Page 1: Network Camera
NETWORK CAMERA Model: IKS-WR7412 User’s Manual For information on our latest products and peripheral devices, refer to the following web site: www.toshibasecurity.com If the URL changes, refer to www.toshiba.com 32700AC... - Page 3 32700AD...
- Page 4 This documentation is copyrighted. All other rights are reserved to TOSHIBA. TOSHIBA, and Surveillix, are registered trademarks of TOSHIBA in the United States and elsewhere; Windows, and Windows XP Embedded are registered trademarks of Microsoft Corporation. All other brand and product names are trademarks or registered trademarks of the respective owners.
-
Page 5: Important Safeguards
Important Safeguards Read Instructions Read all the safety and operating instructions before operating the product. Retain Instructions Retain the safety instructions and user's manual for future reference. Warnings Comply with all warnings on the product and in the user's manual. Follow Instructions Follow all operating and use instructions. - Page 6 13. Lightning For additional protection on this camera during a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the power supply and cable system. This will prevent damage to the camera due to lightning and power line surges.
- Page 7 Precautions Operating • Before using, make sure power supply and others are properly connected. • While operating, if any abnormal condition or malfunction is observed, stop using the camera immediately and then contact your local dealer. Handling • Do not disassemble or tamper with parts inside the camera. •...
- Page 8 • Notwithstanding the foregoing, Toshiba's liabilities shall not, in any circumstances, exceed the purchase price of the product. Copyright and Right of Portrait • There may be a conflict with the Copyright Law and other laws when a customer uses, displays, distributes, or exhibits an image picked up by the camera without permission from the copyright holder.
- Page 9 CAUTION: Your authority to operate this FCC verified equipment could be voided if you make changes or modifications not expressly approved by the party. Industry Canada Information CAN ICES-3 A / NMB-3 A This symbol on the product or on its packaging indicates that this product shall not be treated as household waste in accordance with Directive 2002/96/EC.
- Page 10 Warning TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. DANGEROUS HIGH VOLTAGES ARE PRESENT INSIDE THE ENCLOSURE. DO NOT OPEN THE CABINET. THIS INSTALLATION SHOULD BE MADE BY A QUALIFIED SERVICE PERSON AND SHOULD CONFORM TO ALL LOCAL CODES.
-
Page 11: Table Of Contents
TABLE OF CONTENTS Introduction .................... 14 Overview ........................14 Product Features ...................... 14 Getting Started ..................15 Box Contents ........................ 15 Camera Overview ......................16 Dimensions ....................... 16 Connections ......................17 Reset Button ......................18 Device Search Software ....................19 Installation .............. - Page 12 Delete User ......................29 Modify User ......................29 File Location ......................30 Picture Setup ........................ 30 Camera Tab ......................30 Exposure ......................31 White Balance ...................... 31 Picture Adjustment ....................32 Motion Detection ....................... 32 Add Detection Window ..................33 Delete Motion Detection Window .................
- Page 13 Interval Recording ....................47 Maintenance ......................48 Configuration ......................48 Factory Default ..................... 48 Software ........................49 Picture Setting ......................49 Video Mask ....................... 49 Hot Spot ........................49 Text Overlay ......................49 Streaming Setting ......................49 Audio ......................... 50 Logout .....................
-
Page 14: Introduction
INTRODUCTION OVERVIEW The IKS-WR7412 is a 2 megapixel indoor and outdoor IP camera that provides users with crisp IP video in a feature-rich, compact package. The camera is lightweight and compact with a 3-axis gimbal for a large degree of rotation. -
Page 15: Getting Started
GETTING STARTED BOX CONTENTS Before proceeding, please check that the box contains the items listed here. If any item is missing or has defects, DO NOT install or operate the product and contact your dealer for assistance. Camera Self Tapping Screws Plastic Anchors Torx Screwdriver Security Screw... -
Page 16: Camera Overview
CAMERA OVERVIEW Before installing or connecting the dome camera, please refer to this section and complete preparations for dome setup and all switch settings. Dimensions 4.625” (117.5 mm) Ø 3.125” (79.38 mm) • Diameter – 110.21mm (4.3 inches) • Height – 47.66mm (1.87inches) -
Page 17: Connections
Connections The Indoor Tamper Resistant IP Dome Cameras use Power over Ethernet (PoE) to power the cameras. The only connection on the camera is the RJ45 Ethernet connector located on the rear of the camera. Connect one end of the Ethernet cable to the RJ45 port on the camera and the other end to power sourcing equipment (PSE) like a hub or router. -
Page 18: Reset Button
Reset Button Push the reset button to return the camera to factory default settings. -
Page 19: Device Search Software
Installation You can run Device Search on any personal computer (PC) or laptop using the software CD included with your Surveillix IP camera or by downloading the program from toshibasecurity.com. Note Device Search will only work on PCs or laptops that use a Windows operating system. -
Page 20: Device Addressing
Device Addressing The functions on the Device Addressing tab allow you to find network cameras. Finding Network Devices Click Device Search. To sort your search by Camera Model, Project, or Camera Name, select your desired criteria from the appropriate lists. - Page 21 Viewing a Network Camera To view a network camera over the web using the camera’s viewer software, double-click the name of the camera. Click Browse. Enter the Username and Password for the camera. The username and password are case sensitive. It is strongly recommended that the password be changed after the initial setup to prevent unauthorized access.
