Page 1: Network Camera
NETWORK CAMERA Model: IKS-WD6112 User’s Manual For information on our latest products and peripheral devices, refer to the following web site: www.toshibasecurity.com If the URL changes, refer to www.toshiba.com... - Page 3 Toshibahas been advised of the possibility of such damages and whether in an action or contract or tort, including negligence. This documentation is copyrighted. All other rights are reserved to Toshiba. Surveillix, and Toshiba, are registered trademarks of Toshibain the United States and elsewhere; Windows, and Windows XP Embedded are registered trademarks of Microsoft Corporation.
-
Page 4: Important Safeguards
Important Safeguards Read Instructions Read all the safety and operating instructions before operating the product. Retain Instructions Retain the safety instructions and user's manual for future reference. Warnings Comply with all warnings on the product and in the user's manual. Follow Instructions Follow all operating and use instructions. - Page 5 13. Lightning For additional protection on this camera during a lightning storm, or when it is left unattendedand unused for long periods of time, unplug it from the wall outlet and disconnect the powersupply and cable system. This will prevent damage to the camera due to lightning and power line surges.
- Page 6 While operating, if any abnormal condition or malfunction is observed, stop using the camera immediately and then contact your local dealer. Handling Do not disassemble or tamper with parts inside the camera. Do not drop or subject the camera to shock and vibration as this can damage camera. ...
- Page 7 Installation and Storage Do not install the camera in areas of extreme temperaturesin excess of the allowable range. (14°F~ 122°F / -10°C ~ 50°C) Avoid installing in humid or dusty places. The relative humidity must be below 90%. ...
- Page 8 Usage Limitation The product is not designed for any "critical applications." "Critical applications" means lifesupport systems, exhaust or smoke extraction applications, medical applications, commercialaviation, mass transit applications, military applications, homeland security applications, nuclearfacilities or systems or any other applications where product failure could lead to injury topersons or loss of life or catastrophic property damage.
- Page 9 This symbol on the product or on its packaging indicatesthat this product shall not be treated as household waste inaccordance with Directive 2002/96/EC. Instead it shall behanded over to the applicable collection point for therecycling of electrical and electronic equipment. By properwaste handling of this product you ensure that it has nonegative consequences for the environment and humanhealth, which could otherwise be caused if this product isthrown into the garbage bin.
- Page 10 Warning TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. DANGEROUS HIGH VOLTAGES ARE PRESENT INSIDE THE ENCLOSURE. DO NOT OPEN THE CABINET. THIS INSTALLATION SHOULD BE MADE BY A QUALIFIED SERVICE PERSON AND SHOULD CONFORM TO ALL LOCAL CODES.
-
Page 11: Table Of Contents
TABLE OF CONTENTS Table of Contents ................... 11 Introduction .................... 14 Overview ........................14 Product Features ...................... 14 Getting Started ..................15 Box Contents ........................ 15 Camera Overview ......................16 Dome Diagram ......................16 ... - Page 12 Network ........................ 31 Get IP address automatically (DHCP) ............. 31 Use Fixed IP Address ..................32 QoS (Quality of Service) .................. 33 SNMP....................... 33 UPnP (Universal Plug and Play) ..............34 DDNS ........................35 ...
- Page 13 Picture Adjustment ....................63 Backlight ....................... 63 Digital Zoom ......................63 D-WDR Function ....................63 Noise Reduction ....................64 TV System ......................64 Logout ........................64 Specifications ..................65 Camera Specifications ....................65 ...
