Maximum length of wire
connected to the
Perimeter Switch in one
loop is 1000ft (300m)
While the picture
shows two wires
separate, they
should be adjacent
- Three separate zones, all in one loop connected to the Perimeter Switch. In order to mow any
Figure 1.8b
of the zones, Robomow to the desired one and press GO.
Plot connector
for Perimeter
Switch connection
18
Zone A
Zone B
Zone A
Back Yard
Zone B
Zone C
While the picture
shows two wires
separate, they
should be adjacent
Plot connector
for Perimeter
Switch connection
Zone C
Front Yard
Figure 1 . 8 c – Three separate zones.
Each operated separately by a perimeter switch.
Perimeter
Switch
Perimeter
Switch
