Friendly Robotics robomow rl350 Operating Manual page 40

User Preferences User Preferences User Preferences
5.2.1 Zones setup
Allows user to set the parameters that are specific per zone (Figure 5.4):
5.2.1.1 Work Time
Allows the user the option of setting the operating time from the 'MAX' default setting to times ranging
from 20 minutes up to 2:40 hours (1:40 hours in RL350). Figure 5.5. This option is available for up to
4 different zones, Dock Zone, Zone B, C or D. Having four different zones can allow you to set
operating time for several different zones that are of varying sizes, not requiring the same operating
time for mowing.
Figure 5.5
38
Press 'GO' Press 'GO' Press 'GO'
Press GO Press GO Press GO
Figure 5.3
Figure 5.4
Zones setup options
Zone A Zone A MAX MAX
Press GO Press GO
Zone A Zone A 2:00 2:00
Press GO Press GO
Zones setup Zones setup Zones setup
Press GO Press GO Press GO
Sound Sound on on
Press GO Press GO
Wire Position Wire Position
Press GO Press GO
Language Language
Press GO Press GO
Wide scan Wide scan off off
Press GO Press GO
Blades replaced Blades replaced
Press GO Press GO
Anti theft Anti theft
Press GO Press GO
Work time Work time Work time
Press GO Press GO Press GO
Learn edge Learn edge Learn edge
Press GO Press GO Press GO
Set default edge Set default edge Set default edge
Press GO Press GO Press GO
Scroll to select
different zones.
Scroll to select different operating
times. Times range from: 20
minutes to 2:40 hours to '
MAX'