-
Page 14: Introduction
INTRODUCTION OVERVIEW The Surveillix Tamper Resistant IP Mini Dome cameras are capable of providing real time streaming video with smooth image quality. The IP Mini Dome cameras offer quad streaming and can be used in a variety of installations including shops, stores, banks, parking lots, factories and for building surveillance. -
Page 15: Getting Started
GETTING STARTED BOX CONTENTS Before proceeding, please check that the box contains the items listed here. If any item is missing or has defects, DO NOT install or operate the product and contact your dealer for assistance. Camera Self Tapping Screws Plastic Anchors Rubber Washers Security Torx Tool... -
Page 16: Camera Overview
CAMERA OVERVIEW Before installing or connecting the dome camera, please refer to this section and complete preparations for dome setup and all switch settings. Dome Diagram Reset Button Restore camera settings to default settings Lens Lock Nut Loosen the nut to adjust the lens Lens Rotate the lens left/right to adjust the focus Tilt Fixed Screw... -
Page 17: Dimensions
Dimensions 1.75” (44.45 mm) 4.625” (117.5 mm) Ø 1.75” (44.45 mm) Diameter – 110.21mm (4.3 inches) Height – 47.66mm (1.87inches) -
Page 18: Connections
Connections Indoor Camera The Indoor Tamper Resistant IP Dome Cameras use Power over Ethernet (PoE) to power the cameras. The only connection on the camera is the RJ45 Ethernet connector located on the rear of the camera. Connect one end of the Ethernet cable to the RJ45 port on the camera and the other end to power sourcing equipment (PSE) like a hub or router. -
Page 19: Micro Sd Card
Micro SD Card All Surveillix Tamper Resistant IP Mini Dome cameras include a Micro SD card slot. Use a Micro SD card for on-board emergency recording. -
Page 20: Locate Camera
LOCATE CAMERA SURVEILLIX DEVICE SEARCH Use the included Device Search software to easily find your network cameras for initial setup. The Surveillix Device Search software is included on the CD with all Surveillix IP devices. Installation You can runDevice Search on any personal computer (PC) or laptop using the software CD included with your Surveillix IP camera or by downloading the program from toshibasecurity.com. -
Page 21: Device Addressing
Device Addressing The functions on the Device Addressing tab allow you to find network cameras. Finding Network Devices Click Device Search. To sort your search by Camera Model, Project, or Camera Name, select your desired criteria from the appropriate lists. -
Page 22: Setup & Configuration
SETUP & CONFIGURATION CONNECTING TO THE CAMERA Locate the camera on the Device Search list. Double-click the camera to open the Viewer software in your web browser. Log in to the camera with the appropriate User Name and Password. Note The default User name is Admin and the default Password is1234. -
Page 23: Connecting A Stream
Surveillix IP cameras using third party software like VLC media player (http://www.videolan.org). To connect the camera you may need to provide the stream URL. All Surveillix IP cameras are capable of delivering two RTSP streams, as well as streaming MJPEG over HTTP. -
Page 24: Connecting Over The Internet
There are some challenges with connecting to Surveillix IP cameras over WAN (internet) connections because the camera streams video over RTSP. RTSP is an excellent protocol for media and is now used on many IP cameras (including Surveillix) as the default streaming option. -
Page 25: Viewer Software
VIEWER SOFTWARE To access the setup menu, you need to install the viewer software on your PC or recorder. The viewer software will install automatically the first time you connect to the camera. If your internet browser doesn’t install the viewer software, check the security settings or ActiveX controls and plug-in settings. - Page 26 Screen Size Adjustment – Click the screen size buttons to adjust image display size x1/2 and full screen. Digital Zoom Control – In full screen mode, right-click to activate digital zoom and use the scroll wheel to zoom in/out. Talk – Talk allows the local site to talk to the remote site. This function is only available to Users who have been granted this privilege by the Administrator.
- Page 27 Snapshot – Click the button, and a JPEG snapshot will automatically be saved in the appointed place. The default location is: C:\. Note If you are using Windows Vista or 7, you will need to change the Snapshot location. Windows UAC does not allow internet programs to write directly to C:\ for security reasons.
-
Page 28: System
System Note The System tab is only accessible by the Administrator. System Host Name – The Host Name is used to identify the camera on your system. If camera based Motion Detection is enabled and is set to send alarm message by Mail/FTP, the host name entered here will display in the alarm message. -
Page 29: Security
Security Admin Password To change the administrator password, type a new password in the Admin Password box and confirm below. Note The maximum length of the password is 14 characters. The following characters are valid: A-Z, a-z, 0-9, !#$%&’-.@^_~. -
Page 30: Add User
Add User The user name and passwords are limited to 16 characters. There is a maximum of twenty user accounts Type the new User name and Password Select the appropriate check boxes to give the user Camera Control, Talk and Listen permissions. -
Page 31: Network
Every network device has a unique Media Access Control (MAC) address that can be used for identification. The MAC address is located on the bottom of each camera, and on the box label (Surveillix Device Search also displays the MAC address for identification). Record your camera’s MAC address for... -
Page 32: Use Fixed Ip Address
