codes that are not assigned due to the heating sys- tem equipment level or the setting of other codes are not displayed. Heating systems with one heating circuit without ■...
  • Page 52 Code 1 General/group "1" (cont.) Coding Coding in the delivered condition Possible change System design 00:1 System version 1: 00:2 For system schemes, see the follow- One heating circuit without mixer ing table: A1 (heating circuit 1), without DHW 00:10 heating Value ad- System ver-...

  • Page 53: Boiler/Group "2

    Code 1 General/group "1" (cont.) Coding in the delivered condition Possible change Subscriber no. 77:1 LON subscriber number (only for 77:2 LON subscriber number adjustable weather-compensated control from 1 to 99: units) 77:99 1 - 4 = Boiler 5 = Cascade 10 - 97 = Vitotronic 200-H 98 = Vitogate 99 = Vitocom...

  • Page 54: Dhw/Group "3

    Code 1 Boiler/group "2" (cont.) Coding in the delivered condition Possible change Service interval in months 23:0 No interval for burner service 23:1 Interval adjustable from 1 to 24 months 23:24 Service status 24:0 No "Service" indication on the dis- 24:1 "Service"...

  • Page 55: Heating Circuit 1, Heating Circuit 2, Heating Circuit 3/Group "5

    Code 1 Solar/group "4" (cont.) Coding Coding in the delivered condition Possible change Speed control solar circuit pump 02:0 Solar circuit pump is not speed- 02:1 Solar circuit pump is speed-control- controlled. led with wave packet control. 02:2 Solar circuit pump is speed-control- led with PWM control.
  • Page 56 Code 1 Heating circuit 1, heating circuit 2, heating… (cont.) Coding Coding in the delivered condition Possible change Priority DHW heating A2:2 Cylinder priority applicable to heat- A2:0 Without cylinder priority for heating ing circuit pump and mixer circuit pump and mixer A2:1 Cylinder priority only for mixers A2:3...
  • Page 57 Code 1 Heating circuit 1, heating circuit 2, heating… (cont.) Coding in the delivered condition Possible change Extended economy function mixer A7:0 Without mixer economy function A7:1 With mixer economy function (exten- (only for weather-compensated ded heating circuit pump logic): control units and heating circuits Heating circuit pump also "OFF": with mixer)
  • Page 58 Code 1 Heating circuit 1, heating circuit 2, heating… (cont.) Coding in the delivered condition Possible change Min. flow temperature heating circuit C5:20 Electronic minimum flow tempera- C5:1 Minimum limit adjustable from 1 to ture limit 20 C (only for weather- C (limited by boiler-specific pa- °...
  • Page 59 Code 1 Heating circuit 1, heating circuit 2, heating… (cont.) Coding in the delivered condition Possible change Start temperature raising F8:-5 Temperature limit for terminating F8:+10 Temperature limit adjustable from the reduced mode -5 C, see ex- +10 to -60 º...

  • Page 60: Calling Up Coding Level 2

    Code 2 Calling up coding level 2 All codes are accessible in coding level 2. ■ ■ Codes that are not assigned due to the heating sys- tem equipment level or the setting of other codes are not displayed. ■ The heating circuit without mixer is designated "Heating circuit 1"...
  • Page 61 Code 2 General/group "1" (cont.) Value ad- System ver- Description dress 00: ... sion One heating circuit without mixer A1 (heating circuit 1), with DHW heating (code is set automatically) One heating circuit with mixer M2 (heating circuit 2), without DHW heating One heating circuit with mixer (heating circuit 2), with DHW heating One heating circuit without mixer A1 (heating circuit 1) and one heating circuit with mixer M2 (heating circuit 2), without DHW heating (code is set automatically)
  • Page 62 Code 2 General/group "1" (cont.) Coding in the delivered condition Possible change 3A:0 Function input DE1 at extension 3A:1 Function input DE1: Heating pro- EA1: Not assigned gram - changeover 3A:2 Function input DE1: External de- mand with set flow temperature. Flow temperature setting: Coding address 9b.
  • Page 63 Code 2 General/group "1" (cont.) Coding in the delivered condition Possible change 3C:3 Function input DE3: External block- ing. Internal circulation pump function: Coding address 3E 3C:4 Function input DE3: External block- ing with fault message input Internal circulation pump function: Coding address 3E 3C:5 Function input DE3: Fault message...
  • Page 64 Code 2 General/group "1" (cont.) Coding in the delivered condition Possible change 54:3 With solar control module SM1 with- out auxiliary function (automatic rec- ognition) 54:4 With solar control module SM1 with auxiliary function, e.g. central heat- ing backup (automatic recognition) 6E:50 No measured outside temperature 6E:0...

