Page 1: Network Camera
NETWORK CAMERA Model: IKS-WR7022 User’s Manual For information on our latest products and peripheral devices, refer to the following web site: www.toshibasecurity.com If the URL changes, refer to www.toshiba.com... - Page 3 32953AC...
- Page 4 This documentation is copyrighted. All other rights are reserved to TOSHIBA. TOSHIBA, and Surveillix, are registered trademarks of TOSHIBA in the United States and elsewhere; Windows, and Windows XP Embedded are registered trademarks of Microsoft Corporation. All other brand and product names are trademarks or registered trademarks of the respective owners.
-
Page 5: Important Safeguards
Important Safeguards Read Instructions Read all the safety and operating instructions before operating the product. Retain Instructions Retain the safety instructions and user's manual for future reference. Warnings Comply with all warnings on the product and in the user's manual. Follow Instructions Follow all operating and use instructions. - Page 6 13. Lightning For additional protection on this camera during a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the power supply and cable system. This will prevent damage to the camera due to lightning and power line surges.
- Page 7 Precautions Operating • Before using, make sure power supply and others are properly connected. • While operating, if any abnormal condition or malfunction is observed, stop using the camera immediately and then contact your local dealer. Handling • Do not disassemble or tamper with parts inside the camera. •...
- Page 8 • Notwithstanding the foregoing, Toshiba's liabilities shall not, in any circumstances, exceed the purchase price of the product. Copyright and Right of Portrait • There may be a conflict with the Copyright Law and other laws when a customer uses, displays, distributes, or exhibits an image picked up by the camera without permission from the copyright holder.
- Page 9 CAUTION: Your authority to operate this FCC verified equipment could be voided if you make changes or modifications not expressly approved by the party. Industry Canada Information CAN ICES-3 A / NMB-3 A This symbol on the product or on its packaging indicates that this product shall not be treated as household waste in accordance with Directive 2002/96/EC.
- Page 10 Warning TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. DANGEROUS HIGH VOLTAGES ARE PRESENT INSIDE THE ENCLOSURE. DO NOT OPEN THE CABINET. THIS INSTALLATION SHOULD BE MADE BY A QUALIFIED SERVICE PERSON AND SHOULD CONFORM TO ALL LOCAL CODES.
-
Page 11: Table Of Contents
Product Features ...................... 14 Getting Started ..................15 Box Contents ........................ 15 Camera Overview ......................16 Camera Dimensions ....................16 IKS-WR7022 ......................16 Connections ......................17 Indoor Cameras ....................17 POE Power Source ..................17 12vDC Power Source ..................18 Locate Camera .................. - Page 12 Get IP an Address Automatically (DHCP) ............27 Use Static IP Address ..................27 IPv6 Address Configuration ................28 User Setup ........................ 28 Admin Password ....................28 Add User ......................28 Delete User ......................28 Modify User ......................29 File Location ......................29 Picture Setup ........................
- Page 13 Tampering and Network Failure Detection ............... 41 Mail, HTTP and FTP Setup ..................42 SD Card ........................42 Network Share ......................43 Recording Schedule ....................44 Recording ......................44 Schedule ......................45 Interval Recording ....................46 Maintenance ......................47 Configuration ......................47 Factory Default .....................
-
Page 14: Introduction
INTRODUCTION OVERVIEW The Toshiba Outdoor Fixed IP cameras are capable of providing real time streaming video with smooth image quality. The IP Mini Dome cameras offer quad streaming and can be used in a variety of installations including shops, stores, banks, parking lots, factories and for building surveillance. -
Page 15: Getting Started
GETTING STARTED BOX CONTENTS Before proceeding, please check that the box contains the items listed here. If any item is missing or has defects, DO NOT install or operate the product and contact your dealer for assistance. Camera (FPW or APW) Mount Plate &... -
Page 16: Camera Overview
CAMERA OVERVIEW Before installing or connecting the dome camera, please refer to this section and complete preparations for dome setup and all switch settings. Camera Dimensions IKS-WR7022 Height: 2.9” Width: 4.9”... -
Page 17: Connections
Connections Indoor Cameras The camera is compatible with 12vDC and Power over Ethernet (PoE). Connect power to the camera using the provided power connector lead or connect the camera to a PoE power source. If you are connecting 12vDC power, verify the polarity of the power connection. -
Page 18: 12Vdc Power Source
12vDC Power Source If PoE is not being used, a power adapter is needed to power the camera. An additional 12vDC connector cable is required. -
Page 19: Locate Camera
Installation You can run Device Search on any personal computer (PC) or laptop using the software CD included with your Surveillix IP camera or by downloading the program from toshibasecurity.com. Note Device Search will only work on PCs or laptops that use a Windows operating system. -