-
Page 22: Setup & Configuration
SETUP & CONFIGURATION Connecting to the Camera Locate the camera on the IP Finder list. Double-click the camera to open the Viewer software in your web browser. Click Browse in the pop-up window. Log in to the camera with the appropriate User Name and Password. Note The default User name is admin and the default Password is1234. -
Page 23: Connecting Over The Internet
Connecting Over the Internet There are some challenges with connecting to Toshiba IP cameras over WAN (internet) connections because the camera streams video over RTSP. RTSP is an excellent protocol for media and is now used on many IP cameras (including Toshiba) as the default streaming option. -
Page 24: Viewer Software
VIEWER SOFTWARE To access the setup menu, you need to install the viewer software on your PC or recorder. The viewer software will install automatically the first time you connect to the camera. If your internet browser doesn’t install the viewer software, check the security settings or ActiveX controls and plug-in settings. -
Page 25: Live
LIVE Full Screen – This will display the live feed in full screen. Snapshot – Click the button, and a JPEG snapshot will automatically be saved in the appointed place. The default location is: C:\. Note If you are using Windows Vista or 7, you will need to change the Snapshot location. -
Page 26: Setup
SETUP The Setup menu includes System Settings, Picture Setup, and Streaming Settings. Note The Setup menu displays limited setup options. For a complete list of setup options, see the Advanced section. SYSTEM SETTING Camera Name Host Name – The Host Name is used to identify the camera on your system. -
Page 27: Ip Address
IP Address You can choose to use a fixed IP address or a dynamic IP address (assigned by a DHCP server or router) for the camera. Get IP an Address Automatically (DHCP) The camera comes preconfigured with a fixed IP address, selecting Get IP address automatically requires a router or DHCP server to assign an IP address to the camera. -
Page 28: Use Static Ip Address
Use Static IP Address To set up a new static IP address: Select the Use static IP address option. Type a new IP address in the IP address box. Type a new address in the Default Gateway box. Click Apply to confirm the new setting. When using static IP address to log in to the IP Camera, you can access it either through Toshiba IP Finder software or type the IP address directly in the address bar of your Internet Explorer. -
Page 29: Ipv6 Address Configuration
IPv6 Address Configuration To enable IPv6 select Enable IPv6 and click Save. See your network administrator if you are unsure of your network configuration. User Setup Admin Password Manage the password for the Administrator account. To change the administrator password: Type a new Administrator Password, and then type again to confirm the password. -
Page 30: File Location
Select the user name on the User Name list. Click Edit. In the resulting window, modify the Password and/or feature permissions. Click Save. Note For security reasons, every time the user properties are opened the access check boxes are automatically cleared. Make sure you select any user access options each time you edit the user properties. -
Page 31: Exposure
Exposure Min Shutter Speed – Choose a pre-determined shutter speed. Manual Mode – Changing the shutter mode to manual will allow you to select the minimum shutter speed that the camera will use. This can drastically change the amount of light entering the camera. Click Set to save your changes. -
Page 32: Picture Adjustment
Picture Adjustment Each of the Picture Adjustment settings is set to the recommended default. Brightness – Adjust the image’s brightness on the camera. The Backlight value is adjustable from 0 (dim) ~ +20 (brightest). Sharpness – Increasing the sharpness level can make the image looked sharper;... -
Page 33: Add Detection Window
Add Detection Window Use the Motion Detection dropdown to select a motion detection preset. Click Add. Note The selected motion detection square will be red. Arrange and size the motion detection window as desired. Click Save. Delete Motion Detection Window Click to select the desired motion detection window. -
Page 34: Streaming Settings
STREAMING SETTINGS Video Resolution The camera provides eight codec options under video resolution (two single streaming options, two sets of dual streaming options, two sets of tri-streaming options, and two sets of quad-streaming options): • H.264 Only • MJPEG Only •... -
Page 35: Video Orientation
Video Orientation Normal Video – The video will be oriented as the camera position dictates. 180 Degree Rotate – Rotate the video 180 degrees. 90 Degree Clockwise – Rotate the video 90 degrees clockwise. 90 Degree Counter Clockwise– Rotate the video 90 degrees counter clockwise. Mirror Video –... -
Page 36: Video Frame Rate
Video Frame Rate Setting the camera to transmit fewer frames can save bandwidth. Use the Frame Rate Control screen to adjust the frame rate of each stream. Each of the MJPEG and H.264 streams can have a separate frame rate setting from 1 to 30 frames per second. -
Page 37: Video Compression
Video Compression You can select an MJPEG / H.264 compression mode on the video compression page appropriate for your application. You can also select to display compression inflation on the Live Screen. MJPEG compression settings include: • High compression, low bitrate, low quality •... -