  • Page 65: Boiler/Group "2

    The control unit transmits the out- lised internally (only for weather- side temperature to the compensated control units) Vitotronic 200-H 98:1 Viessmann system number (in 98:1 System number adjustable from 1 to conjunction with monitoring several systems via Vitocom 300) 98:5...
  • Page 66 Code 2 Boiler/group "2" (cont.) Coding Coding in the delivered condition Possible change 01:1 Single boiler system (only for con- 01:2 Multi boiler system with stant temperature control units) Vitotronic 300-K 04:1 Minimum burner pause time sub- 04:0 Minimum burner pause time set per- ject to the boiler load (specified by manently (specified by boiler coding boiler coding card)

  • Page 67: Dhw/Group "3

    Code 2 DHW/group "3" Select "DHW" for weather-compensated control unit Select "3" for constant temperature control unit (see (see page 60). page 60). Coding Coding in the delivered condition Possible change 56:0 Set DHW temperature adjustable 56:1 Set DHW temperature adjustable from 10 to 60 from 10 to over 60 °...

  • Page 68: Solar/Group "4

    Code 2 DHW/group "3" (cont.) Coding in the delivered condition Possible change 6F:... Max. heating output for DHW heat- 6F:0 Max. heating output for DHW heat- ing in %; defaulted by the boiler ing adjustable from min. heating out- coding card 6F:100 put to 100 % 71:0...
  • Page 69 Frost protection function for solar 0b:1 Frost protection function for solar cir- circuit switched off. cuit switched on (not required with Viessmann heat transfer medium). 0C:1 Delta T monitoring switched on. 0C:0 Delta T monitoring disabled. No flow rate captured in the solar circuit, or flow rate too low.

  • Page 70: Heating Circuit 1, Heating Circuit 2, Heating Circuit 3/Group "5

    Code 2 Solar/group "4" (cont.) Coding in the delivered condition Possible change 20:5 Thermostat function. 20:6 Thermostat function and auxiliary function. 20:7 Solar heating via external heat ex- changer without additional tempera- ture sensor. 20:8 Solar heating via external heat ex- changer with additional temperature sensor.
  • Page 71 Code 2 Heating circuit 1, heating circuit 2, heating… (cont.) Coding Coding in the delivered condition Possible change A0:0 Without remote control A0:1 With Vitotrol 200A/200RF (automatic recognition) A0:2 With Vitotrol 300A/300RF or Vito- comfort (automatic recognition) A1:0 All possible settings at the remote A1:1 Only party mode can be set at the control can be accessed...
  • Page 72 Code 2 Heating circuit 1, heating circuit 2, heating… (cont.) Coding in the delivered condition Possible change Note "Important" observe for code "A3". A5:5 With heating circuit pump logic A5:0 Without heating circuit pump logic function (economy control): Heat- function ing circuit pump "OFF"...
  • Page 73 Code 2 Heating circuit 1, heating circuit 2, heating… (cont.) Coding in the delivered condition Possible change A9:7 With pump idle time: Heating cir- A9:0 Without pump idle time cuit pump "OFF" if the set value is A9:1 With pump idle time, adjustable from altered through a change in oper- 1 to 15.
  • Page 74 Code 2 Heating circuit 1, heating circuit 2, heating… (cont.) Coding in the delivered condition Possible change d4:0 Heating curve level = 0 d4:–13 Heating curve level adjustable from 13 to 40 (see page 46) – d4:40 d5:0 The external operating program d5:1 The external operating program changeover switches the operating...
  • Page 75 Code 2 Heating circuit 1, heating circuit 2, heating… (cont.) Coding in the delivered condition Possible change F2:8 Time limit for party mode or exter- F2:0 No time limit for party mode nal operating program changeover F2:1 Time limit adjustable from 1 to 12 h via key: 8 h (only for weather-com- pensated control units) F2:12...

  • Page 76: Service Level

    Diagnosis and service scans Service level Weather-compensated control unit Constant temperature control unit Calling up the service level Service menu: Service menu: 1. Press OK and simultaneously for approx. 4 s. 1. Press OK and simultaneously for approx. 4 s. å...