Page 20: Device Addressing
Device Addressing The functions on the Device Addressing tab allow you to find network cameras. Finding Network Devices Click Device Search. To sort your search by Camera Model, Project, or Camera Name, select your desired criteria from the appropriate lists. -
Page 21: Viewing A Network Camera
Viewing a Network Camera To view a network camera over the web using the camera’s viewer software, double-click the name of the camera. Click Browse. Enter the Username and Password for the camera. The username and password are case sensitive. It is strongly recommended that the password be changed after the initial setup to prevent unauthorized access. -
Page 22: Setup & Configuration
SETUP & CONFIGURATION Connecting to the Camera Locate the camera on the IP Finder list. Double-click the camera to open the Viewer software in your web browser. Click Browse in the pop-up window. Log in to the camera with the appropriate User Name and Password. Note The default User name is admin and the default Password is1234. -
Page 23: Connecting Over The Internet
Connecting Over the Internet There are some challenges with connecting to Toshiba IP cameras over WAN (internet) connections because the camera streams video over RTSP. RTSP is an excellent protocol for media and is now used on many IP cameras (including Toshiba) as the default streaming option. -
Page 24: Viewer Tabs
Viewer Tabs Live – Monitor video and perform other video related functions. Setup – Set the camera name, IP address, and define users. This tab also allows you to configure the camera settings and view streams. Advanced – Perform advanced setup configurations, like network setup, security, alarms and maintenance. -
Page 25: Live
LIVE Full Screen – This will display the live feed in full screen. Snapshot – Click the button, and a JPEG snapshot will automatically be saved in the appointed place. The default location is: C:\. Note If you are using Windows Vista or 7, you will need to change the Snapshot location. -
Page 26: Setup
SETUP The Setup menu includes System Settings, Picture Setup, and Streaming Settings. Note The Setup menu displays limited setup options. For a complete list of setup options, see the Advanced section. SYSTEM SETTING Camera Name Host Name – The Host Name is used to identify the camera on your system. -
Page 27: Get Ip An Address Automatically (Dhcp)
Get IP an Address Automatically (DHCP) The camera comes preconfigured with a fixed IP address, selecting Get IP address automatically requires a router or DHCP server to assign an IP address to the camera. Note Every network device has a unique Media Access Control (MAC) address that can be used for identification. -
Page 28: Ipv6 Address Configuration
IPv6 Address Configuration To enable IPv6 select Enable IPv6 and click Save. See your network administrator if you are unsure of your network configuration. User Setup Admin Password Manage the password for the Administrator account. To change the administrator password: Type a new Administrator Password, and then type again to confirm the password. -
Page 29: Modify User
Modify User Select the user name on the User Name list. Click Edit. In the resulting window, modify the Password and/or feature permissions. Click Save. Note For security reasons, every time the user properties are opened the access check boxes are automatically cleared. Make sure you select any user access options each time you edit the user properties. -
Page 30: White Balance
Min Shutter Speed – Choose a pre-determined shutter speed. Manual Mode – Changing the shutter mode to manual will allow you to select the minimum shutter speed that the camera will use. This can drastically change the amount of light entering the camera. Click Set to save your changes. -
Page 31: Picture Adjustment
Picture Adjustment Each of the Picture Adjustment settings is set to the recommended default. Brightness – Adjust the image’s brightness on the camera. The Backlight value is adjustable from 0 (dim) ~ +20 (brightest). Sharpness – Increasing the sharpness level can make the image looked sharper;... -
Page 32: Add Detection Window
Add Detection Window Use the Motion Detection dropdown to select a motion detection preset. Click Add. Note The selected motion detection square will be red. Arrange and size the motion detection window as desired. Click Save. Delete Motion Detection Window Click to select the desired motion detection window. -
Page 33: Streaming Settings
STREAMING SETTINGS Video Resolution The camera provides eight codec options under video resolution (two single streaming options, two sets of dual streaming options, two sets of tri- streaming options, and two sets of quad-streaming options): • H.264 Only • MJPEG Only •... -
Page 34: Video Orientation
Video Orientation Normal Video – The video will be oriented as the camera position dictates. 180 Degree Rotate – Rotate the video 180 degrees. 90 Degree Clockwise – Rotate the video 90 degrees clockwise. 90 Degree Counter Clockwise– Rotate the video 90 degrees counter clockwise. Mirror Video –... -
Page 35: Video Frame Rate
Video Frame Rate Setting the camera to transmit fewer frames can save bandwidth. Use the Frame Rate Control screen to adjust the frame rate of each stream. Each of the MJPEG and H.264 streams can have a separate frame rate setting from 1 to 30 frames per second. -
