5.2.1.2 Learn Edge
The default distance for edge mowing is approximately 1.5 to 2 rounds around the perimeter. This
feature allows the user to learn a specific distance in each operating zone in order to cause the
mower to cut the edge a specific distance, such as one full round. It will remain as a learned distance
until the edge is re-learned or the factory default edge is selected. It should be done when the Manual
Controller is in the holder and flush with the mower top. 'Learn Edge' gives you the ability to have the
Robomow learn the distance around the edge. Figure 5.6.
•
Position the Robomow to start edge mowing and place the Manual Controller in its holder
•
Follow the steps described in Figure 5.6 to begin the process
•
'Learn Edge' is specific to each zone, so be sure you have selected the correct zone where
you want the edge learned
Figure 5.6
5.2.1.3 Set Default Edge
Selecting Default Edge restores the factory default edge distance to the specific zone selected.
5.2.2 Sound
Allows user to shut off non-safety related operating sounds.
5.2.3 Wire position
Allows user to test the wire position in 'Edge' mode while the mowing motors are switched off to
prevent any damage to the perimeter wire after the initial setup of the wire is completed.
5.2.4 Language
Allows the user the option of viewing the LCD text in several different language versions.
5.2.5 Scan Width
Scan Width provides the Robomow the option to change the progress of the mower when mowing.
This can be beneficial in some lawns. Scan width will modify the distance between subsequent legs
of mowing after each movement off of the perimeter wire. If it appears that the Robomow is simply
driving along the same path back and forth,it is recommended to increase the scan width.
User Options User Options
Press GO Press GO
User Preferences User Preferences
Press GO Press GO
Zones setup Zones setup
Press GO Press GO
Zone A Zone A
Press GO Press GO
Zone B Zone B
Press GO Press GO
Work time
Work time
Press GO Press GO
Learn edge Learn edge
Press GO to learn Press GO to learn
Learning Edge Learning Edge Learning Edge
STOP to Set STOP to Set STOP to Set
Use the 'Up' ⇑ or 'Down' ⇓ arrow keys to scroll
to the 'User Options' display and press 'GO'.
GO'
Press '
GO'
Press '
Scroll down to the zone you
want to learn the edge distance
GO'
Press '
Scroll down once to
'Learn edge' option
GO'
Press '
Driving around perimeter. Follow the
mower and press the 'Stop' button when
the desired distance has been reached.