Click Save to confirm the new setting. When using static IP address to login to the IP Camera, you can access it either through Surveillix Device Search software or type the IP address directly in the address bar of your Internet Explorer. -
Page 33: Qos (Quality Of Service)
QoS (Quality of Service) Quality of Service allows you to prioritize network traffic services of the camera’s functions. The QoS function utilizes the Differentiated Services prioritized using Codepoint values (DSCP). Note Routers and switches on the network must be QoS or DSCP capable, and have these settings enabled for this function to operate on your network. -
Page 34: Upnp (Universal Plug And Play)
UPnP (Universal Plug and Play) Enable UPnP: When enabled the camera will appear in My Network Places on Windows computers running UPnP on the same network. Enable UPnP Port Forwarding: When enabled the camera will attempt to open the web server port on the router automatically. -
Page 35: Ddns
DDNS DDNS (Dynamic Domain Name Service) is a service that allows a connection to an IP address using a hostname (URL) address instead of a numeric IP address. Most Internet Service Providers use Dynamic IP Addressing that frequently changes the public IP address of your internet connection;... -
Page 36: Mail
Mail The camera can send an e-mail via Simple Mail Transfer Protocol (SMTP) when motion is detected.SMTP is a protocol for sending e-mail messages between servers. SMTP is a relatively simple, text-based protocol, where one or more recipients of a message are specified and the message text is transferred. -
Page 37: Ftp
The camera can send alarm message toa specific File Transfer Protocol (FTP) site when motion is detected.You can assign alarm message to up to two FTP sites. Type the FTP details, including server, server port, user name, password and remote folder, in the appropriate boxes. -
Page 38: Http
HTTP The camera can send alarm messages toa specific Hypertext Transfer Protocol (HTTP) site when motion is detected or when the sensor input is activated.You can assign alarm messages to up to two HTTP sites. Type the HTTP details, including server, user name and password, in the appropriate fields. -
Page 39: Motion Detection
Motion Detection Motion Detection allows the camera to detect motion and trigger alarms when the motion level in the detected area exceeds the determined sensitivity threshold value. In the Motion Detection page, there is a motion detection window (red box) displayed on the Live View Pane. - Page 40 Whenmotion detection is activated, the Motion pop-up window will open. When motion is detected, the signals will be displayed on the Motion window as shown below. Motion Detection Turn motion detection on or off.The default setting is Off. Motion Detection Setting ...
- Page 41 Triggered Action You can specify which actions the camera should take when motion is detected. Send Alarm Message by FTP/E-Mail – Select to send an alarm message to a configured FTP and/or E-Mail address when motion is detected. When sending to email, the alarm notification is text only.
- Page 42 File Name – Enter a file name in the box, ex. image.jpg. The uploaded image’s file name format can be set in this section. Please select the one that meets your requirements. Add date/time suffix File name: imageYYMMDD_HHNNSS_XX.jpg Y: Year, M: Month, D: Day H: Hour, N: Minute, S: Second X: Sequence Number ...
-
Page 43: Storage Management
Storage Management All Surveillix Tamper Resistant IP Mini Dome cameras include an integrated microSD™ card that can be used to record video or images. The card slot is compatible with a microSD™ card up to 16GB. Device Information – Displays the storage total size and free space information of the included microSD™... -
Page 44: Recording
Recording The recording schedule allows you to set up scheduled recording to the microSD™ card. To set up continuous recording: Select Always to continually record until the card is full. To set the camera to overwrite old data, see the instructions for Disk Cleanup Setting earlier in this section. -
Page 45: File Location
File Location The camera supports a JPEG snapshot function. You can specify a storage location for snapshot images. The default location is: C:\. Note If you are using Windows Vista,7, or 8, you will need to change the Snapshot location. Windows UAC does not allow internet programs to write directly to C:\ for security reasons. -
Page 46: Information
Information The Information page contains the System Log, User Information, and Parameter List. System Log Click System Log to view the system log file. The content of the file provides useful information about configuration and connections. -
Page 47: User Login Information
User Login Information All users for the cameraare listed under User information. The example below show that the Admin password is 1234 and there is one user named User with the password 4321. View User Privilege Select a user account from the list and click get user privacy to view the permissions for the user account. -
Page 48: Parameter List
Parameter List Click Parameter List to view the system parameter settings. -
Page 49: Software Upgrade
Software Upgrade Upgrading the Camera Viewer Software Note Make sure the software upgrade file is available before starting the software upgrade. Click Browse and find the upgrade file. Note Do not change the file name, or the system will fail to find the file. Select the file name from the list under Step 2. -
Page 50: Maintenance