Page 36: Video Compression
Video Compression You can select an MJPEG / H.264 compression mode on the video compression page appropriate for your application. You can also select to display compression inflation on the Live Screen. MJPEG compression settings include: • High compression, low bitrate, low quality •... -
Page 37: Advanced
ADVANCED SYSTEM SETTING Network Setup The Network Setup settings will automatically be set at the recommended default after the camera connection is made. DDNS DDNS (Dynamic Domain Name Service) is a service that allows a connection to an IP address using a hostname (URL) address instead of a numeric IP address. Most Internet Service Providers use Dynamic IP Addressing that frequently changes the public IP address of your internet connection;... -
Page 38: Snmp Settings
SNMP Settings With Simple Network Management Protocol (SNMP) enabled, the camera can be monitored and managed remotely with a network management system. Contact your network administrator if you are not familiar with SNMP setup. UPnP (Universal Plug N’ Play) • Enable UPnP –... -
Page 39: Network Security
Network Security HTTP The camera can send alarm messages to a specific Hypertext Transfer Protocol (HTTP) site when motion is detected or when the sensor input is activated. You can assign alarm messages to up to two HTTP sites. IP Filtering IP Filtering allows you limit access to your IP cameras by IP address. -
Page 40: Alarm Application
Alarm Application The alarms menu is where alarm connections are configured. Alarm Switch – Designate when the alarm will be active; Off, On, or By Schedule. Alarm Type – Designate if the alarm is normally open or normally closed. • NOH –... -
Page 41: Tampering And Network Failure Detection
Tampering and Network Failure Detection Tampering Alarm – Turn the Tampering Alarm On, Off, or On By Schedule. Tampering Duration – Designate the amount of time (in seconds) that tampering must occur in order for a Tampering Alarm to activate. Triggered Action –... -
Page 42: Mail, Http And Ftp Setup
Mail, HTTP and FTP Setup The camera can send an e-mail via Simple Mail Transfer Protocol (SMTP) when a variety of events occur. SMTP is a protocol for sending e-mail messages between servers. SMTP is a relatively simple, text-based protocol, where one or more recipients of a message are specified and the message text is transferred. -
Page 43: Network Share
Network Share Network Share is a network protocol that runs a variety of different system platforms, allowing for file sharing between computers operating on Windows and computers operating on Unix. This serves as an additional storage type. Configuration requires the host IP address, share name, and credentials. Once configured, cameras can record events to the network share. -
Page 44: Recording Schedule
Recording Schedule The recording schedule allows you to set up scheduled recording to the microSD™ card or to Network Sharing. Recording This section allows you to define recording schedules for the camera. For continuous recording: Select type of Recording Storage. •... -
Page 45: Schedule
Schedule This section allows you to establish schedules to use in other section. To create a schedule: Select a Schedule set (1-10). Check the desired week day check boxes. Select Day or Night. Designate a Start Time and Duration. Click Save. 32953AC... -
Page 46: Interval Recording
Interval Recording... -
Page 47: Maintenance
Maintenance On the Maintenance page you can export the cameras current configuration, or import the configuration for a camera. Use the factory default page to reset the IP Camera to factory default settings if necessary. Note Do not import configuration files from different models of cameras. Configuration Export Configuration: Check the appropriate boxes for information that you want exported. -
Page 48: Software
Software Note Make sure the software upgrade file is available before starting the software upgrade. Click Browse and find the upgrade file. Note Do not change the file name, or the system will fail to find the file. Select the file name from the list under Step 2. Click Upgrade. -
Page 49: Streaming Setting
STREAMING SETTING Audio Audio Input Grain – sets the amplification that the camera applies to the incoming audio before transmitting. Audio Output Delay – Sets a delay in the audio transmission. This is used when there is significant lag in video transmission to help sync the audio and video. Volume –... -
Page 50: Specifications
SPECIFICATIONS CAMERA SPECIFICATIONS Model IKS-WR7022 Maximum Resolution 1080p (2MP) Image Sensory Sony 1/2.8” CMOS Video Compression H.264 / MPEG4 / MJPEG Frame Rate 30IPS @ 1080p (2MP) ONVIF Profile S Streaming Up to 2 configurable streams Browser Supoprt Internet Explorer (Active X) - Page 51 Model IKS-WR7022 Power Consumption 8.2W Max Rated Amperage 0.68A (12vDC) Input Voltage PoE / 12vDC PoE Class Camera Weight 0.97 lbs (439 g) Dimensions (W x H): 4.9" x 2.9" (125 mm x 74 mm) Housing / Dome Cover White / Clear Tilt / Rotation Tilt = 90º...
- Page 52 www.toshibasecurity.com 1-877-855-1349 © 2015 Toshiba All rights reserved. No part of this publication may be reproduced by any means without written permission from Toshiba. The information in this publication is believed to be accurate in all respects. However, Toshiba cannot assume responsibility for any consequences resulting from the use thereof.