  • Page 77: Diagnosis

    Diagnosis and service scans Diagnosis Operating data Weather-compensated control unit Constant temperature control unit Calling up operating data Operating data can be scanned in six areas. See "Di- Operating data can be called up in the "i" menu. ■ ■ agnosis"...
  • Page 78 Diagnosis and service scans Diagnosis (cont.) Line (brief Field scan) Software version Type Burner control unit version Burner control unit Burner control unit Internal details for calibration Software ver- Software ver- sion, AM1 ex- sion, EA1 exten- tension sion Flow sensor switching state 1: Flow rate...
  • Page 79 Diagnosis and service scans Diagnosis (cont.) Constant temperature control unit 3. Select the required scan with . For example, "b" for "Max. output" (see following table): 1. Press OK and simultaneously for approx. 4 s. å " " flashes on the display. 4.

  • Page 80: Checking Outputs (Relay Test)

    Diagnosis and service scans Diagnosis (cont.) Brief scan Display Output 157 con- Output 157 Input DE1 Input DE2 Input DE3 switch- figuration switching state switching state switching state ing state (value corre- 0: OFF 0: open 0: open 0: open sponds to set- 1: ON 1: closed...

  • Page 81: Constant Temperature Control Unit

    Diagnosis and service scans Checking outputs (relay test) (cont.) Display Explanation EA1 output 1 Contact P - S at plug of extension EA1 closed Solar circuit pump Solar circuit pump output on solar control module SM1 active Solar circ pmp min Solar circuit pump output on solar control module SM1 switched to minimum speed Solar circ pmp max...

  • Page 82: Fault Display

    Troubleshooting Fault display Weather-compensated control unit In the event of a fault, red fault indicator flashes. Calling up acknowledged faults " " flashes on the display and "Fault" is shown. Select "Fault" in the standard menu. The current faults will be displayed in a list. Calling up fault codes from the fault memory (fault history) The 10 most recent faults (including resolved ones)

  • Page 83: Fault Codes

    Troubleshooting Fault display (cont.) Calling up acknowledged faults 1. Press OK and simultaneously for approx. 4 s. å Press OK for approx. 4 s. 2. Select " " and activate fault history with OK. ã The 10 most recent faults (including resolved ones) are saved and can be called up.
  • Page 84 Troubleshooting Fault codes (cont.) Displayed Const. Weather- System characteris- Cause Measures fault code comp. tics Regulates without Lead break, sys- Check low loss header flow temperature sen- tem flow tempera- sensor (see page 92) sor (low loss header) ture sensor If no low loss header sen- sor is connected, set code 52:0.
  • Page 85 Troubleshooting Fault codes (cont.) Displayed Const. Weather- System characteris- Cause Measures fault code comp. tics No solar DHW heat- Lead break, collec- Check temperature sen- tor temperature on solar control & sensor module or sensor on the Vitosolic. Control mode Lead break, cylin- Check temperature sen- der temperature...
  • Page 86 Troubleshooting Fault codes (cont.) Displayed Const. Weather- System characteris- Cause Measures fault code comp. tics Control mode without Communication er- Check connections, ca- remote control ror, Vitotrol remote ble, coding address "A0" control, heating cir- in "Heating circuit" cuit 1 (without mix- group and remote control DIP switches (see page 124).
  • Page 87 Troubleshooting Fault codes (cont.) Displayed Const. Weather- System characteris- Cause Measures fault code comp. tics Control mode Communication er- Check OpenTherm exten- ror, OpenTherm sion extension Control mode, max. Communication er- Check pump KM-BUS pump speed ror, variable speed pump Control mode Communication er- Check connections,...
  • Page 88 Troubleshooting Fault codes (cont.) Displayed Const. Weather- System characteris- Cause Measures fault code comp. tics Burner in a fault state Ionisation current Check gap between ioni- too high during cal- sation electrode and burn- ibration er gauze assembly (see page 38). In open flue operation, prevent high incidence of dust in the combustion air.
  • Page 89 Troubleshooting Fault codes (cont.) Displayed Const. Weather- System characteris- Cause Measures fault code comp. tics Burner in a fault state Ionisation current Check flue system; reme- outside permissible dy flue gas recirculation if range during cali- required. bration (excessive In open flue operation, deviation from pre- prevent high incidence of vious level)
  • Page 90 Troubleshooting Fault codes (cont.) Displayed Const. Weather- System characteris- Cause Measures fault code comp. tics Burner in a fault state Flame is lost imme- Check gas supply (gas diately after it has pressure and gas flow built (during the switch). safety time).

