Recommended Maintenance Schedule
Maintenance Service
Interval
Each Use
50 Hours
150 – 200 Hours
8.1 Mowing Deck
The underside of the mowing deck needs to be inspected, and cleaned if necessary, between operations.
The Robomow is a dedicated mulching mower and may accumulate clippings under the mowing deck,
particularly when mowing wet and damp grass. Figure 8.2
WARNING! WARNING!
!
!
Most grass accumulation can be removed using a small wooden stick or similar object. Carefully scrape
the collected grass debris from under the mowing deck. If necessary, remove the blades to gain better
access to the mowing chambers in order to clean them. Do not place the mower upside down, damage to
the Manual Controller can occur. Instead, lean the mower against another surface to gain access to the
mowing deck area.
NEVER use a water hose or other type of liquid sprayer to clean the underside of the mower. Component
damage can occur. Use only a damp or wet cloth to wipe the surface clean after scraping.
8.2 Blades
The cutting blades of the Robomow should be examined for damage between operations. Replace any
damaged blade found. Only use sharp blades. Replace blades at least once per season, more often if
they have been severely dulled. It is recommended to replace all three blades for best performance.
Machine sharpening is not recommended, as a good balance cannot be achieved after machine
sharpening. See Figure 9.1.
Robomow has an automatic reminder to replace the blades after every 200 hours of operation. 'Replace
blades – every 200 hours' message appears and pressing the GO button will clear the message and
enables the operation of Robomow.
Chapter 8
Maintenance and Storage
Check and remove grass clippings and dirt from the mowing deck if necessary,
particularly when mowing wet and damp grass (refer to section 8.1)
Charge the power pack after every use.
Remove Power Pack and check any damage on the blades (refer to section 8.2)
Replace the blades; replace them more frequently if the edges dull in rough or
sandy conditions (see Figure 8.2).
Remember to restart the automatic blades replacement reminder after every time
the blades have been replaced (refer to section 8.2).
Serious injury can occur. Always remove Power Pack before lifting Serious injury can occur. Always remove Power Pack before lifting
mower. Blades are very sharp and can cause severe cuts or
mower. Blades are very sharp and can cause severe cuts or
lacerations. Always wear heavy work gloves when working with lacerations. Always wear heavy work gloves when working with
and around the blades. Never use a damaged or broken blade. and around the blades. Never use a damaged or broken blade.
Maintenance Procedure
Use only sharp blades. Use only sharp blades.