Maintenance On the Maintenance page you can export the cameras current configuration, or import the configuration for a camera.Use the factory defaultpage to reset the IP Camera to factory default settings if necessary. Note Do not import configuration files from different models of cameras. Full Restore –To reset the IP camera to the factory default settings, including the default IP address, click Set Default. -
Page 51: Video And Audio Streaming Settings
Video and Audio Streaming Settings On the Streaming tab, the Administrator can configure specific video resolution, video compression mode, video protocol, audio transmission mode, etc. Video Format Select the desired video resolution for the camera on the Video Format page. The recorder will record video based on the resolution selected here. -
Page 52: Video Resolution
Video Resolution The camera provides four codec options under video resolution (two single streaming options and two sets of dual streaming options): MJPEG only H.264 only MJPEG+ H.264 H.264 + H.264 Once a codec option is selected, multiple resolutions are available for each stream. MJPEG Resolutions* H.264 Resolutions* 1920x1080... -
Page 53: Video Rotate Type
Video Rotate Type You can change the orientation of the video output if necessary. Normal Video – This is the default rotation designed for a normal setup with the camera mounted with the dome facing down. Flip Video – This option will vertically flip the video image (without the intervention of another device this may cause the reversal of perceived left and right when viewing the image). -
Page 54: Video Compression
Video Compression You can select the MJPEG/H.264 compression mode on the video compression page appropriate for your application. You can alsoselect to display compression information on the Home page. MJPEG compression settings include: high compression, low bitrate, low quality ... -
Page 55: Hot Spot
Hot Spot The Hot Spot feature allows you to transmit different parts of the camera image on separate streams. Each stream is displaying a portion of the image at the full size of a regular image. This is useful for focusing on details in different areas of a single camera view. -
Page 56: Video Ocx Protocol
Video OCX Protocol On the Video OCX protocol page, you can select different protocols for streaming media over the network.In the case of multicast networking, you can select the Multicast mode. Video OCX protocol setting options include: RTP over UDP ... -
Page 57: Frame Rate Control
Frame Rate Control Setting the camera to transmit fewer frames can save bandwidth. Use the Frame Rate Control screen to adjust the frame rate of each stream. Each of the MJPEG and H.264 streams can have a separate frame rate setting from 1 to 30 frames per second. -
Page 58: Video Mask
Video Mask You can use the video mask page to define a privacy mask to keep users from viewing parts of the image. You can enable up to five privacy masks and choose a color to obscure the live view from users. -
Page 59: Audio
Audio On the Audio page, you can select an audio transmission mode and audio bit rate. Audio is only available on the CM-611. Note Audio monitoring and recording laws vary from location to location. It is highly recommended that you consult your local, state and federal laws to verify that you are in compliance before implementing audio recording. -
Page 60: Bit Rate
Bit Rate Selectable audio transmission bit rates include the following: 16 kbps (G.726) 40 kbps (G.726) 24 kbps (G.726) uLAW (G.711) 32 kbps (G.726) ALAW (G.711) Both uLAW and ALAW signify 64 kbps, but in different compression formats. A higher bit rate will provide higher audio quality and require more bandwidth. -
Page 61: Camera
Camera Exposure The exposure is the amount of light received by the image sensor and is determined by the width of lens diaphragm opening (iris adjustment),the amount of exposure by the sensor (shutterspeed) and other exposure parameters. When you have made your changes, click Set in the Exposure section. -
Page 62: White Balance
White Balance Acamera needs to find reference color temperature, which is a way of measuring the quality of a light source, for calculating all the other colors. The unit for measuring this ratio is in degree Kelvin (K). Users can select one of the White Balance Control modes according to the operating environment. -
Page 63: Picture Adjustment
Picture Adjustment Adjust your image quality in the Picture Adjustment section. When you have made an alteration to any of the following settings, click Set to save your changes. Brightness Adjust the image’s brightness on the camera. The Backlight value is adjustable from -12 (dim) ~ +15 (brightest). -
Page 64: Noise Reduction
Noise Reduction Adjust your level of Noise Reduction as necessary, and then click Set. TV System Select your transmission type (NTSC or PAL), and then click Set. Logout Click the Logout tab to change users. -
Page 65: Specifications
SPECIFICATIONS CAMERA SPECIFICATIONS Model IKS-WD6112 Indoor / Outdoor Indoor Image Sensor 1/2.8” CMOS IP Rating Type / Format H.264 / MJPEG Wide Dynamic Range Digital WDR Minimum Illumination 0.1 Lux @ 30 IRE Day / Night Digital Day / Night... -
Page 66: Ip Specifications
Model IKS-WD6112 Rated Amperage 0.073A Input Voltage PoE Only Weight 0.4 lbs (180 g) Dimensions Ø4.625" (117.5 mm) x H: 1.75” (44.45 mm) Housing / Dome White / Clear Cover IP SPECIFICATIONS Model IKS-WD6112 Video Compression H.264 / MJPEG Multi Streaming H.264 + H.264 + H.264 + H.264... - Page 67 www.toshibasecurity.com 1-877-855-1349 © 2014Toshiba All rights reserved. No part of this publication may be reproduced by any means without written permission from Toshiba. The information in this publication is believed to be accurate in all respects. However, Toshibacannot assume responsibility for any consequences resulting from the use thereof.