  • Page 91: Maintenance

    Troubleshooting Fault codes (cont.) Displayed Const. Weather- System characteris- Cause Measures fault code comp. tics Burner in a fault state Boiler coding card Insert the boiler coding and additional fault missing card. b7 is displayed Press reset button R. Replace control unit if fault persists.

  • Page 92: Checking The Boiler Water Temperature Sensors, Cylinder Tempera- Ture Sensor Or Flow Temperature Sensor For The Low Loss Header

    Troubleshooting Maintenance (cont.) 1. Pull plug "X3" from the control unit. 2. Test the resistance of the outside temperature sen- sor across terminals "X3.1" and "X3.2" on the dis- connected plug and compare it with the curve. 3. Where actual values deviate severely from the curve values, disconnect the wires at the sensor and repeat test on the sensor itself.

  • Page 93: Replacing The Flow Sensor

    Troubleshooting Maintenance (cont.) 2. Check the sensor resistance and compare it with the curve. 3. In the event of severe deviation replace the sensor. Danger The boiler water temperature sensors are immersed in the heating water (risk of scald- ing). Drain the boiler before replacing the sensor.

  • Page 94: Checking The Flue Gas Temperature Sensor

    Troubleshooting Maintenance (cont.) Checking the flue gas temperature sensor The flue gas temperature sensor locks out the boiler when the permissible flue gas temperature is excee- ded. Reset the interlock after the flue system has cooled down by pressing reset button R. 1.

  • Page 95: Checking The Fuse

    Troubleshooting Maintenance (cont.) Checking the fuse Fig.57 1. Switch off the power. 3. Remove cover 2. Release the side closures and pivot the control unit 4. Check fuse F1 (see connection and wiring dia- down. gram). Extension kit, mixer Checking the setting of rotary selector S1 Note The mixer motor can also be started via the actuator The rotary selector on the PCB of the extension kit...

  • Page 96: Checking The Vitotronic 200-H (Accessories)

    Troubleshooting Maintenance (cont.) Changing the rotational direction of the mixer motor (if required) 1. Remove the upper casing cover of the extension kit. Danger An electric shock can be life-threatening. Before opening the boiler, disconnect from the mains voltage, e.g. at the fuse or the mains isolator.
  • Page 97 Troubleshooting Maintenance (cont.)

  • Page 98: Parts Lists Overview Of Assemblies

    Parts lists Overview of assemblies The following details are required when ordering Standard parts are available from your local supplier. parts: ■ Serial no. (see type plate ■ Assembly (from this parts list) Position number of the individual part within the ■...
  • Page 99 Parts lists Overview of assemblies (cont.)
  • Page 100 Parts lists Overview of assemblies (cont.) Fig.60 Type plate Control unit assembly Casing assembly Hydraulic assembly Heat cell assembly Miscellaneous with burner...
  • Page 101 Parts lists Overview of assemblies...

  • Page 102: Casing Assembly

    Parts lists Casing assembly 0006 0001 0007 0004 0005 0002 0003 0008 0001 0002 Fig.61...
  • Page 103 Parts lists Casing assembly (cont.) Pos. Part 0001 Fixing clip (2 pce) 0002 Logo 0003 Contact guard 0004 Control unit support 0005 Siphon grommet 0006 Wall mounting bracket 0007 Cover panel 0008 Front panel...

  • Page 104: Heat Cell Assembly

    Parts lists Heat cell assembly 0002 0003 0008 0002 0004 0003 0001 0005 0014 0001 0002 0003 0004 0005 0006 0007 0008 0011 0012 0013 0015 0015 0007 0016 0012 0006 0010 0011 0011 0009 0013 0013 Fig.62...
  • Page 105 Parts lists Heat cell assembly (cont.) Pos. Part 0001 Diaphragm grommet Ø 110 0002 Lip seal Ø 150 0003 Lip seal Ø 110 0004 Boiler flue connection plug 0005 Flue gas temperature sensor 0006 Condensate hose 0007 Siphon 0008 Boiler flue connection 0009 Gas supply pipe 0010...

  • Page 106: Burner Assembly

    Parts lists Burner assembly 0015 0005 0015 0007 0015 0014 0015 0014 0010 0006 0012 0015 0014 0015 0001 0001 0013 0008 0011 0009 0002 0003 0002 0004 Fig.63...
  • Page 107 Parts lists Burner assembly (cont.) Pos. Part 0001 Gasket, ignition electrode (5 pce) 0002 Gasket, ionisation electrode (5 pce) 0003 Radial fan 0004 Gas train 0005 Burner gasket 0006 Burner door 0007 Thermal insulation ring 0008 Flue gas non-return device 0009 Ionisation electrode 0010...