Page 38: Advanced
ADVANCED SYSTEM SETTING Network Setup The Network Setup settings will automatically be set at the recommended default after the camera connection is made. DDNS DDNS (Dynamic Domain Name Service) is a service that allows a connection to an IP address using a hostname (URL) address instead of a numeric IP address. Most Internet Service Providers use Dynamic IP Addressing that frequently changes the public IP address of your internet connection;... -
Page 39: Snmp Settings
SNMP Settings With Simple Network Management Protocol (SNMP) enabled, the camera can be monitored and managed remotely with a network management system. Contact your network administrator if you are not familiar with SNMP setup. UPnP (Universal Plug N’ Play) • Enable UPnP –... -
Page 40: Network Security
Network Security HTTP The camera can send alarm messages to a specific Hypertext Transfer Protocol (HTTP) site when motion is detected or when the sensor input is activated. You can assign alarm messages to up to two HTTP sites. IP Filtering IP Filtering allows you limit access to your IP cameras by IP address. -
Page 41: Alarm Application
Alarm Application The alarms menu is where alarm connections are configured. Alarm Switch – Designate when the alarm will be active; Off, On, or By Schedule. Alarm Type – Designate if the alarm is normally open or normally closed. • NOH –... -
Page 42: Tampering And Network Failure Detection
Tampering and Network Failure Detection Tampering Alarm – Turn the Tampering Alarm On, Off, or On By Schedule. Tampering Duration – Designate the amount of time (in seconds) that tampering must occur in order for a Tampering Alarm to activate. Triggered Action –... -
Page 43: Mail, Http And Ftp Setup
Mail, HTTP and FTP Setup The camera can send an e-mail via Simple Mail Transfer Protocol (SMTP) when a variety of events occur. SMTP is a protocol for sending e-mail messages between servers. SMTP is a relatively simple, text-based protocol, where one or more recipients of a message are specified and the message text is transferred. -
Page 44: Network Share
Network Share Network Share is a network protocol that runs a variety of different system platforms, allowing for file sharing between computers operating on Windows and computers operating on Unix. This serves as an additional storage type. Configuration requires the host IP address, share name, and credentials. Once configured, cameras can record events to the network share. -
Page 45: Recording Schedule
Recording Schedule The recording schedule allows you to set up scheduled recording to the microSD™ card or to Network Sharing. Recording This section allows you to define recording schedules for the camera. For continuous recording: Select type of Recording Storage. •... -
Page 46: Schedule
Schedule This section allows you to establish schedules to use in other section. To create a schedule: Select a Schedule set (1-10). Check the desired week day check boxes. Select Day or Night. Designate a Start Time and Duration. Click Save. -
Page 47: Interval Recording
Interval Recording Interval recording allows you to record in consistent intervals and save the files for later viewing. Turn Interval Recording On or Off. Designate the Time Interval (seconds). Designate the Trigger Action using the appropriate checkbox, and then use the dropdown menus to further manage the Trigger Action. Type a file name, and then choose how the file name is multiplied for multiple files. -
Page 48: Maintenance
Maintenance On the Maintenance page you can export the cameras current configuration, or import the configuration for a camera. Use the factory default page to reset the IP Camera to factory default settings if necessary. Note Do not import configuration files from different models of cameras. Configuration Export Configuration: Check the appropriate boxes for information that you want exported. -
Page 49: Software
Software Note Make sure the software upgrade file is available before starting the software upgrade. Click Browse and find the upgrade file. Note Do not change the file name, or the system will fail to find the file. Select the file name from the list under Step 2. Click Upgrade. -
Page 50: Audio
Audio Audio Input Grain – sets the amplification that the camera applies to the incoming audio before transmitting. Audio Output Delay – Sets a delay in the audio transmission. This is used when there is significant lag in video transmission to help sync the audio and video. Volume –... -
Page 51: Specifications
SPECIFICATIONS CAMERA SPECIFICATIONS Model IKS-WR7412 Maximum Resolution 1080p (2MP) Image Sensor Sony 1/2.8” CMOS Video Compression H.264 / MJPEG 30 IPS @ 1080P [1920 x 1080 / 2MP] 30 IPS @ 1280 x 1024 (1.3MP) Frame Rate 30 IPS @ 720P [1280 x 720 / 1MP]... - Page 52 Model IKS-WR7412 Backlight Compensation Auto Gain Control IP Rating IP66 (Outdoor) Operating Temperature 14°F (-10°C) ~ 122°F (50°C) Active / Passive Passive Cooling Power Consumption 5.8W Max Input Voltage 802.3af (PoE Only) PoE Class IR Range 24 LEDs (850 mm)
- Page 53 www.toshibasecurity.com 1-877-855-1349 © 2015 Toshiba All rights reserved. No part of this publication may be reproduced by any means without written permission from Toshiba. The information in this publication is believed to be accurate in all respects. However, Toshiba cannot assume responsibility for any consequences resulting from the use thereof.