  • Page 108: Hydraulic Assembly

    Parts lists Hydraulic assembly 0001 0001 0002 0001 0001 0004 0003 0004 0001 Fig.64...
  • Page 109 Parts lists Hydraulic assembly (cont.) Pos. Part 0001 Clip Ø 8 (5 pce) 0002 Temperature sensor (2 pce) 0003 Pressure gauge 0004 Flow sensor...

  • Page 110: Control Unit Assembly

    Parts lists Control unit assembly 0002 0008 0009 0009 0004 0005 0015 0001 0003 0020 0015 0014 0005 0006 0004 0015 0018 0007 0017 0010 0011 0013 Fig.65...
  • Page 111 Parts lists Control unit assembly (cont.) Pos. Part 0001 Control unit 0002 Casing back panel 0003 Coding card 0004 Fuse 6.3 A slow (10 pce) 0005 Fuse holder, 6.3 A (slow) 0006 Programming unit for weather-compensated mode 0007 Programming unit for constant temperature mode 0008 LON communication module 0009...

  • Page 112: Miscellaneous Assembly

    Parts lists Miscellaneous assembly 0004 0005 0003 0002 0001 Fig.66...
  • Page 113 Parts lists Miscellaneous assembly (cont.) Pos. Part 0001 Operating instructions for weather-compensated mode 0002 Operating instructions for constant temperature mode 0003 Installation and service instructions 0004 Spray paint, Vitowhite 0005 Touch-up paint stick, Vitowhite...

  • Page 114: Function Description Constant Temperature Control Unit

    Function description Constant temperature control unit °C Fig.67 Heating mode The selected set boiler water temperature will be main- The electronic temperature limiter inside the burner tained when a demand is being raised by the room control unit limits the boiler water temperature. thermostat and the heating program is set to DHW and Flow temperature setting range: 20 to 74 °C.

  • Page 115: Heating Mode

    Function description Weather-compensated control unit (cont.) Heating mode The control unit determines a set boiler water tempera- The electronic temperature limiter inside the burner ture subject to outside temperature or room tempera- control unit limits the boiler water temperature. ture (if a room temperature-dependent remote control is connected) and to the slope level of the heating curve.

  • Page 116: Internal Extensions (Accessories)

    Function description Internal extensions (accessories) Internal extension H1 Fig.69 The internal extension is integrated into the control unit ■ Heating circuit pump for heating circuit without mixer casing. The following alternative functions can be con- (code "53:2") nected to relay output .

  • Page 117: Internal Extension H2

    Function description Internal extensions (accessories) (cont.) Internal extension H2 Fig.70 The internal extension is integrated into the control unit ■ Heating circuit pump for heating circuit without mixer casing. The following alternative functions can be con- (code "53:2") nected to relay output .

  • Page 118: External Extensions (Accessories)

    Function description External extensions (accessories) Extension AM1 Fig.71 Circulation pump A Power supply for additional accessories fÖ Circulation pump KM BUS Power supply fÖ Functions Select the output functions by means of the codes on the boiler control unit. One of the following circulation pumps can be connec- ted to each of the connections A1 and A2: Heating circuit pump for the heating circuit without ■...

  • Page 119: Ea1 Extension

    Function description External extensions (accessories) (cont.) EA1 extension Fig.72 MCB/fuse Power supply fÖ Digital input 1 Power supply for additional accessories fÖ Digital input 2 Central fault message/feed pump/DHW circu- Digital input 3 lation pump (potential-free) 10 V 0 10 V input KM BUS –...

  • Page 120: Control Functions

    Function description External extensions (accessories) (cont.) Assigning the operating program changeover DHW circulation pump runtime for brief operation function to the heating circuits The DHW circulation pump is started by closing the Select the operating program changeover function for contact at DE1, DE2 or DE3 by means of a pushbut- the respective heating circuit via coding address d8 in ton.

  • Page 121: External Blocking

    Function description Control functions (cont.) Heating program - changeover Code Changeover via input DE1 d8:1 Changeover via input DE2 d8:2 Changeover via input DE3 d8:3 You can select which direction the heating program changeover takes in coding address "d5" in the "Heat- ing circuit"...

  • Page 122: Venting Program

    Function description Control functions (cont.) External demand Code Input DE1 3A:2 Input DE2 3b:2 Input DE3 3C:2 The effect on the internal circulation pump is selected The minimum set boiler water temperature in case of in coding address "3F" in the "General" group. external demand is selected in coding address "9b"...
  • Page 123 Function description Control functions (cont.) Temperature profile 3: Code "F1:3" Days Fig.75 Temperature profile 4: Code "F1:4" Days Fig.76 Temperature profile 5: Code "F1:5" Days Fig.77 Temperature profile 6: Code "F1:6" Days Fig.78 Temperature profile 7: Code "F1:15" Days Fig.79...

  • Page 124: Raising The Reduced Room Temperature

    Function description Control functions (cont.) Raising the reduced room temperature During operation with reduced room temperature, the The outside temperature limits for the start and end of reduced set room temperature can be automatically temperature raising can be set in coding addresses raised subject to the outside temperature.

  • Page 125: Assigning Heating Circuits To The Remote Control

    Function description Control functions (cont.) Example using the settings in the delivered condition Time in h Fig.81 Start of operation with standard room temperature Set boiler water or flow temperature in accordance with the selected heating curve Set boiler water or flow temperature in accordance with coding address "FA": C + 20 % = 60 °...

  • Page 126: Electronic Combustion Control Unit

    Function description Assigning heating circuits to the remote control (cont.) Note One heating circuit can be assigned to the Vitotrol 200A and 200 RF. Up to three heating circuits can be assigned to the Vitotrol 300A and 300 RF. A maximum of 2 hardwired remote control units or 3 wireless remote controls may be connected to the con- trol unit.

  • Page 127: Connection And Wiring Dia-Connection And Wiring Diagram - Internal Connections

    Connection and wiring diagram Connection and wiring diagram Internal connections – Fig.82 X... Electrical interfaces Fan motor a-Ö (A/B) Boiler water temperature sensor Fan motor control § a-Ö Ionisation electrode a:Ö Modulation coil Flue gas temperature sensor Flow sensor Ignition unit Flow sensor...

  • Page 128: Gram Connection And Wiring Diagram - External Connections

    Connection and wiring diagram Connection and wiring diagram External connections – Fig.83 A1 Main PCB Outside temperature sensor A2 Power supply unit Flow temperature sensor, low loss header A3 Optolink Cylinder temperature sensor A4 Burner control unit (plug on the cable harness) A5 Programming unit Heating circuit pump or boiler circuit pump sÖ...

  • Page 129: Commissioning/Service

    Commissioning/service reports Settings and actual values Set value Commissioning Maintenance/ Service Date Signature Static pressure mbar 57.5 ≤ 5.75 ≤ Supply pressure (flow pressure) for natural gas E mbar 17.4-25 1.74-2.5 for natural gas LL mbar 17.4-25 1.74-2.5 for LPG mbar 42.5-57.5 4.25-5.75...

  • Page 130: Specification

    Specification Specification Gas boiler, category II 2N3P 32 - 125 32 - 150 Rated heating output range 50/30 °C Rated heating input range 30 - 118 30 - 142 Rated voltage Rated frequency Rated current Backup fuse (power supply) Power consumption in the delivered condition Electronic temperature limiter setting (fixed) °C Temperature limiter setting (fixed)

  • Page 131: Certificates Declaration Of Conformity

    Certificates Declaration of conformity Declaration of Conformity for the Vitodens 200-W We, Viessmann Werke GmbH & Co KG, D-35107 Allendorf, confirm as sole responsible body that the product Vitodens 200-W complies with the following standards: EN 15417 EN 60 335-2-102...

  • Page 132: Keyword Index

    Keyword index Keyword index Acknowledging a fault display........82 Heating circuit assignment........125 Heating curve............. 46 Heating curve level.............47 Boiler, opening............27 Heating curve slope........... 47 Boiler water temperature sensor ....... 92 Heating output, setting..........34 Boosting DHW heating..........115 Heating program changeover........120 Brief scans..............
  • Page 133 Keyword index Keyword index (cont.) Tightness test, balanced flue system......34 Wiring diagram............127 Time, setting...............28 Venting............... 29 Venting program............122 Vitotronic 200-H............96...
  • Page 136 Applicability These service instructions relate to appliances with the following serial numbers (see type plate): 7506550 7506551 Viessmann Werke GmbH&Co KG Viessmann Limited D-35107 Allendorf Hortonwood 30, Telford Telephone: +49 6452 70-0 Shropshire, TF1 7YP, GB Fax: +49 6452 70-2780 Telephone: +44 1952 675000 www.viessmann.com...

Table of Contents
